Figure 1.1
POWER LED
ALARM LED
Console Port
Communication Ports
Failsafe Alarm Relay
Power Supply Terminal Blocks
RUGGEDCOM RS930W
Installation Manual, 02/2020, C79000-G8976-1035-07
POWER LED
ALARM LED
EoVDSL Port
Copper (10/100Base-TX) Ethernet Ports
Wireless Ethernet Ports
RS232 Console Port (Serial)
Failsafe Alarm Relay
Chassis Ground Connection
Power Supply Terminal Block
RUGGEDCOM RS930W
5
6
7
5
Illuminates green when power is supplied to the device.
Illuminates red when an alarm condition exists.
The serial console port is for interfacing directly with the device and
accessing initial management functions. For information about con-
necting to the device via the serial console port, refer to
ing to the Device (Page
19)".
Communication ports in general receive and transmit data, as well
as provide access to the RUGGEDCOM RUGGEDCOM RS930W Web
interface. For more information about the various ports available,
refer to
"Communication Ports (Page
Latches to default state when a power disruption or other alarm
condition occurs. For more information, refer to:
•
"Connecting the Failsafe Alarm Relay (Page 12)"
•
"Failsafe Alarm Relay Specifications (Page 32)"
Pluggable terminal blocks for connecting one or more power
sources. For more information, refer to
13)"
and
"Power Supply Specifications (Page
Introduction
1.2 Description
8
9
"Connect-
21)".
"Connecting Power (Page
31)".
