- Page 1 SignalMax Fiber DAS High-Performance Hybrid-Fiber DAS Cellular Booster System for Large Buildings User Guide Questions support@surecall.com 1-888-365-6283...
-
Page 2: Table Of Contents
If you have any questions during setup, please reach out to our US-based experienced support technicians: Call: 1-888-365-6283 Email: support@surecall.com | Visit: www.surecall.com/support Watch installation, optimization and @SureCall Stay up to date with all things SureCall troubleshooting techniques on our SureCall YouTube channel 1-888-365-6283 | support@surecall.com | www.surecall.com... -
Page 3: Overview
The high-gain outside antenna captures even the weakest cell signal, from the cell tower where it is aimed. 2. The SignalMax Fiber DAS master unit uses Extended Range Technology™ (ERT ) to grab signal outside, at its strongest point, where it boosts voice, text and data signals for all 5G & 4G devices. -
Page 4: Package Contents
SureCall SignalMax Fiber DAS | Overview Package contents Unpack all package contents. For missing or damaged items, contact your reseller. Turn over the signal booster and record the model and serial number for reference: Serial #: Purchase Date: Inside Antenna... -
Page 5: Optional Accessories
SureCall SignalMax Fiber DAS | Overview Optional accessories Looking to upgrade your SureCall booster ? Boost your signal even further with these best-selling accessories: SC-LP Lightning arrestor prevents damage from electrical surges Expandable with Additional Remote Units The modular design of the hybrid-fiber DAS system allows for seamless upgrades and add-ons. As wireless demands increase, SignalMax Fiber DAS can scale accordingly. -
Page 6: Bluetooth Installation App
SureCall SignalMax Fiber DAS | Overview SureCall Bluetooth Installation App Use the SureCall mobile app to help with two important aspects of your SignalMax Fiber DAS signal booster setup; proper aiming of the outside antenna and ensuring adequate separation between outside antenna and inside antenna(s). -
Page 7: Bluetooth App Features
SureCall SignalMax Fiber DAS | Before Installation Bluetooth App Features SignalMax Fiber DAS features SureCall’s innovative Bluetooth mobile install app that indicates signal strength readings in real-time providing installation feedback and troubleshooting. Once you’ve downloaded the app and paired it with your booster, you will need to create a ‘soft install’... -
Page 8: Rsrp Vs Rssi Signal Measurements
SureCall SignalMax Fiber DAS | Before Installation RSRP vs RSSI signal measurements Cell phone bars are an approximation of your signal that varies by phone and carrier. Viewing measurements in decibel milliwatts provides a more accurate reading. In most cases, units are reported in RSRP (LTE & 5G signals) and will generally fall between -80 dBm (strong) and -130 dBm (very weak). - Page 9 SureCall SignalMax Fiber DAS | Before Installation FOR ANDROID devices: Download the app “LTE Discovery” in the Google Play store. Note band number 2. 4G LTE/5G (measurement in RSSI or RSRP) Android app “LTE Discovery” Signal measurement scales The relationship between RSRP and RSSI is approximate and depends on the channel bandwidth, noise floor and channel loading.
-
Page 10: Finding Your Closest Cell Tower
SureCall SignalMax Fiber DAS | Before Installation Finding your closest cell tower Since performance is largely determined by the signal received by the outdoor antenna, it is important to know the direction in which you will aim your directional outside antenna before installation. - Page 11 SureCall SignalMax Fiber DAS | Before Installation Visit website www.cellmapper.net Find your location on the map 2. Select your provider 3. Find your cell tower by clicking on the red or green dots on the map closest to the building.
-
Page 12: Soft Install
• Drill • Poles 1.75-2.5 inches in diameter are recommended to support the outdoor equipment in case of high winds. SureCall does not accept responsibility for damages to equipment installed on poles under 1.75 inches. • Recommended: Surge protected power strip for each unit Grounding the outside antenna SureCall recommends all outside antennas be properly grounded. -
Page 13: Installation
SureCall SignalMax Fiber DAS | Installation I N S TA L L AT I O N Before installation, review all the information in this manual. Prior to securing the location of any booster parts, a “soft install” is recommended as adjustments may be needed to optimize performance. -
Page 14: Components Overview
Components Overview Each SignalMax Fiber DAS kit contains a Master Unit and a Remote Unit. Each unit has two primary components – the booster unit and its mounting bracket. The Master Unit (MU) will be connected to a Outdoor Yagi Antenna (Donor) via SC-400 coax cable and then connected to the Remote Unit(s) via fiber cable (Optic). - Page 15 SureCall SignalMax Fiber DAS | Installation Outdoor Yagi Antenna Specifications Part Number: SC-530W Frequency: 617-697 / 698-960 / 1710-2700 MHz Beamwidth: H:90° E:60° / H:90° E:60° / H:70° E:55° Maximum Gain: 7 / 8 / 9 dBi VSWR: ≤2.0 Input Impedance: 50 Ω...
