EL-8500VA
9 x 2 Multi-format Presentation Scaler with HDBT
OPERATION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EL-8500VA and is the answer not in the manual?

Questions and answers

Related Manuals for CYP EL-8500VA

Summary of Contents for CYP EL-8500VA

  • Page 1 EL-8500VA 9 x 2 Multi-format Presentation Scaler with HDBT OPERATION MANUAL...
  • Page 3 DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. CYP (UK) Ltd assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. CYP (UK) Ltd assumes no responsibility for any inaccuracies that may be contained in this document.
  • Page 4 SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.

  • Page 5: Table Of Contents

    CONTENTS 1. Introduction ...........6 2. Applications ...........6 3. Package Contents ........7 4. System Requirements ......7 5. Features ..........8 6. Operation Controls and Functions ..9 6.1 Front Panel ........... 9 6.2 Rear Panel ...........10 6.3 IR Cable Pinouts ........13 6.4 RS-232 Pinout and Defaults ....13 6.5 OSD Menu ..........14 6.6 WebGUI Control ........33 6.7 Telnet Control ..........47...

  • Page 6: Introduction

    1. INTRODUCTION This 9 by 2 multi-format scaling switcher provides HDMI, USB-C, HDBaseT, and VGA inputs which can be freely selected for output at a scaled resolution of the user’s choosing over the mirrored HDMI and HDBaseT outputs. The HDMI and USB-C ports support resolutions up to 4K@60 (4:4:4, 8-bit) while the HDBaseT output supports automatic colour subsampling of 4K50/60(4:4:4) sources to 4K50/60(4:2:0).

  • Page 7: Package Contents

    3. PACKAGE CONTENTS  1× HDMI/HDBaseT/USB-C/VGA to HDMI/HDBaseT Scaler  1× 24V/6.25A DC Power Adapter  1× 3.5mm to IR Blaster Cable  1x 3.5mm to IR Extender cable  1× Shockproof Feet (Set of 4)  1× Operation Manual 4.

  • Page 8: Features

    5. FEATURES  HDMI 2.0 and DVI 1.0 compliant  HDCP 1.x and 2.2 compliant  9 video inputs (1×USB-C, 2×HDBaseT, 4×HDMI, 2×VGA)  2 mirrored video outputs (1×HDMI, 1×HDBaseT)  Supports switching and scaling of all AV inputs for display over the mirrored HDMI and HDBaseT outputs  Supports up to 4K UHD (18Gbps, 4K@50/60Hz 4:4:4, 8-bit) digital video input (HDMI, USB-C) and output (HDMI)

  • Page 9: Operation Controls And Functions

    SELECT SELECT 1080P VOLUME AMPLIFIER LINE OUT EL-8500VA WUXGA POWER LED: This LED will illuminate to indicate the unit is on and receiving power. MENU Button: Press to enter the OSD menu, or to back out from menu items. MINUS (-) Button: Press to move down or adjust selections within OSD menus.

  • Page 10: Rear Panel

    knob controls the HDMI audio output (LPCM 2.0 only). VOL. Rotary Knob & LEDs: Rotating the knob increases or decreases the currently selected audio output’s volume level. The LED bar will change according to the current level. Pressing in on the knob toggles the audio mute function.
  • Page 11 RELAY 1~2 2-pin Terminal Blocks: Connect to devices that can be powered and controlled via a DC 0~24V/5A relay connection such as a curtain, projection screen, or lights. IR IN Port: Connect to an IR Extender to receive local IR control signals and extend them to devices connected to the other end of the HDBaseT connection.
  • Page 12 HDMI INPUT 1~4 Ports: Connect to HDMI source equipment such as media players, game consoles, or set-top boxes. DVI sources are supported with the use of an HDMI to DVI adapter. VGA INPUT 1~2 Ports: Connect to VGA source equipment such as PCs or laptops.

  • Page 13: Ir Cable Pinouts

    6.3 IR Cable Pinouts IR Blaster IR Extender Cable Cable Power Infrared Infrared Power Not Used Ground 6.4 RS-232 Pinout and Defaults Serial Port Default Settings Baud Rate 19200 Data Bits Parity Bits None Stop Bits Flow Control None RS-232 Port 1 (Unit control) RS-232 Port 2 (HDBaseT extension) 4-pin Terminal Block...

