Long-Reach EoVDSL Performance Characteristics
On No. 24 AWG Polyethylene Insulated Cable (PIC) twisted-pair wiring, the following
performance is typical with Long-Reach EoVDSL:
RUGGEDCOM RS930W
Installation Manual, 02/2020, C79000-G8976-1035-07
Distance
0.7 km (2297 ft)
0.9 km (2953 ft)
1.0 km (3280 ft)
1.3 km (4265 ft)
1.7 km (5577 ft)
2.0 km (6562 ft)
2.5 km (8202 ft)
Distance (km)
0.50
1.00
1.50
2.00
2.50
3.20
4.00
4.60
5.00
Distance (ft) Downstream (Mas-
ter to Slave) (Mbps)
1600
3300
4900
6600
8200
10500
13100
15100
16400
Communication Ports
4.4.3 EoVDSL Performance
Downstream/Upstream (Mbps)
25
20
15
10
5
2.5
1.2
Upstream (Slave
to Master) (Mbps)
40
25
20
15
10
5
2.1
1.2
0.48
20
5
0.54
0.54
0.54
0.54
0.54
0.54
0.18