-
Page 16: Step 1: Install The Outside Antenna And Master Unit
SureCall SignalMax Fiber DAS | Installation Step 1: Install the outside antenna and master unit Once you have identified the area of strongest signal using the mobile app, choose where you will mount your outside antenna and master unit while considering the following antenna placement guidelines. -
Page 17: Step 2: Place The Remote Unit And Connect The Units With Fiber Optic Cable
SureCall SignalMax Fiber DAS | Installation Ground The Master Unit The Master unit includes a 20 ft ground wire (14-gauge) that can be used to help protect against electrical surges and potential shock hazards by providing a path for excess current to flow to the earth. -
Page 18: Step 3: Mount The Inside Antennas
Optimal placement should be central to where signal is needed with minimal obstacles near the antennas. Ultra-Thin Antenna • SureCall's Ultra-Thin dome antenna is mounted to the ceiling and broadcasts in 360°. Optional directional panel antennas: • Antennas should be mounted to a wall facing the area signal is needed –... -
Page 19: Step 4: Connect To Power
SureCall SignalMax Fiber DAS | Installation Ultra-Thin antenna installation The SC-628W ultra-wideband antenna is an omni- Indoor directional interior antenna that gathers and sends signals cable from all sides. Besides the antenna itself, parts include mounting options for an install that is accessible by crawl space or one that is not. -
Page 20: Base Unit Installation
SureCall SignalMax Fiber DAS | Installation Base Unit Installation Step 1: Mounting the Base Unit to a Wall To mount the booster to the wall in your chosen location follow the steps outlined below. Note: The Master Unit (MU) must be mounted vertically with the connectors facing downwards. If it is not mounted vertical the product warranty is voided. - Page 21 SureCall SignalMax Fiber DAS | Installation Add M8x14 bolts to lower sides of the booster. Place booster onto the U-shaped part of the Do not tighten. bracket as shown. Figure 14: Adding bolts to lower sides of the booster Figure 15: Placing the booster onto the wall bracket Tighten all 4 bolts.
-
Page 22: Booster Testing And Optimization
Antenna optimization The SignalMax Fiber DAS automatically reduces gain (coverage performance) because of insufficient RF separation between the inside and outside antennas. Consider the options listed in this section to resolve issues with inadequate antenna isolation. -
Page 23: Technical Specifications
SureCall SignalMax Fiber DAS | Specifications S P E C I F I C AT I O N S TECHNICAL SPECIFICATIONS Uplink Frequency Range (MHz): 698–716 / 776–787 / 824–849 / 1850–1915 / 1710–1755 Downlink Frequency Range (MHz): 728–746 / 746–757 / 869–894 / 1930–1995 / 2110–2155... -
Page 24: Kitting
6 dBi 7 dBi 7 dBi / 7 dBi *All equivalent antennas and cables are suitable for use with the SignalMax Fiber DAS Use of unauthorized antennas, cables, and/or coupling devices not conforming with ERP/ElRP and/or indoor-only restrictions is prohibited. -
Page 25: Account Management
Use the SureCall Cloud web portal to log in: https://SureCall-cloud.azurewebsites.net/ Log in Click the ‘Log in’ link in the upper right. Enter your login information provided by SureCall customer support and click the ‘Log in’ button. This will bring you to your dashboard screen. 1-888-365-6283 | support@surecall.com | www.surecall.com... -
Page 26: Reset Password
SureCall SignalMax Fiber DAS | IoT Cloud Access Click on your username to manage your account from any screen. From the dashboard screen, you can manage your access and devices. Reset Password Here, you can reset your password and view your profile. -
Page 27: Device Management
SureCall SignalMax Fiber DAS | IoT Cloud Access DEVICE MANAGEMENT Add New Device To manage devices, click the ‘Add/Delete Devices’ button from your dashboard to open up the booster management screen. To add a booster to your account, you will need the serial number (booster ID) and the authentication code provided by customer support. -
Page 28: Edit Device Name
SureCall SignalMax Fiber DAS | IoT Cloud Access Edit Device Name From this same window, the booster can be named so that it can be identified easier. Simply click the ‘Edit ’ button next to the booster then enter the new name in the edit box as shown below. Then click the ‘Update’ button to set this change. - Page 29 SureCall SignalMax Fiber DAS | Guidelines THIS IS A CONSUMER DEVICE BEFORE USE, you MUST REGISTER THIS DEVICE with your wireless provider and have your provider’s consent. Most wireless providers consent to the use of signal boosters. Some providers may not consent to the use of this device on their network. If you are unsure, contact your provider.
-
Page 30: Three-Year Product Warranty
Buyers may obtain an RMA number for warranty returns by calling the SureCall Return Department toll-free at 1-888-365-6283. Any returns received by SureCall without an RMA number clearly printed on the outside of the shipping container will be returned to sender. In order to receive full credit for signal boosters, all accessories originally included in the signal booster box must be returned with the signal booster.