  • Page 14: Osd Menu

    6.5 OSD Menu All functions of this unit can be controlled by using the OSD (On Screen Display) which is activated by pressing the MENU button on the front of the unit. Use the + (PLUS), − (MINUS), and ENTER buttons to navigate the OSD menu.
  • Page 15 VIDEO LEVEL LEVEL LEVEL HDMI Out Bypass Output Route USB-C HDBT 1 HDBT 2 HDMI 1 HDMI 2 HDMI 3 HDMI 4 VGA 1 VGA 2 Output Resolution NATIVE HDMI Native HDBT 640x480@60 800x600@60 1024x768@60 1280x768@60 1360x768@60 1280x720@60 1280x800@60 1280x1024@60 1440x900@60 1400x1050@60 1680x1050@60...
  • Page 16 VIDEO LEVEL LEVEL LEVEL Output Resolution 1600x1200@60 (Cont.) 1920x1080@60 1920x1200@60RB 2560x1600@60RB 720x480p 720x576p 1280x720p50 1280x720p60 1920x1080p24 1920x1080p25 1920x1080p30 1920x1080p50 1920x1080p60 3840x2160p24 3840x2160p25 3840x2160p30 3840x2160p50 3840x2160p60 3840x2160p50(420) 3840x2160p60(420) 4096x2160p24 4096x2160p25 4096x2160p30 4096x2160p50...
  • Page 17 VIDEO LEVEL LEVEL LEVEL Output Resolution 4096x2160p60 (Cont.) 4096x2160p50(420) 4096x2160p60(420) Aspect Over Scan Full BEST FIT Pan Scan Letterbox Under 1 Under 2 Follow In Blank Freeze Auto Setting Auto Sync Off Auto Input Auto Switch HDCP Setting ENABLED HDCP On USB-C Disabled ENABLED HDCP On HDBT 1...
  • Page 18 VIDEO LEVEL LEVEL LEVEL HDCP Setting (Cont.) HDCP On HDBT 2 ENABLED Disabled ENABLED HDCP On HDMI 1 Disabled ENABLED HDCP On HDMI 2 Disabled ENABLED HDCP On HDMI 3 Disabled ENABLED HDCP On HDMI 4 Disabled 1) HDMI Out Bypass: Enable or disable the video output bypass mode.
  • Page 19 5) Blank: Enable or disable blanking the video output. Note: Not available when HDMI bypass mode is enabled. 6) Freeze: Enable or disable freezing the video output. Note: Not available when HDMI bypass mode is enabled. 7) Auto Setting: ■ Auto Sync Off: Sets the amount of time to continue outputting sync with the free run colour if there is no live source and no operations have been executed on the unit.
  • Page 20 PICTURE LEVEL LEVEL LEVEL 0~1023 (512) Color Gain R Color Gain G 0~1023 (512) 0~1023 (512) Color Gain B 0~1023 (512) Color Offset R 0~1023 (512) Color Offset G 0~1023 (512) Color Offset B 0~60 (30) Brightness 0~60 (30) Contrast Fine Tune HDMI 0~60 (30) 0~60 (30)
  • Page 21 1) Color Gain R/G/B: Set the red, green, and blue color gain level of the scaled output. 2) Color Offset R/G/B: Set the red, green, and blue color offset level of the scaled output. 3) Brightness/Contrast: Set the overall brightness and contrast of the scaled output image.
  • Page 22 AUDIO LEVEL LEVEL LEVEL HDMI Out Bypass Audio Routing Follow User FOLLOW VIDEO Fixed Analog 1 Fixed Analog 2 Fixed Analog 3 Fixed Analog 4 Fixed Analog 5 Fixed Analog 6 Follow User Setting EMBEDDED Audio On USB-C Analog 1 Follow User Setting Audio On USB-C Analog 2...
  • Page 23 AUDIO LEVEL LEVEL LEVEL Follow User Setting Audio On HDMI 3 [Same options as for (Cont.) USB-C] Audio On HDMI 4 [Same options as for USB-C] ANALOG 1 Audio On VGA 1 Analog 2 Analog 3 Analog 4 Analog 5 Analog 6 Audio On VGA 2 Analog 1...
  • Page 24 AUDIO LEVEL LEVEL LEVEL Analog Out Mute Speaker Out Mute 1) HDMI Out Bypass: Enable or disable HDMI audio bypass mode. When enabled, all audio will automatically behave as if in “Follow Video” mode and bitstream audio can be supported. Note: This bypass setting affects audio only.
  • Page 25 5) Mic Gain: Sets the microphone input’s volume level when the microphone is an active audio source (mixed or unmixed). 6) HDMI/Analog/Speaker Out Volume: Set the volume level for each audio output type. Note: LPCM 2.0 sources only. Not active when HDMI audio Out Bypass is enabled.
  • Page 26 LEVEL LEVEL H Position 0~100 (50) V Position 0~100 (50) Transparency 1~8 (1) OSD Menu Timeout Display INFO 1) H/V Position: Controls the position of the OSD menu. 2) Transparency: Set the transparency level of the OSD menu’s background. The available range is from Level 0 (fully opaque) to Level 8 (fully transparent).
  • Page 27 4) Display: Set the behaviour of the OSD informational display. Selecting “Info” will show the information display for a short time after a source or display change. Selecting “Off” will disable the info display. Selecting “On” will always show the info display.
  • Page 28 ETHERNET LEVEL LEVEL LEVEL IP Mode STATIC DHCP Static IP Setting 0~255 (192) Static IP 0~255 (168) 0~255 (1) 0~255 (50) 0~255 (255) Mask 0~255 (255) 0~255 (0) 0~255 (0) 0~255 (192) Gate 0~255 (168) 0~255 (1) 0~255 (254) [Current IP address] [Unit’s MAC address] 1) IP Mode: Set the unit to Static or DHCP mode.
  • Page 29 EDID LEVEL LEVEL EDID On USB-C DEFAULT FHD 2CH Default FHD MCh Default UHD 2Ch Default UHD MCh Default UHD+ 2Ch Default UHD+ MCh Default VGA User 1 User 2 Sink HDMI Sink HDBT EDID On HDBT 1 [Same options as for USB-C] EDID On HDBT 2 [Same options as for USB-C] EDID On HDMI 1...
  • Page 30 EDID LEVEL LEVEL EDID On VGA 1(Cont.) User 1 User 2 Sink HDMI Sink HDBT EDID On VGA 2 [Same options as for VGA 1] 1) EDID Selection: Select the EDID to use with each input. Note: In most cases, assigning a new EDID to an input will cause the affected input to briefly blink out while the source adapts to the new information.
  • Page 31 SYSTEM LEVEL LEVEL Relay 1 Relay 2 RS-232 HDBT OUT HDBT In 1 HDBT In 2 HDBT OUT HDBT In 1 HDBT In 2 1) Relay 1~2: Manually open or close Relay 1 and Relay 2. Selecting “ON” closes the relay, selecting “OFF” opens it. 2) RS-232: Set which HDBaseT port the local RS-232 port should route across.
  • Page 32 FACTORY LEVEL LEVEL Reset All Execute FW Update From USB Execute 1) Reset All: Selecting “Execute” will reset all of the unit’s settings back to their factory defaults. 2) FW Update From USB: Provides a way to update the unit’s firmware. Insert a USB thumb drive, with a valid firmware file (*.bin format) in the root directory, into the unit’s USB service port then select this option.

