Summary of Contents for Coemar REFLECTION LEDKO VariWhite 2 Series

  • Page 1 VariWhite Series 2...
  • Page 2 VariWhite Series 2 Serial Number: ....................................... Purchase date: ....................................... Dealer: ....................................... Address: ....................................... Suburb: ....................................... Country: ....................................... Phone / Fax: ....................................... Please note in the space provided above the relative service information of the model and the re- tailer from whom you purchased your LEDko VariWhite Series 2: this information will assist us in providing spare parts, repairs or in answering any technical enquiries with the utmost speed and accuracy.

  • Page 3: Table Of Contents

    Index 1. Packaging and transportation .......................Pag. 5 1.1 Packaging ............................Pag. 5 1.2 Transportation ...........................Pag. 5 2. General information ........................... Pag. 5 2.1 Safety informations ......................... Pag. 5 2.2 Warranty conditions ........................Pag. 6 2.3 EC norms ............................Pag. 6 3. Product specifications ........................Pag. 7 3.1 Technical characteristics .........................Pag.
  • Page 4 11. Maintenance ............................. Pag. 27 11.1 Firmware update .......................... Pag. 27 11.2 Periodic cleaning ......................... Pag. 27 11.3 Periodic controls .......................... Pag. 27 11.4 Fuses ...............................Pag. 27 12. F.A.Q. and answers ......................... Pag. 28...

  • Page 5: Packaging And Transportation

    Congratulations on having purchased a Coemar product. You have assured yourself of a fixture of the highest quality, both in componentry and in the technology used. We renew our invitation to you to complete the service information on the previous page, to expedite any request for service information or spares (in case of problems encountered either during, or subsequent to, instal- lation).

  • Page 6: Warranty Conditions

    The level of technology of LEDko VariWhite Series 2 requires the use of specialised personnel for all service applications; refer all work to your autho- rised Coemar service centre. A good earth connection is essential for the proper functioning of the projec- tor.

  • Page 7: Product Specifications

    Product specifications Technical characteristics Power supply 90-264 V, auto-sensing, 50/60 Hz Maximum current 1 A at 230 V - 2.03 A at 115 V Power factor Cosφ = 0.9 Max power consumption 210 W Color temperature All whites from 2.700 to 6.500 K Weight (without optic) 6 Kg - 13.2 lbs Minimum ambient temperature...

  • Page 8: Unit's Main Components

    Unit’s main components Components description A Adjustable yoke Iris (optional) Gobo holder (optional) Lens adjusting handles Yoke locking handle Gel frame locking spring Profile blade H Interchangeable optic...

  • Page 9: Back Panel Description

    Back panel description Display Plus button Menu button Minus button DMX In Enter button DMX Out PowerCon In PowerCon Out...

  • Page 10: Installation

    . Installation Optical installation Remove the frontal cap by loosening the upper and lower screws enough to free the cap itself, set the optic’s flange tilted about 60°. Insert the optic’s flange into the body’s receptacle and turn the optic 60° until it is firmly assembled to the projector body, free to rotate but not free to detach itself from the body.

  • Page 11: Mechanical Installation

    The safety chain must pass through the handles of the unit and then at- tached to the structure. If using steel cables and chains not Coemar’s production, make sure they are suitable to sup- port the weight of the unit according to normative UL/ETL (required: the weight of 6 complete devices for at least one hour).

  • Page 12: Powering Up

    Note: in case of cable replacement, similar cable with comparable thermal resistant qualities must be used exclusively (cable 3 X 1,5 ø external 10 mm, rated 300/500V, tested to 2 KV, op- erating temperature -40°C + 180°C, Coemar cod. CV5311). Connection to mains power LEDko VariWhite Series 2 is equipped with two power connectors, one as input and one as output, which can be used to feed up to 8 (at 230 V) or 4 (at 115 V) fixtures.

  • Page 13: Control Signal Connections

    Warning!! The use of a thermal/magnetic circuit breaker is recommended. Strict adherence to regulatory norms is strongly recommended. LEDko VariWhite Series 2 should not be powered through a dimmer as this may damage the internal switching power supply. Prior to connecting the device to mains power, ensure that the mains characteristics are within the recommended range for the use of LEDko VariWhite Series 2.

  • Page 14: Turning The Projector On

    . Turning the projector on After having followed the preceding steps described, proceed with the power supply and turn on the projector connecting it to the mains power. The software version installed on the internal microprocessors will be shown on the display, suddenly it will show the current DMX address- ing.

