- Page 1 IP Camera User Manual O3FDP9 /O3FB56M /O3FB68 /O3FD8M O2iBD3 /O2iB68 / O2iB68M/ O2iD8 /O2iD8M O2B6M /O2iB50M /O2D6M /O2iD9 /O2iB9 Please read this manual carefully before operating the unit and keep it for further reference.
-
Page 2: Regulatory Information
This owner’s manual is designed to be a reference tool for your system. Please read this manual carefully before operating the unit and retain it for future reference. Should you require any technical assistance, contact Speco Technologies Tech Support at 1-800-645-5516 Important Safeguards and Warnings 1．Electrical safety... - Page 3 Speco Technologies is not liable for any loss caused by improper operation. Note: Before installation, check the package and make sure that all components are included. Contact your rep or Speco customer service department immediately if something is broken or missing in the package. Accessory Name Amount...
-
Page 4: Table Of Contents
IP Camera User Manual Table of Contents Regulatory Information --------------------------------------------------------------------------------------------------------------------- Introduction ........................................6 Welcome ..........................................6 Web Access and Login ....................................7 2.1 LAN ..........................................7 Live View ......................................... 8 Camera Configuration ....................................9 4.1 System ........................................9 4.1.1 System Restart ....................................9 4.1.2 Factory Default .................................... - Page 5 4.4.3 Alarm In Mode ....................................23 4.4.4 Notification ...................................... 24 4.5 User Admin ....................................... 25 4.5.1 Password Change ..................................25 4.5.2 User Account ....................................25 Appendix ..........................................26 Appendix 1 Troubleshooting ....................................26...
-
Page 6: Introduction
IP Camera User Manual 1. Introduction Thank you for purchasing this network camera! Please read this manual carefully before operating the unit and retain it for future reference. Should you require any technical assistance, please contact Speco Technologies Technical Support. Applications... -
Page 7: Web Access And Login
IP Camera User Manual 2. Web Access and Login The IP camera settings can be accessed via a web browser through the LAN. 2.1 LAN Access through IP Scanner Network connection: ① Make sure that the camera and the PC are connected on the same local network. The camera is set to DHCP by default and will be assigned an IP address by the DHCP server. -
Page 8: Live View
IP Camera User Manual 3. Live View The window below will be shown after logging in. The following table describes the buttons on the live view interface. Function Button Description Stream Dropdown menu Choose which stream to view Video Size Fixed Scales the video to fit in the browser window Video Size... -
Page 9: Camera Configuration
Navigate to the directory where the file is located and select it. Click on “Upgrade” at the bottom of the page to start the firmware update. Make sure to not close the browser window until the update has completed. Firmware files can be downloaded on the Speco website. 4.1.2 System Restart... -
Page 10: Factory Default
IP Camera User Manual 4.1.3 Factory Default If the device needs to be factory reset for any reason, it can be done here. Be aware that this procedure will erase all settings that were changed and saved in the device and restore them to a factory default state. If restoring settings after a factory reset is desired, make sure to back up the settings using the “Export”... -
Page 11: Date / Time
IP Camera User Manual 4.1.5 Date / Time Time Zone Select the appropriate time zone of the location of the device. The system time will update automatically if the device is connected to the internet. Setup Time If the device is not updating the time automatically for some reason, the time can be adjusted manually. Click the checkbox and change the time accordingly. -
Page 12: System Information
IP Camera User Manual 4.1.7 System Information System Information Provides information such as the current firmware version of the device and the model number. The device nickname can also be set up here. HTTP API Authentication and WSSE Authentication are used for 3rd party integration purposes and can remain disabled unless specifically needed. -
Page 13: Basic Setup
IP Camera User Manual 4.2 Basic Setup Basic Setup includes setup for video, audio, and image settings. 4.2.1 Video Setup Resolution, frame rate, etc. can be adjusted in this section. Each setting can be adjusted per stream. There are 3 streams in total – one main stream and two sub streams. -
Page 14: Image Setup
IP Camera User Manual 4.2.2 Image Setup Image settings such as brightness, contrast, white balance, etc can be set up here. - 2MP (O2iBD3 /O2iB68 / O2iB68M/ O2iD8 /O2iD8M /O2B6M /O2iB50M /O2D6M /O2iD9 /O2iB9) Privacy Mask: There are 8 zones that can be applied. Right click within the image window and choose which zones to apply under “Show”. Once the zones are enabled, they can be moved around within the image and resized. - Page 15 IP Camera User Manual - 2MP-F Brightness: Adjusts the brightness of the image. If set too high, it can have a white-out effect on the image. Contrast: Adjusts the contrast of the image which is the difference between black and white (color differentiation). If set too high, bright scenes may look too bright.
