CrimeStopper EZEE Start EZ-45DP Installation Instructions Manual

CrimeStopper EZEE Start EZ-45DP Installation Instructions Manual

Remote engine starting system
Hide thumbs Also See for EZEE Start EZ-45DP:
Table of Contents

Advertisement

Quick Links

EZ-45DP/55DP 1 WAY SYSTEMS
EZ-95FM 2-WAY SYSTEM
DP SERIES (Data port)
CONGRATULATIONS on your choice of a "Cool Start" System by Crimestopper Security Products Inc. This booklet
contains the information necessary for installing your remote starter system. If any questions arise, contact your
installation dealer or Crimestopper Security Products Inc. at the Tech Support number below.
DISCLAIMER:
This installation book is designed for the installer or individual with an existing understanding of automotive electrical
systems, along with the ability to test and connect wires for proper operation. To ease installation, we suggest that you
READ THIS MANUAL before beginning your installation. This book is provided as a GENERAL GUIDELINE and the
information contained herein may differ from your vehicle. Crimestopper Security Products, Inc. and its' vendors shall not
be liable for any accident resulting from the use of this product. This system is designed to be professionally installed into
a vehicle in which all systems and associated components are in perfect working condition.
TECHNICAL SUPPORT: (800) 998-6880
Monday - Friday 8:00am - 4:30pm Pacific Std. Time
Web Site: www.crimestopper.com
E-mail: tech-support@crimestopper.com
CRIMESTOPPER SECURITY PRODUCTS, INC.
1770 S. TAPO STREET, SIMI VALLEY, CA. 93063
REV A 10.19.2005
REMOTE ENGINE STARTING SYSTEM

INSTALLATION INSTRUCTIONS

INTRODUCTION
This device complies with FCC Rules part 15. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) This device must accept any interference that
may be received, including interference that may cause undesired
operation. The manufacturer is not responsible for any radio or TV
interference caused by unauthorized modifications to this equipment.
Such modification could void the user's authority to use the
equipment.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EZEE Start EZ-45DP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CrimeStopper EZEE Start EZ-45DP

Summary of Contents for CrimeStopper EZEE Start EZ-45DP

  • Page 1: Installation Instructions

    READ THIS MANUAL before beginning your installation. This book is provided as a GENERAL GUIDELINE and the information contained herein may differ from your vehicle. Crimestopper Security Products, Inc. and its’ vendors shall not be liable for any accident resulting from the use of this product. This system is designed to be professionally installed into a vehicle in which all systems and associated components are in perfect working condition.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Pre-Installation Considerations……….………...……...…………………………………..……………………………………2 Installation Cautions & Warnings…………….…….…………………………..……………………………….……..…..……3 3 Pin and 5 Pin connector ……...……….……………………………………………………………………….…..………...4 Power Door Lock Wiring …….…….………………...……………………………………………….……………..………...5-8 Wiring Wiring High-Current Connector...……………..………….……….……..…………...…..……...…………….…..9-14 Smart Tachless, Tach Reference, Tach Finder, & Timed Crank Modes…………………..…..…….…...…...….…15-18 Diesel Glow Plug Delay..………………….……………………………...………………..……...…..……….………………19 Options Programming ………..……………………….……………………………...….…………...……………………19-25 Transmitter / Transceiver Programming…………………………………………………..…………………………….…...26 2 Vehicle Operation...…………………………….…………………..……………...…….……..……………...……………27 Troubleshooting “Before You Call”...

  • Page 3: Installation Cautions & Warnings

    INSTALLATION CAUTIONS & WARNINGS **FOR SAFETY REASONS, DO NOT INSTALL in vehicles with MANUAL TRANSMISSIONS.** If accidentally left in gear, a remote started vehicle could become a self-propelled threat to life and property. DO NOT extend the Remote start ignition harness length. Mount the module so that main harness reaches all ignition switch wiring.