  • Page 15: Dmx Chart

    . DMX chart 8.1. DMX Chart 6 channels type of channel function effect decimal percentage control master adjust luminous output proportional 0 - 255 - 100% dimmer intensity from 0 to 100% dimmer fine proportional fine dimmer control 16 bit 0 - 255 - 100% 3200 K...
  • Page 16 step no effect fine white temperature control proportional (from temperature selected to - 126 - 49% the previous step) white temperature step no effect 127 - 128 50% - 50% fine fine white temperature control proportional (from temperature selected 129 - 254 51% - 99% to the following step) step...

  • Page 17: Dmx Chart 2 Or 1 Channels

    8.2. DMX Chart 2, 1 channels type of channel function effect decimal percentage control master adjust luminous output intensity from 0 to proportional 0 - 255 - 100% dimmer 100% 3200 K 0 - 10 2700 K 11 - 16 2800 K 17 - 22 2900 K...

  • Page 18: Display Panel Functions

    Changing the preset settings made by Coemar can vary the functions of the projec- tor so that it will respond differently to the controller; therefore carefully read about the func- tions described here before carrying out any possible selection.

  • Page 19: Main Functions Menu

    Main functions menu Dimmer: dIMM It allows the selection of different dim- mer curves: exponential (default), loga- [Dimmer] rithmic, linear and halogen; Test: Allows to manually set the DMX channels controlled by a DMX console: • Dimmer: sets the luminous intensity; •...
  • Page 20 DMX channels: Allows to choose the number of channels 6 CH with which operate in DMX mode. [DMX] Display functions: Changes the display settings: 2 CH • Reverse: rotates the display of 180°; • Hold Sets or disables the automatic display lock function that occurs after 10 seconds of inactivity;...

  • Page 21: Measure (Meas)

    Measures menu (MEAS) Temperature: tEMP Shows the current temperature values: t.LEd • LED: shows the LED module temper- [Temperature] ature; • Board: shows the electronic board temperature. t.brd Volt: Shows the power supply voltage. uOLT DMX Input: Shows the value of the DMX channels received by the fixture on every channel [Supply Voltage] that the fixture occupies on the line.
  • Page 22 Alarm: ALrM This menu shows the alarm statuses if there is any. [Alarms] LED: Shows the percentage value of the LED status. Frequency: Shows the operating frequency of the LED (611 Hz as default). [LED Status] Fan speed: Shows the voltage in which the fan is operating.

  • Page 23: Electronic Alignment Of The Leds

    The display panel of LEDko VariWhite Series 2 allows the electronic alignment of the LEDs, this procedure is performed by Coemar at the time of testing, this procedure may be useful for special effects or in case of replacement of internal components (PCBs, LEDs, etc...).

  • Page 24: Special Functions Of The Fixture

    If a malfunction occurs, LEDko VariWhite Series 2 has a self-diagnostic system that will show the error message on the display. The following table will explain in detail the most common er- rors. If, despite of suggested intervention, the problem persists, call the Coemar Service Center. Error code...

  • Page 25: Accessories And Spare Parts

    . Accessories and spare parts LEDko VariWhite Series 2 is a very versatile fixture, optional accessories for its customization are available under request: Accessory name Code Front barrel for lens tube with burnished blades BC10011A200 Profile 5°, lens tube BC10011A041 Profile 10°, lens tube BC10011A042 Profile 14°, lens tube...
  • Page 26 BC10011A044 max. load 20 Kg. All the components of LEDko VariWhite Series 2 are available as spare parts from your Coemar dealer or Service. Accurate description of the fixture, model number and type will assist us in pro- viding for your requirements in an efficient and effective manner.
  • Page 27 . Maintenance 11.1 Firmware update The firmware of LEDko VariWhite Series 2 can be updates through the RDM protocol (ANSI E1.20). Contact Coemar assistance to receive the software and the device updater. 11.2 Periodic cleaning Lenses Even a thin layer of dust can reduce the luminous output and alter the consistency of the beam.
  • Page 28 . F.A.Q. and answers The following list shows common issues that may be simply solved. If issues persist, the unit must be repaired by a qualified personnel or just contact your Coemar service near you. Question Possible solution Projector not powered on: •...
  • Page 29 User notes .......................................................................................................................................................................................................................................................................................................................................................................................................................................................
  • Page 30 Information on disposal of the equipment The equipment at the end of its useful life must be disposed of at an appropriate recycling center for waste electrical and electronic equipment. The treatment and disposal of environmentally friendly, helps prevent potential negative environmental and health and promote the reuse and / or recycling of materials making up the equipment.
  • Page 31 Coemar Lighting s.r.l. Via Carpenedolo 90 46043 Castiglione delle Stiviere, Mantova, Italy phone. +39 0376/1514412 - fax +39 0376/1514380 info@coemar.com Coemar reserves the right to change specifications without prior notice...
