Removing the Device
To remove the device from a DIN rail, do the following:
1.
2.
3.
2.3.2

Mounting the Device to a Panel

For panel installations, the RUGGEDCOM RS930W can be equipped with panel
adapters on the top and bottom of the chassis. The adapters allow the device to be
attached to a panel using screws.
To mount the device to a panel, do the following:
1.
RUGGEDCOM RS930W
Installation Manual, 02/2020, C79000-G8976-1035-07
Insert a flathead screwdriver into the slot of the sliding release and move it
down.
1
DIN Rail
1
DIN Rail Adapter
2
Figure 2.2 Removing the Device from a DIN Rail
Swing the bottom of the device away from the DIN rail.
Lift the device off the DIN rail.
Prepare mounting holes in the panel where the device is to be installed.
2.3.2 Mounting the Device to a Panel
2
Installing the Device
3
1
2
1