  • Page 4: Pin And 5 Pin Connector

    WIRING: 3-Pin (EZ-45DP) and 5-PIN (EZ-55DP/95FM) Connector PIN 1: White: (+12V) Brake Reset Connect the White wire to the side of brake pedal switch that shows +12 volts ONLY when pedal is depressed. This will turn off the remote start if someone attempts to drive the car without the keys or if the Ignition key is not turned on all the way.

  • Page 5: Power Door Lock Wiring

    To install aftermarket systems in these vehicles, an interface module is required that converts the regular lock/unlock pulses into “Data messages” to allow locking & unlocking. Interface modules are sold separately. Crimestopper Door Lock Accessories: CS-6600DLM: Dual-relay plug-in module for Reverse Polarity, Positive, or Aftermarket Motors.
  • Page 6 BASIC DOOR LOCK DIAGRAMS NEGATIVE TRIGGER DOORLOCK WIRING GREEN BLUE BLUE/WHITE RS-1505DP IN4001 RS-1905FM only DIODES LOCK UNLOCK REVERSE POLARITY DOOR LOCK WIRING GREEN BLUE BLUE/WHITE RS-1505DP RS-1905FM only MASTER SWITCH POSITIVE TRIGGER DOORLOCK WIRING GREEN BLUE BLUE/WHITE RS-1505DP RS-1905FM only FACTORY POWER...
  • Page 7 PRIORITY DOOR LOCK DIAGRAMS (For EZ-55DP/EZ-95FM only) NEGATIVE TRIGGER DOOR LOCKS GREEN BLUE BLUE/WHITE DRIVER'S DOOR MOTOR POSITIVE TRIGGER DOOR LOCKS GREEN BLUE BLUE/WHITE DRIVER'S DOOR MOTOR 30 87A FACTORY LOCK RELAYS +12V FUSED UNLOCK WIRE LOCK WIRE LOCK WIRE UNLOCK WIRE FUSED +12V...
  • Page 8 PRIORITY DOOR LOCK DIAGRAMS Cont. (For EZ-55DP/EZ-95FM only) GREEN BLUE BLUE/WHITE DRIVER'S DOOR MOTOR Reverse Polarity: Many Ford/Lincoln/Mercury/Dodge/Chrysler/Plymouth and early 90’s GM Trucks The door lock/unlock motors are controlled directly from the lock and unlock switches in the door. The lock and unlock wires rest at Negative Ground when not in use.

  • Page 9: Wiring Wiring High-Current Connector

    PIN 1: GREEN/RED: (-) AUX#1 OUTPUT (TRUNK POP) or DOME LIGHT ILLUMINATION OUTPUT This output is programmable for two modes of operation. See Programming Option Section. Mode (1) DEFAULTS: Provides a Ground pulse when button #3 (Trunk) on the remote transmitter is pushed to activate a factory electric trunk release or other optional accessory.
  • Page 10 PIN 3: GREEN: (-) START ACTIVATION INPUT, OEM INTERFACE or TURBO TIMER INPUT See descriptions & diagrams below. Mode (1) [Default (-) Neg. Start Activation] This wire allows a host (or parent) alarm’s or keyless entry system to activate a Remote Start by sending a 1-Second Negative signal to the Green input wire to trigger a remote engine start or stop.
  • Page 11 PIN 4: BROWN/WHITE: (-) HORN CHIRP/HONK OUTPUT Connect to the LOW CURRENT Negative Horn Trigger wire usually located near the steering column. If the vehicle horn circuit requires +12V, then a relay is required. RELAY WIRING: Connect the Yellow/White wire to terminal #85, connect relay terminals #86 and #87 to +12V constant power.
  • Page 12 PIN 5:YELLOW/BLACK: FOR ANTI-GRIND/STARTER DISABLE OUTPUT: (Relay not included) MOTOR PIN 6: BLUE/WHITE: (-) STARTER #3 This wire provides a ground output for vehicle that requires a third starter wire to remote start. PIN 7: ORANGE: (-) OEM REARM OUTPUT This wire provides a ground pulse to rearm the vehicles' FACTORY anti-theft system after a timed-out or aborted remote start.
  • Page 13 PIN 1: WHITE/RED: TACHOMETER INPUT When installing the system in Tach mode, this wire must be connected to a valid source of AC voltage. This wire allows the unit to sense the engine running and control the starter motor. See TACH REFERENCE MODE. PIN 2: BLACK: MAIN SYSTEM GROUND Connect to chassis metal of the vehicle.
  • Page 14 WIRING: 6-PIN HIGH-CURRENT CONNECTOR PINK/WHITE: +12V MULTI-FUNCTION OUTPUT 30A (JUMPER SELECTABLE page 29): This is an optional multi-function output wire the can be configured as a Second IGN, ACC or STARTER output. Some vehicles require more than just one IGN, ACC, or STARTER wire in order to start and run successfully. If this is the case for your particular vehicle, then use the jumper pin located under the access panel on the top of the EZEESTART control module to configure this wire to suit your needs.