  • Page 33: Webgui Control

    6.6 WebGUI Control Device Discovery Please obtain the “Device Discovery” software from your authorised dealer and save it in a directory where you can easily find it. Connect the unit and your PC/Laptop to the same active network and execute the “Device Discovery” software. Click on “Find Devices on Network”...
  • Page 34 WebGUI Overview After connecting to the WebGUI’s address in a web browser, the login screen will appear. Please enter the appropriate user name and password then click “Submit” to log in. Note: The default user name and password is “admin”. On the left side of the browser, you will see the following menu tabs where all primary functions of the unit are controllable via the built-in WebGUI.
  • Page 35 6.6.1 Video Tab This page provides video routing settings, I/O renaming options and control over the video output signal’s format and behaviour. To begin assigning a new video route, please click an output button and then click on the button of the preferred input port. As you select each button they will change their colour to orange.
  • Page 36 3) Additional Settings: ■ HDMI Out Bypass: Enable or disable the video output bypass mode. When bypass is enabled, HDR video and bitstream audio can be supported, however, it will disable the unit’s scaling and video adjustment functions. Note: This setting affects both the HDMI and HDBaseT outputs. This setting does not enable audio bypass.
  • Page 37 6.6.2 HDCP Tab Provides control over the HDCP behaviour of each input. To enable or disable HDCP support on one or more inputs, select the preferred inputs on the left, and then select the HDCP mode on the right. The change will occur immediately.
  • Page 38 6.6.3 Picture Tab This tab provides controls over the scaled video output’s colour, brightness, contrast. When a digital source is selected hue, saturation, sharpness and noise reduction are also controllable. When a VGA input is selected, the available controls will change and auto set, H/V position, clock and phase will become adjustable instead.
  • Page 39 2) Picture Settings (Digital Sources): ■ Hue: Provides control over the hue shift of the scaled output image. ■ Saturation: Provides control over the colour saturation level of the scaled output image. ■ Sharpness: Provides control over the amount of sharpness processing to apply to the scaled output image.
  • Page 40 6.6.4 Audio Tab This tab provides control over how audio is routed within the unit as well as control over audio mixing, individual output volume and the microphone’s gain level. 1) Audio Settings: ■ HDMI Volume & Mute: Set the volume level, or mute the audio, for the HDMI and HDBaseT audio outputs.
  • Page 41 ■ MIC Gain: Sets the microphone input’s volume level when the microphone is an active audio source (mixed or unmixed). ■ Output Mixer: Set the microphone mixing mode of the unit – Mixer Off: Disable the audio mixer. – Mixer On: Enable the audio mixer. Audio from the current source and the microphone will be mixed together.
  • Page 42 6.6.5 OSD Tab This tab provides controls over the appearance of the unit’s informational OSD and OSD menu. 1) H/V Position: Controls the position of the OSD menu. 2) Transparency: Controls the transparency level of the OSD menu’s background. The available range is from Level 0 (fully opaque) to Level 8 (fully transparent).
  • Page 43 1) User EDID Settings: ■ Save Name: To change the name of a User EDID, type the new name in the space provided, then click on the “Save Name” button. ■ Download: To save an existing User EDID to your local PC please press the “Download”...
  • Page 44 2) Sink EDID Download: To save the EDID from one of the connected displays to your local PC, select the appropriate sink from the dropdown list then press the “Download” button. Depending on your browser settings you will either be asked where to save the downloaded file, or the file will be transferred directly to the default download location on your PC.
  • Page 45 6.6.7 System Tab Click on the “System” tab to make changes to various system settings. From this tab, you can change the WebGUI login username and password as well as configure the RS-232/IR HDBaseT routing. Finally, this tab provides buttons to reset the unit to factory defaults and to update the firmware.
  • Page 46 3) Control Route Setting: These settings control the unit’s 2 relay ports as well as defining the HDBaseT routing to use for the RS-232 and IR ports on the unit. ■ Relay 1 & 2: Manually open or close Relay 1 and Relay 2. Selecting “ON”...

  • Page 47: Telnet Control

    6.7 Telnet Control Before attempting to use Telnet control, please ensure that both the unit and the PC are connected to the same active networks. To Access the Command Line Interface (CLI) Windows 7 Click Start, type “cmd” in the search field, and press Enter.

