EZ-30 / EZ-10
Congratulations on your choice of an EZEE Start system by Crimestopper! This installation Handbook covers the
following models: EZ-30 Remote Start & Keyless Entry System & EZ-10 Basic Remote Start System only (No Keyless
entry).
DISCLAIMER:
This installation book is designed for the installer or individual with an existing understanding of automotive electrical
systems, along with the ability to test and connect wires for proper operation. To ease installation, we suggest that you
READ THIS MANUAL before beginning your installation. This book is provided as a GENERAL GUIDELINE and the
information contained herein may differ from your vehicle. Crimestopper Security Products, Inc. and its' vendors shall
not be liable for any accident resulting from the use of this product. This system is designed to be professionally
installed into a vehicle in which all systems and associated components are in perfect working condition.
TECHNICAL SUPPORT: (800) 998-6880
Monday - Friday 8:00am - 4:30pm Pacific Std. Time
Web Site: www.crimestopper.com
E-mail: tech-support@crimestopper.com
CRIMESTOPPER SECURITY PRODUCTS, INC.
1770 S. TAPO STREET, SIMI VALLEY, CA. 93063
REV A 08.2004
REMOTE ENGINE STARTING SYSTEM
INSTALLATION INSTRUCTIONS
INTRODUCTION
This device complies with FCC Rules part 15. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) This device must accept any interference that
may be received, including interference that may cause undesired
operation. The manufacturer is not responsible for any radio or TV
interference caused by unauthorized modifications to this equipment.
Such modification could void the user's authority to use the
equipment.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for CrimeStopper EZEE Start EZ-10
Summary of Contents for CrimeStopper EZEE Start EZ-10
-
Page 1: Installation Instructions
REMOTE ENGINE STARTING SYSTEM Congratulations on your choice of an EZEE Start system by Crimestopper! This installation Handbook covers the following models: EZ-30 Remote Start & Keyless Entry System & EZ-10 Basic Remote Start System only (No Keyless entry). DISCLAIMER: This installation book is designed for the installer or individual with an existing understanding of automotive electrical systems, along with the ability to test and connect wires for proper operation. -
Page 2: Table Of Contents
TABLE OF CONTENTS Pre-Installation Considerations……….………...……...…………………………………………………………….……2 Cautions & Warnings…….…………...….……..…..…………………………………………………………….…..……3 Wiring……..…………………………...…………………………………………………………………………….…….3-6 Wiring High-Current Connector…….………………...………………………………………………………………...6-8 Power Door Lock Wiring...………………………………………….…………….……..………...……………………..9-10 Smart Tachless, Tach & Tach Finder………………………………………………..…..……...…...………11-12 Diesel Glow Plug Delay..………………….…………………………………...…………………...…..…………………13 Options Programming ………..……………………….…………………………………...……………….……………13-15 Transmitter Programming…………………………………………………….……………..……...………………….….16 2 Vehicle Operation.……………………………….……………………………………...………………….……………17 Troubleshooting “Before You Call” Section……………..…………………………..……………….………….………18 Jumper Pin, Antenna, & System Diagrams………………………………………………………..………….….……19-20 PRE-INSTALLATION CONSIDERATIONS BEFORE BEGINNING, check all vehicle manufacturer cautions and warnings regarding electrical service (AIR BAGS, ABS BRAKES, ENGINE / BODY COMPUTER AND BATTERY). -
Page 3: Cautions & Warnings
INSTALLATION CAUTIONS & WARNINGS **FOR SAFETY REASONS, DO NOT INSTALL in vehicles with MANUAL TRANSMISSIONS.** If accidentally left in gear, a remote started vehicle could become a self-propelled threat to life and property. DO NOT extend the Remote start ignition harness length. Mount the module so that main harness reaches all ignition switch wiring. - Page 4 PIN 8: YELLOW/BLACK FOR NEGATIVE IGNITION OUTPUT: (Relay and/or Module not included) YELLOW/BLACK Diode isolate if using both! PIN 8: YELLOW/BLACK: FOR ANTI-GRIND/STARTER DISABLE OUTPUT: (Relay not included) MOTOR WIRING 3rd IGN (If needed) IGN 1 IGN 2 START BROWN YELLOW/BLACK MAKE CERTAIN TO CONNECT "BROWN"...
- Page 5 Connect the Green wire to optional outside sensors such as the Crimestopper RS-400 CoolStart Temperature/Timer module. This wire can also be connected to the Negative output channel of an alarm or Keyless entry system.
-
Page 6: Wiring High-Current Connector
WIRING PIN 4: PURPLE: (+12V) BRAKE RESET Connect the Purple wire to the side of brake pedal switch that shows +12 volts ONLY when pedal is depressed. This is the wire that turns off the remote start once the driver’s key is in the Ignition and turned to the ON position. PIN 3: ORANGE/BLACK: (-) OEM DISARM OUTPUT This wire provides a Ground pulse to disarm the vehicles' Factory anti-theft system prior to a Remote Start. - Page 7 WIRING: 7-PIN HIGH-CURRENT CONNECTOR PINK: +12V IGNITION OUTPUT 40A: Connect to circuit in the vehicle that provides true Ignition Power for systems such as Spark and Fuel. Typically, this wire turns ON with the second position of the key, STAYS ON WHEN CRANKING, and continues ON as the vehicle runs.