  • Page 15: Smart Tachless, Tach Reference, Tach Finder, & Timed Crank Modes

    Your EZEESTART system includes a unique voltage monitor called “Smart Tachless” mode. This mode allows this unit to efficiently start an engine without the use of a tach signal wire. These modules actively monitor the voltage level of the vehicle to control the starter motor each time a remote start is requested. IMPORTANT NOTES: (1) SETUP may be required for the EZEESTART “Smart Tachless”...
  • Page 16 TACH FINDER MODE: This Tach Finder mode can assist in locating a Tach source for your installation. When following the steps, the unit will begin to flash the parking lights if you have the WHITE/RED wire connected to a tach source. If lights do not flash, then try another wire until you locate a tach signal that will cause the Parking lights to flash.
  • Page 17 TACH PROGRAMMING & TACH SIGNALS INTRODUCTION Tach signals will vary in levels and frequencies depending on many factors including the type of vehicle and the source of the signal. The signals from a vehicle’s injector wire and coil pack wire can vary greatly even on the same engine. The tach signal from an engine can also be affected by other sources such as electronic noise from the ignition or computer modules.
  • Page 18 This feature provides an easy method of starting the vehicle without locating an exact tach wire. The system uses a timed cranking output combined with the use of the WHITE/RED tach wire as an engine ON/OFF monitor. The WHITE/RED Tach wire must still be used in this mode of operation. THIS FEATURE MUST BE PROGRAMMED BEFORE USE! THERE ARE 2 LEVELS of programming required: First, set the system for “Timed Crank”...

  • Page 19: Diesel Glow Plug Delay

    DIESEL GLOW PLUG DELAY This feature provides a solution for diesel vehicles without having to connect to the Glow Plug-“Wait to Start Circuit”. This may be needed for various reasons. If your vehicle does not have a viable “Wait to Start Circuit”, or you cannot locate and identify the circuit, then change your system to “Diesel Glow Plug Delay”...
  • Page 20 To Engage Option Programming: 1. Open hood (If no hood pin switch is installed, then ground the Blue wire) 2. Turn Key to the ON position. (Do not start vehicle) Pink wire must be connected! 3. Press the program / valet button 5 times. Wait for the unit to flash the lights and/or horn honk 5 times. 4.
  • Page 21 Option Option Description Number Yellow/black wire function Horn Chirp Confirmation Unlock with Trunk pop Timed Crank or Tach Monitor Horn Pulse (Chirp) OEM Disarm/Unlock Starter Cranking Time (Option #15 is set to Timed Crank) Diesel Glow Plug Delay Remote Start Engine Run Time Smart Tachless Voltage Adjustment 80-100% Aux # 2...
  • Page 22 OPTIONS PROGRAMMING Cont. OPTION DESCRIPTIONS: 1. Engine Monitoring: This option sets how the unit monitors your engine. You can program either for Tach mode in which the unit uses a Tach signal (RPM) or for Tachless mode that monitors voltage level. See pages 15-17 for more information and additional steps for actual Tach learning and Tach finder modes.
  • Page 23 OPTIONS PROGRAMMING Cont. 7. Horn Chirps on Remote Start: This option allows the unit to provide 3 short chirps for audible confirmation of a remote start. The horn output wire must be connected for this feature. 8. Lock During/After Remote Start: This option controls whether the unit will automatically lock during and after a remote Start abort or time-out.
  • Page 24 OPTIONS PROGRAMMING Cont. 17. OEM Disarm / Unlock Pulse: Some vehicles like Nissan and VW require a shorter setting to prevent the vehicle from attempting to roll down the windows due to the length of the UNLOCK and/or DISARM pulses. Use this option to SHORTEN the Disarm/Unlock Pulses should your vehicle require this.
  • Page 25 OPTIONS PROGRAMMING FOR EZ-55 AND EZ-95 ONLY FOR EZ-55 AND EZ-95 ONLY 24. Aux #3: This option controls the function of the Violet wire for a negative output for a Momentary, Pulse, Timed or Latched output, depending on option used. Option #25 controls the length of time output. 25.

