EZ-30 / EZ-10
REMOTE ENGINE STARTING SYSTEM

OPERATING INSTRUCTIONS

**IMPORTANT NOTES:- FOR EZ-10 MODEL ONLY**
The EZ-10 Model is for remote starting purposes only. It has NO keyless entry functions. Any information in this
manual pertaining to remote keyless entry functions, door lock & door unlock applies only to the EZ-30 model.
*IMPORTANT INFORMATION: Primary and Optional Features
-PRIMARY: These are features that must be connected in order for the system to operate properly i.e. Remote
Start connections, Flashing lights, Brake Reset. For programming, the hood pin and program button are required.
-OPTIONAL: These features are to be connected only if desired or agreed upon by the customer and the
installing dealer i.e. Anti-Grind, Turbo timer, etc. These features may also require additional parts and/or labor
fees. Consult with your installer beforehand to be sure of what is going to be installed with your particular system.
TECHNICAL SUPPORT: (800) 998-6880
Monday - Friday 8:00am - 4:30pm Pacific Std. Time
Web Site: www.crimestopper.com
E-mail: email@crimestopper.com
CRIMESTOPPER SECURITY PRODUCTS, INC.
1770 S. TAPO STREET, SIMI VALLEY, CA. 93063
REV A - 08.2004
INTRODUCTION
This device complies with FCC Rules part 15. Operation is
subject to the following two conditions: 1) This device may not
cause interference, and (2) this device must accept any
interference that may be received, including interference that
may cause undesired operation.
responsible for any radio or TV interference caused by
unauthorized modification to this equipment. Such modification
could void the user's authority to operate the equipment.
The manufacturer is not

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EZEE START EZ-10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for CrimeStopper EZEE START EZ-10

  • Page 1: Operating Instructions

    **IMPORTANT NOTES:- FOR EZ-10 MODEL ONLY** The EZ-10 Model is for remote starting purposes only. It has NO keyless entry functions. Any information in this manual pertaining to remote keyless entry functions, door lock & door unlock applies only to the EZ-30 model.
  • Page 2: Table Of Contents

    Troubleshooting “Before You Call” Section……………..……………………………………………………..….11-12 OPERATION CAUTIONS & WARNINGS CRIMESTOPPER SECURITY PRODUCTS, INC. / EZEE START and its VENDORS shall not be liable for any accident resulting from the use of this equipment. This system is designed to be professionally installed into a car or vehicle in which all items, such as parking brake and all associated components, door switches, transmission shift linkage, throttle linkage, and all engine safety features, are in perfect working condition.
  • Page 3: Remote Control Diagrams

    EZ-30 or EZ-10 system. EZ-10 SYSTEM The transmitter supplied with the EZ-10 system has 3 buttons total. The button configuration of the EZ-10 is Factory-set and unchangeable. See Page 11 for additional information on how to use your remote to operate a second vehicle equipped with an EZ-10 system.
  • Page 4: Remote Engine Control

    REMOTE ENGINE STARTING - SUCCESSFUL START: 1) Press the remote start button for at least 1 second. 2) Parking lights flash once; return solid, and the Ignition/Acc circuits turn on. 3) After a few seconds the Starter Motor engages, Parking lights and Acc circuits will turn off while cranking. 4) Engine Starts and Runs.
  • Page 5 REMOTE ENGINE CONTROL ENTERING YOUR REMOTE STARTED VEHICLE: 1) With engine running, Remote Unlock system (EZ-30) or open door with key. 2) Enter vehicle and be careful not to step on brake pedal! (Remote Start Reset) 3) Turn Ignition to ON/RUN position, then press brake pedal to reset the Remote Starter & Shift out of park. 4) Remote starter will reset instantly when the brake is pressed.
  • Page 6: Remote Engine Control

    INFINITY RUN MODE This mode can only be activated when "Idle Down" procedure. The Infinity Run mode allows the vehicle engine to remain running INDEFINITELY after the programmed run time elapses. This mode will allow the vehicle to be left running and unattended without the ignition key in the switch preventing the vehicle from being stolen.
  • Page 7: Turbo Timer Mode

    TURBO TIMER MODE (OPTIONAL) The optional Turbo Timer mode allows the EZEE Start system to keep a Turbo or Turbo Diesel vehicle running for 1 to 5 minutes [selectively] after you remove the key, exit the vehicle, and lock the doors remotely. This is handy for turbo cool-down without the need for expensive turbo timers.
  • Page 8: Convenience And Safety Features

    CONVENIENCE AND SAFETY FEATURES EZ-30 ONLY: KEYLESS ENTRY (POWER DOOR LOCK CONTROL, Optional) This system enables you to remotely lock and unlock the vehicle’s doors (if equipped with power locks) via remote control for safety and convenience. Note: This feature may require extra labor and/or parts to install. Press the Lock or Unlock transmitter button as you leave or come near the vehicle.
  • Page 9: Transmitter Programming

    3. Press Programming button 4 times, then after a few seconds the unit flashes the parking lights 4 times. 4. Press Lock Button #1 of the transmitter to be coded. EZ-10 MODEL: Press Engine Start Button. You should get 2 light flashes indicating the unit is waiting for a 2 unit will flash 3 times indicating its waiting for the 3 automatically exit code learning mode, otherwise turn key off and close hood.
  • Page 10: Transmitter Programming

    TRANSMITTER PROGRAMMING TRANSMITTER PROGRAM DIAGRAM: WAIT FOR (GRAY WIRE GROUNDED) 4 FLASHES PRESS 4X's EZ-30 EZ-10 FLASH 2, 3, or 4 X's COMPLETE PRESS PRESS LOCK BUTTON START BUTTON...
  • Page 11: Vehicle Operation

    YOUR remote, along with vehicle #2’s existing remotes. MULTI-VEHICLE NOTES: (1) The EZ-30 system can remote start an EZ-10 one-button system using the EZ-30’s Unlock button as the “start” button for an EZ-10. (2) An EZ-10 system remote can ONLY control another EZ-10 system. You cannot remote start any other models using the EZ-10.
  • Page 12: Troubleshooting "Before You Call" Section

    • Press remote control Lock or Unlock button several times in succession to check if remote is out of sync with receiver. • Verify if remotes are programmed to module, otherwise perform transmitter programming steps. www.crimestopper.com email@crimestopper.com Phone (800) 998-6880 FAX (805) 581-9500 © 2004 Crimestopper Security Products ONLINE TECHNICAL SUPPORT www.crimestopper.com/techweb04.html...