- Page 8 WIRING: 7-PIN HIGH-CURRENT CONNECTOR 7-PIN High Current Connector PARKING LIGHTS WHITE FUSE +10A or 500mA (-) PINK/WHITE FUEL ENGINE PUMP COIL IGN 2 ACC 2 START 2 IF NECESSARY PINK BROWN GRAY STARTER H/V/AC Diagram not to scale, for illustration purposes only.
-
Page 9: Power Door Lock Wiring
To install aftermarket systems in these vehicles, an interface module is required that converts the regular lock/unlock pulses into “Data messages” to allow locking & unlocking. Interface modules are sold separately. Crimestopper Door Lock Accessories: CS-6600DLM: Dual-relay plug-in module for Reverse Polarity, Positive, or Aftermarket Motors. - Page 10 EZ-30 ONLY: BASIC POWER DOOR LOCK DIAGRAMS NEGATIVE TRIGGER DOORLOCK WIRING GREEN BLUE REVERSE POLARITY DOOR LOCK WIRING GREEN BLUE MASTER SWITCH POSITIVE TRIGGER DOORLOCK WIRING GREEN BLUE FACTORY POWER LOCKING RELAYS AFTERMARKET MOTOR/DOOR LOCK WIRING GREEN FUSED +12V BLUE FUSED +12V FACTORY...
-
Page 11: "Smart Tachless" Mode
Your EZEE Start system includes a unique voltage monitor called “Smart Tachless” mode. This mode allows this unit to efficiently start an engine without the use of a tach signal wire. These modules actively monitor the voltage level of the vehicle to control the starter motor each time a remote start is requested. - Page 12 5. Push program button again once. (You must get one light flash after button is pressed.) This unit is now at option #1-Tach Learning. 6. Press the #1 Lock Button on the remote. (ON EZ-10 MODELS: Press the brake pedal once). The unit will read the Tach source and flash the lights once for program confirmation.
-
Page 13: Diesel Glow Plug Delay
5. Press the Lock/Unlock button on the remote select an option value. 5A. NOTE on EZ-10 One-Button Model, Tap the brake 1-4 times to select/toggle through the option values: The lights flash 1X for Value 1; Tap the brake pedal again for value 2 (Lights flash 2X); tap 3 or 4 times for options that have 3 or 4 values. -
Page 14: Option Descriptions
NOTES: (1) Options #2, #4 and #5 DO NOT APPLY TO THE EZ-10 MODEL (NO KEYLESS ENTRY) (2) For EZ-10 Model, tap the Brake Pedal to select/toggle the option values. Option Option Description Tach or Tachless Mode Autolock with RPM/Ignition... - Page 15 This option allows you to restore all programmable options to factory default values. Go to the option #8 and press the Unlock Button #2 on the remote. (For EZ-10 Model, Tap the brake pedal 2 times.) The unit will flash the lights 2 times...
-
Page 16: Transmitter Programming
3. Press Program/Valet button 4 times. After a few seconds, the unit will flash the parking lights 4 times. 4. EZ-30: Press Button #1 (Lock) of the transmitter to be learned. EZ-10 Model: Press Engine Start button. You should get 2 light flashes indicating the code-learn. Now the unit is waiting for a 2 up to 3 additional remotes. -
Page 17: Vehicle Operation
(2) An EZ-10 system remote can ONLY control another EZ-10 system. You cannot remote start any other models using the EZ-10. (3) Other EZEE Start remotes, such as the EZ-90 system, can be programmed to control an EZ-30 or EZ-10 system. -
Page 18: Troubleshooting "Before You Call" Section
TROUBLESHOOTING: “BEFORE YOU CALL” SECTION UNIT WILL NOT ATTEMPT A START (KEYLESS ENTRY FUNCTIONS NORMALLY): The unit is in Valet mode. Turn IGN ON, press and hold valet/programming button for 5-6 seconds then turn key off. Unit is now out of valet mode and should remote start. If optional LED is installed, then it will be on solid when in Valet. SYSTEM IS UNSUCCESSFUL AT REMOTE START DURING EXTREME COLD CONDITIONS: Please be aware that during sub-freezing conditions your remote starter may take more that one attempt to start, or it may not successfully start the vehicle after 3 attempts. -
Page 19: Jumper Pin, Antenna, & System Diagrams
Jumper pins are used to configure the operation of the on board multi-function output PINK/WHITE wire and the Parking Light WHITE wire. See the diagram below for Jumper Pin configurations. CONTROL MODULE JP1 JUMPERS: IGN2 / ACC2 / STR2 PINK WHITE ANTENNA / RECEIVER GUIDE JUMPER PIN &... - Page 20 TRANSMISSION ENGINE START #2 JUMPER STARTER SELECT +/- PARKING LIGHT JUMPER EZ-30/10 ANTENNA/RECEIVER PLUG (OPTIONAL) (-) UNLOCK OUTPUT PROGRAM +12 V FOR RELAYS SWITCH (-) LOCK OUTPUT **DOOR LOCK OUTPUT FOR MODEL EZ-30 ONLY** NOTE: USE EXTERNAL RELAYS FOR HIGH-CURRENT FUEL A/C - HEAT PUMP...