  • Page 26: Transmitter / Transceiver Programming

    Transmitter Programming: Notes: Remote Transmitters/Transceivers come pre-programmed from the Factory. When re-learning remotes or adding remotes, ALL your system’s remote codes must be learned at time of programming!! These systems allow storage of up to 4 different remote codes in memory. The “Sidekick” transmitters for the TW1/TW2 and FM systems are a special model that is not compatible with each other.

  • Page 27: Vehicle Operation

    The EZ-45DP, EZ-55DP and EZ-95FM can be used for 2 vehicle operation. A single remote can control two independent vehicles with identical systems installed. See diagram below on how to switch your remote(s) to vehicle #2 operation. To set up the 2-Vehicle operation you must first program your remotes to Vehicle #2.

  • Page 28: Troubleshooting "Before You Call" Section

    TROUBLESHOOTING: “BEFORE YOU CALL” SECTION UNIT WILL NOT ATTEMPT TO START (KEYLESS ENTRY FUNCTIONS NORMALLY): The unit is in Valet mode. Turn IGN ON, press and hold valet/programming button for 5-6 seconds then turn key off. Unit is now out of valet mode and should remote start. If optional LED is installed, then it will be on solid when in Valet. SYSTEM IS UNSUCCESSFUL AT REMOTE START DURING EXTREME COLD CONDITIONS: Please be aware that during sub-freezing conditions your remote starter may take more that one attempt to start or it may not successfully start the vehicle after 3 attempts.

  • Page 29: Jumper Pin, Antenna, & Wiring Diagram

    JUMPER PIN DIAGRAMS PINK/WHITE = ACC #2 PINK/WHITE = IGN #2 (DEFAULT) PINK/WHITE = START #2 SECURING JUMPERS JUMPERS: PINK WHITE for ACC 2, IGN2, START2 PARKING LIGHT JUMPER WHITE WIRE: Jumper Select for Postive or Negative Type Light Circuits JUMPER PLUG SIDE VIEW...
  • Page 30 ANTENNA DIAGRAM EZ-45DP EZ-95FM EZ-55DP...
  • Page 31 30AMP FUSE RED: +12V 30AMP BATTERY FUSE RED: +12V PINK GRAY IGNITION BROWN SWITCH IGNITION 1 FLASHING ACCESSORY LIGHTS (Heat/Air) STARTER 4 5 6 WHITE/RED TACH INPUT ENGINE MONITOR (-) NEG. PULSE ORANGE/BLACK FOR FACTORY ALARM DISARM (-) OEM DISARM (500mA) (-) NEG.

  • Page 32: Data Port Diagram

    This unit includes DP Technology it will allow you to plug our bypass modules model OFA-10/20/30 directly into the unit by via Data Port. The OFA module cable plugs directly to the Data port on the side of the unit manual for detail instructions. Module Not Included www.crimestopper.com email@crimestopper.com Phone (800) 998-6880 FAX (805) 581-9500 ©...
