- Page 1 Flexible Intensifier® Technology Bullet IP Camera QUICK INSTALLATION GUIDE O3FDP9 Please read this guide carefully before installation and operation of the product.
- Page 2 Thank you for purchasing this product. This guide is designed to be a reference tool for the product. Please read it carefully before operating the product and retain it for future reference. Should you require any technical assistance, please contact Speco Technologies Technical Support. CAUTION...
-
Page 3: Limitation Of Liability
PRECAUTIONS Please read the manual carefully before the installation in order to set up the camera correctly and to obtain the best picture quality. Installation and services should only be carried out by an authorized personnel according to local safety regulations. -
Page 4: Product Overview
Image Setting Auto Exposure Privacy Mask DSS, Corridor-view (in H.264), Mirror / V-Flip, etc. Backlight Shutter Speed 1/4 ~ 1/2000 Noise Reduction 2D / 3DNR Dynamic IP SPECO DDNS (Free of Charge) Password Protection Network Security User Access Log HTTPS Encryption... -
Page 5: Name And Function Of Each Part
Supported Protocol HTTP, HTTPS, DNS, RTSP, RTP, TCP, UDP, ICMP, DHCP Intelligent Video Motion detection 12 x 12 blocks System Alarm Trigger Motion Detection, Tampering Alarm Integration Firmware Upgrade Remote Upgrade via Network 1 x Factory Reset Button Memory Slot Save to Micro SD card with event mode and continuous mode Power Source DC 12V / 1.5A, POE (Power Over Ethernet) : 802.3af... -
Page 6: Name And Function
2.2 Name and Function ITEM DESCRIPTION DC12V Caution : If O3FDP9 is powered by PoE, do not Power Connector plug in DC Jack with active DC power into DC power connector. Network and POE (Power over Ethernet) and LAN cable... -
Page 7: 3-Axis Adjustment
Wall Plastic anchor Tapping screw (Ø4 x 30) x 3 Lock Dome Cover Ass'y Camera Ass'y Drilling Template ① Select the place to install the camera. Place the Drilling template on the ceiling and drill the holes. ② Fix the plastic anchors in the holes. ③... - Page 8 3.3 INSTALLATION EXAMPLE 3.3.1 Installation Example LAN Switch LAN Switch Router Internet Remote Access Remote Access Local Access l Access E-Mail / FTP 3.3.2 Connecting to the Network Open up IP Scanner. IP Scanner can search for the device on the local network. IP Scanner can search for the device on the local network.
-
Page 9: Dimensions (Mm)
3.3.3 Accessing the Camera or video server’s Homepage 1) Open the browser and input network camera address in the address bar or double click the device in IP Scanner. Input your IP address here 2) Please input your user name and password when prompted. 3) Default user name is admin and password is 1234.
