4.2

Fiber Optic Ethernet Ports

Fiber optic Ethernet ports are available with either LC (Lucent Connector), SC (Stan-
dard or Subscriber Connector) or ST (Straight Tip) connectors. Make sure the Trans-
mit (Tx) and Receive (Rx) connections of each port are properly connected and
matched to establish a proper link.
1
1
2
Figure 4.4
1
1
2
Figure 4.6
For specifications on the available fiber optic Ethernet ports, refer to
ernet Port Specifications (Page
RUGGEDCOM M2200F
Installation Manual, 01/2020, C79000-G8976-1343-06
Pin
10/100Base-TX
5
Reserved (Do Not Connect)
6
TX-
7
Reserved (Do Not Connect)
8
Reserved (Do Not Connect)
26)".
Tx Connector
Rx Connector
SC Port
Tx Connector
Rx Connector
ST Port
Name
1000Base-TX
BI_DC-
BI_DB-
BI_DD+
BI_DD-

2
1
Tx Connector
1
Rx Connector
2
Figure 4.5
2
27)".
Communication Ports
4.2 Fiber Optic Ethernet Ports
Description
Receive Data- or Bi-
Directional Pair C-
Transmit Data- or Bi-
Directional Pair B-
Receive Data- or Bi-
Directional Pair D+
Receive Data- or Bi-
Directional Pair D-
"Copper Ethernet
2
LC Port
"Fiber Optic Eth-
23