- Page 16 FIT: FIT stands for Flexible Intensifier® Technology. Using Speco’s low-light technology called Intensifier, the camera stays in color even in low light, to produce a quality color image. As light level drops even further, the camera will adjust itself automatically to provide the mode that will produce the best image according to the scene.
-
Page 17: Display
IP Camera User Manual 4.2.3 Display Display Enables an on-screen display on the video stream. Position: Static places the OSD on a predefined area in the image. Variable allows for a user-specified location. Size: Size of the font in the OSD. Content Input: User-specified text. -
Page 18: Network Setup
The DNS server addresses can be set up here. This does not have to be set up when using DHCP. 4.3.3 DDNS Client The device can be connected to Speco’s DDNS server so that it can have a host name. -
Page 19: Ntp
IP Camera User Manual Click “Enable” to enable DDNS mode. Enter a hostname for the device. The default name that’s provided has the last 6 digits of the Mac address as part of the name. If the name is found to be unique, it will be registered successfully on the DDNS server. 4.3.4 NTP The device can configure the date and time automatically via an NTP (network time protocol) server if it is connected to the internet. -
Page 20: Smtp
RTSP stands for Real Time Streaming Protocol and is used by various clients to stream the video from the device. Examples of clients are Speco’s NVRs and SecureGuard® VMS. Other than changing the RTSP port (default is 554), the other options are advanced and do... -
Page 21: Snmp
IP Camera User Manual 4.3.8 SNMP To get camera status, parameters and alarm information and remotely manage the camera, the SNMP function can be used. Before using SNMP, please install an SNMP management tool and set the parameters of SNMP, such as SNMP port, trap address. 1. -
Page 22: Ip Filter
IP Camera User Manual 4.3.10 IP Filter IP filtering can be used to provide access or deny access to a specific set of IP addresses. 1. Select Enable and the select either “All Accept” or “All Drop”. 2. If All Drops is selected, then nobody can access the device except for a specified list of IP addresses and vice versa for All Accept. 3. -
Page 23: Event Setup
IP Camera User Manual 4.4 Event Setup 4.4.1 Motion Detection Motion detection zone and sensitivity can be set up in this section. 1. Set the sensitivity of motion detection for the zone. Higher sensitivity means that motion alarms will be triggered more easily. 2. -
Page 24: Alarm In Mode
IP Camera User Manual 4.4.3 Alarm in Mode For devices with a sensor input, choose between Normally open or Normally closed. 4.4.4 Notification This section is used to control how notifications are delivered for motion and tampering alarm events. Email: Choose the event type. Interval time defines how often the email is sent out. Images of the event can be attached to the email if enabled. -
Page 25: User Admin
IP Camera User Manual 4.5 User Admin 4.5.1 Password Change Change the password of the admin account. 4.5.2 User Account Add or modify user accounts here. Enter the user ID of the account to be created or modified and enter the new password. To delete an account, click on the account to be deleted and click “Delete”. -
Page 26: Appendix
Appendix Appendix 1 Troubleshooting IP Scanner does not show any device. Make sure that the PC that’s running IP Scanner is on the same local network as the devices. Internet Explorer cannot download ActiveX control IE browser may be set up to block ActiveX. Follow the steps below. 1.
