Poe Power Supply Specifications; Failsafe Relay Specifications; Supported Networking Standards - Siemens RUGGEDCOM RSG2100PF Installation Manual

Chapter 5
Technical Specifications
b
(T) denotes time-delay fuse.
c
Power consumption varies based on configuration. 10/100Base-TX ports consume roughly 1 W less than fiber optic ports.
d
The HI power supply is the same power supply for both AC and DC.
Section 5.2

PoE Power Supply Specifications

Power Supply Type
48 VDC
e
(T) denotes time-delay fuse.
Section 5.3

Failsafe Relay Specifications

Rated Switching Current
Maximum Switching Capacity
Section 5.4

Supported Networking Standards

Standard
IEEE 802.3
IEEE 802.3u
IEEE 802.3x
IEEE 802.3z
IEEE 802.3ab
IEEE 802.3ad
IEEE 802.3af
IEEE 802.1D
IEEE 802.1D
IEEE 802.1p
IEEE 802.1Q
30
Input Range
Minimum
37 VDC
Parameter
Max Switching Voltage
10 Mbps Ports 100 Mbps Ports
ü
ü
ü
ü
ü
ü
ü
Maximum
72 VDC
2 A @ 240 VAC, 0.15 A @ 125 VDC, 2 A @ 30 VDC
1000 Mbps Ports
ü
ü ü
ü
ü
ü
ü
ü ü
ü ü
ü ü
ü ü
e
Internal Fuse Rating
2 A(T)
Value (Resistive Load)
240 VAC, 125 VDC
150 W, 500 VA
Description
10BaseT/10BaseFL
100BaseTX/100BaseFX
Flow Control
1000BaseLX
1000BaseTx
Link Aggregation
Power over Ethernet (PoE)
MAC Bridges
Spanning Tree Protocol (STP)
Class of Service (CoS)
VLAN (Virtual LAN) Tagging
PoE Power Supply Specifications
RUGGEDCOM RSG2100PF
Installation Guide
Maximum Power
Consumption
68 W