  • Page 48: Serial And Telnet Commands

    6.8 Serial and Telnet Commands COMMAND Description and Parameters HELP  Show the full command list. ?  Show the full command list. HELP N1  Show details about the specified command. N1 = {Command name} GET MODEL NAME  Show the unit’s model name.
  • Page 49 COMMAND Description and Parameters SET IP MODE N1  Set the IP address assignment mode. Available values for N1: [Static IP Mode] [DHCP Mode] GET IP MODE  Show the current IP address assignment mode. GET IPADDR  Show the unit’s current IP address. GET MAC ADDR ...
  • Page 50 COMMAND Description and Parameters GET STATIC GATEWAY  Show the unit’s current gateway address. SET WEBGUI USERNAME N1  Set the WebGUI login username. N1 = {Name} [16 characters max] GET WEBGUI USERNAME  Show the current WebGUI login username. SET WEBGUI PASSWORD N1 ...
  • Page 51 COMMAND Description and Parameters SET OUT A ROUTE N1  Route the specified input to both outputs. Available values for N1: [USB-C input] [HDBaseT input 1] [HDBaseT input 2] [HDMI input 1] [HDMI input 2] [HDMI input 3] [HDMI input 4] [VGA input 1] [VGA input 2] GET OUT A ROUTE ...
  • Page 52 COMMAND Description and Parameters GET IN N1 TIMING  Show the index number of the current resolution detected on the specified input. Available values for N1: [USB-C input] [HDBaseT input 1] [HDBaseT input 2] [HDMI input 1] [HDMI input 2] [HDMI input 3] [HDMI input 4] [VGA input 1]...
  • Page 53 COMMAND Description and Parameters SET OUT A TIMING N1  Set the output resolution to use for both outputs. Available values for N1: [Native HDMI] [1920x1080p24] [Native HDBaseT] [1920x1080p25] [640x480@60] [1920x1080p30] [800x600@60] [1920x1080p50] [1024x768@60] [1920x1080p60] [1280x768@60] [3840x2160p24] [1360x768@60] [3840x2160p25] [1280x720@60] [3840x2160p30] [1280x800@60] [3840x2160p50]...
  • Page 54 COMMAND Description and Parameters GET OUT A TIMING STRING  Show the description string of the current resolution used by both outputs. GET IN SOURCE LIST  List the port type of all inputs on the unit. GET OUT TIMING LIST  List all available output resolutions with their local index numbers.
  • Page 55 COMMAND Description and Parameters SET OUT A HUE N1  Set the scaled output’s hue value. N1 = 0~60 [Hue value] GET OUT A HUE  Show the hue value when the output is scaled. SET OUT A SHARPNESS N1  Set the scaled output’s sharpness level.
  • Page 56 COMMAND Description and Parameters GET OUT A NR  Show the current amount of noise reduction applied when the output is scaled. SET OUT A ASPECT RATIO N1  Set the aspect ratio of the video shown when the output is scaled. Available values for N1: [Overscan] [Full]...
  • Page 57 COMMAND Description and Parameters GET OUT A AUTO SYNC OFF  Show the current setting for Auto Sync Off SET OUT A R GAIN N1  Set the scaled output’s red gain level. N1 = 0~1023 [Red gain level] GET OUT A R GAIN  Show the scaled output’s current red gain level.
  • Page 58 COMMAND Description and Parameters SET OUT A G OFFSET N1  Set the scaled output’s green offset. N1 = 0~1023 [Green offset] GET OUT A G OFFSET  Show the scaled output’s current green offset. SET OUT A B OFFSET N1  Set the scaled output’s blue offset.
  • Page 59 COMMAND Description and Parameters SET IN N1 CLOCK N2  Set the PC clock value for the specified input (VGA inputs only). Available values for N1: [VGA input 1] [VGA input 2] N2 = 0~250 [PC clock] GET IN N1 CLOCK  Show the current PC clock value for the specified input (VGA inputs only).
  • Page 60 COMMAND Description and Parameters SET IN N1 VPOSITION N2  Set the PC vertical position for the specified input (VGA inputs only). Available values for N1: [VGA input 1] [VGA input 2] N2 = 0~250 [Vertical position] GET IN N1 VPOSITION  Show the current PC vertical position for the specified input (VGA inputs only).
