Communication Ports
4.1 Copper Ethernet Ports
1
Figure 4.2
4.1
Copper Ethernet Ports
The RUGGEDCOM M2200F supports several 10/100Base-TX and 10/100/1000Base-
TX Ethernet ports that allow connection to standard Category 5 (CAT-5) unshielded
twisted-pair (UTP) cables with Micro-D male connectors. The Micro-D connectors are
directly connected to the chassis ground on the device and can accept CAT-5 shield-
ed twisted-pair (STP) cables.
Pin-Out
The following is the pin-out description for the Micro-D connectors:
Figure 4.3
22
1
Port LED
Port LEDs
1
6
Micro-D 10/100/1000Base-TX Port Pin Configuration
Pin
10/100Base-TX
1
RX+
2
RX-
3
TX+
4
Reserved (Do Not Connect)
LED State
Yellow (Solid)
Yellow (Blinking)
Off
Name
1000Base-TX
BI_DA+
BI_DA-
BI_DB+
BI_DC+
Description
Link established
Link activity
No link detected
Description
Receive Data+ or Bi-
Directional Pair A+
Receive Data- or Bi-
Directional Pair A-
Transmit Data+ or Bi-
Directional Pair B+
Transmit Data+ or Bi-
Directional Pair C+
RUGGEDCOM M2200F
Installation Manual, 01/2020, C79000-G8976-1343-06