  • Page 61 COMMAND Description and Parameters SET VGA IN AUTO  Activate the auto-detection of the current VGA source’s parameters. SET OUT A BLANK N1  Enable or disable blanking the video output Available values for N1: [Video output normal] [Video output blanked] GET OUT A BLANK ...
  • Page 62 COMMAND Description and Parameters SET OUT A OSD TIMER N1  Set the OSD menu’s timeout value. Available values for N1: [Timeout disabled] [5 seconds] [10 seconds] [15 seconds] [20 seconds] [25 seconds] [30 seconds] [35 seconds] [40 seconds] [45 seconds] [50 seconds] [55 seconds] [60 seconds]...
  • Page 63 COMMAND Description and Parameters GET OUT A OSD HPOSITION  Show the current vertical position of the OSD menu. SET OUT A OSD TRANSPARENCY LEVEL N1  Set the transparency level of the OSD menu. N1 = 1~8 [Transparency level] GET OUT A OSD TRANSPARENCY LEVEL ...
  • Page 64 COMMAND Description and Parameters GET AUDIO OUT N1 MUTE  Show the current mute state of the specified output. Available values for N1: [HDMI audio output] [HDBaseT audio output] [Standard analogue audio output] [Amplified analogue audio output] SET AUDIO OUT ALL MUTE N1  Enable or disable muting on all audio outputs.
  • Page 65 COMMAND Description and Parameters SET AUDIO OUT N1 VOLUME N2  Set the volume level of the specified output’s audio. Available values for N1: [HDMI audio output] [HDBaseT audio output] [Standard analogue audio output] [Amplified analogue audio output] N2 = 0~100 [Volume level] Note: The HDMI and HDBaseT outputs share their settings.
  • Page 66 COMMAND Description and Parameters GET AUDIO OUT MIXER  Show the current state of the unit’s audio mixer. SET HDMI OUT AUDIO BYPASS N1  Enable or disable the HDMI/HDBaseT audio output bypass mode. Available values for N1: [Audio bypass disabled] [Audio bypass enabled] GET HDMI OUT AUDIO BYPASS ...
  • Page 67 COMMAND Description and Parameters Available values for N2: [Analogue audio input 1] [Analogue audio input 2] [Analogue audio input 3] [Analogue audio input 4] [Analogue audio input 5] [Analogue audio input 6] [Embedded audio] GET VIDEO IN N1 AUDIO ROUTE  Show the audio source currently assigned to the specified video input to be used when Follow User Mode is enabled.
  • Page 68 COMMAND Description and Parameters SET IN N1 EDID N2  Set the EDID to use on the specified input. Available values for N1: [USB-C input] [HDBaseT input 1] [HDBaseT input 2] [HDMI input 1] [HDMI input 2] [HDMI input 3] [HDMI input 4] [VGA input 1] [VGA input 2]...
  • Page 69 COMMAND Description and Parameters GET IN N1 EDID  Show the EDID currently being used on the specified input. Available values for N1: [USB-C input] [HDBaseT input 1] [HDBaseT input 2] [HDMI input 1] [HDMI input 2] [HDMI input 3] [HDMI input 4] [VGA input 1] [VGA input 2]...
  • Page 70 COMMAND Description and Parameters GET IN N1 HDCP MODE  Show the current HDCP behaviour used by the specified input. Available values for N1: [USB-C input] [HDBaseT input 1] [HDBaseT input 2] [HDMI input 1] [HDMI input 2] [HDMI input 3] [HDMI input 4] GET IN N1 HDCP STATUS ...
  • Page 71 COMMAND Description and Parameters GET OUT N1 HDCP STATUS  Show the current HDCP status of the specified output. Available values for N1: [HDMI output] [HDBaseT output] Possible response values: [No HDCP] [HDCP 1.x] [HDCP 2.2] [HDCP 1.x failed] [HDCP 2.x failed] SET RELAY N1 N2 ...
  • Page 72 COMMAND Description and Parameters GET UART2  Show the current HDBaseT routing path for the unit’s RS-232 port. SET IR N1  Set the HDBaseT routing path for the unit’s IR ports. Available values for N1: [HDBaseT Out] [HDBaseT Input 1] [HDBaseT Input 2] GET IR ...

  • Page 73: Connection Diagram

    7. CONNECTION DIAGRAM Display Display Source Source Screen Volume Screen Volume Down Down 1.5m CD Player Powered 60° 60° Speakers Microphone IR Input Input IR Output Router RS-232 Power Supply MIC IN ANALOG AUDIO AUDIO OUT L+ L- R+ R- RELAY IR IN IR OUT...

  • Page 74: Specifications

    8. SPECIFICATIONS 8.1 Technical Specifications HDMI Bandwidth 18Gbps USB-C Bandwidth 21.6Gbps VGA Bandwidth 165MHz HDBaseT Bandwidth 10.2Gbps Input Ports 1×USB (Type-C) 2×HDBaseT (RJ-45) 4×HDMI (Type-A) 2×VGA (HD-15) 6×Stereo Audio (3.5mm) 1×Microphone (6.35mm) Output Ports 1×HDMI (Type-A) 1×HDBaseT (RJ-45) 1×Stereo Audio (5-pin Terminal Block) 1×Stereo Audio (2×2-pin Term.
  • Page 75 ESD Protection (HBM) ±8kV (Air Discharge) ±4kV (Contact Discharge) Dimensions (W×H×D) 432mm×43mm×164mm [Case Only] 432mm×43mm×174mm [All Inclusive] Weight 2547g Chassis Material Metal (Steel) Chassis Colour Black Operating Temperature 0 ˚C – 40 ˚C/32 ˚F – 104 ˚F Storage Temperature −20 ˚C – 60˚C/−4 ˚F – 140 ˚F Relative Humidity 20 –...

  • Page 76: Video Specifications

    8.2 Video Specifications 8.2.1 Bypass Output Bypass Input Supported Resolutions Output (Hz) HDMI HDBT USBC HDMI HDBT 720×400p@70/85       640×480p@60/72/75/85       720×480i@60 ×      720×480p@60  ...
  • Page 77 Bypass Input Supported Resolutions Output (Hz) HDMI HDBT USBC HDMI HDBT 1680×1050p@60       1920×1080i@50/60       1920×1080p@24/25/30       1920×1080p@50/60       1920×1200p@60RB ...
  • Page 78 8.2.2 Scaled Output Scaled Output Supported Resolutions (Hz) HDMI HDBT × × 720×400p@70/85 640×480p@60/72/75/85 × 720×480i@60 × 720×480p@60   720×576i@50 × × 720×576p@50   800×600p@56/60/72/75/85 848×480p@60 × × 1024×768p@60/70/75/85 1152×864p@75 × × 1280×720p@50/60   1280×768p@60/75/85 1280×800p@60/75/85 1280×960p@60/85 ×...
  • Page 79 Scaled Output Supported Resolutions (Hz) HDMI HDBT 1920×1080p@24/25/30   1920×1080p@50/60   1920×1200p@60RB   2560×1440p@60RB × × 2560×1600p@60RB   2048×1080p@24/25/30 × × 2048×1080p@50/60 × × 3840×2160p@24/25/30   3840×2160p@50/60 (4:2:0)   3840×2160p@24, HDR10 × × 3840×2160p@50/60 (4:2:0), HDR10 ×...

  • Page 80: Audio Specifications

    8.3 Audio Specifications 8.3.1 Digital Audio HDMI Input / Output LPCM Max Channels 2 Channels (8 Channels in bypass) Sampling Rate (kHz) 32, 44.1, 48, 88.2, 96, 176.4, 192 Bitstream (Bypass Only) Supported Formats Standard & High-Definition HDBaseT Input / Output LPCM Max Channels 2 Channels (8 Channels in bypass)
  • Page 81 8.3.2 Analogue Audio Analogue Input (3.5mm) Max Audio Level 1Vrms Impedance 10kΩ Type Unbalanced Mic Input Max Audio Level 50Vrms Impedance 6.8kΩ Type Unbalanced Analogue Output (5-pin Terminal Block) Max Audio Level 4Vrms THD+N < −84dB@0dBFS 1kHz (A-wt) > 104dB@0dBFS Frequency Response <...

  • Page 82: Cable Specifications

    8.4 Cable Specifications 1080p 4K30 4K60 (4:4:4) (4:4:4) Cable Length 8-bit 12-bit 8-bit 8-bit High Speed HDMI Cable HDMI Input HDMI Output USB-C Cable USB-C Input VGA Cable × VGA Input Ethernet Cable × Cat.5e/6 100m × Cat.6A/7 100m 100m Bandwidth Category Examples: 1080p (FHD Video) - Up to 1080p@60Hz, 12-bit colour...

  • Page 83: Hdbaset Features

    8.5 HDBaseT Features HDBaseT Feature Set Transmitter Video & Audio Extension Supported LAN Extension Supported Send power to Receiver Supported (PoH) Accept power from Receiver Unsupported IR Extension Supported RS-232 Extension Supported USB 2.0 Extension Unsupported HDBaseT Feature Set Receiver Video &...

  • Page 84: Acronyms

    9. ACRONYMS ACRONYM COMPLETE TERM Analogue-to-Digital Converter ASCII American Standard Code for Information Interchange Cat.5e Enhanced Category 5 cable Cat.6 Category 6 cable Cat.6A Augmented Category 6 cable Cat.7 Category 7 cable Command-Line Interface Digital-to-Analogue Converter Decibel DHCP Dynamic Host Configuration Protocol Digital Visual Interface EDID Extended Display Identification Data...
  • Page 85 ACRONYM COMPLETE TERM Liquid-Crystal Display Light-Emitting Diode LPCM Linear Pulse-Code Modulation Media Access Control Megahertz On-Screen Display Powered Device Power over HDBaseT Power Sourcing Equipment Signal-to-Noise Ratio Transmission Control Protocol THD+N Total Harmonic Distortion plus Noise TMDS Transition-Minimised Differential Signaling Ultra-High-Definition (10.2Gbps) Ultra-High-Definition Plus (18Gbps) UHDTV...
  • Page 88 CYP (UK) Ltd., Unit 7, Shepperton Business Park, Govett Avenue, Shepperton, Middlesex, TW17 8BA Tel: +44 (0) 20 3137 9180 | Fax: +44 (0) 20 3137 6279 Email: sales@cypeurope.com www.cypeurope.com v1.00...
