EZ-90 / EZ-91
REMOTE ENGINE STARTING SYSTEM
OPERATING INSTRUCTIONS
**IMPORTANT NOTES:- FOR EZ-91 MODEL ONLY**
The EZ-91 model is an add-on (expansion unit), without remotes or antenna. It must be controlled by an existing
alarm or keyless entry system (host system). The "Infinity Run" feature is not available on an EZ-91 system. Most
of the other standard remote starting features of this system can be controlled through the existing remote of the
host system. For most applications, remote start is triggered by pressing a Factory remote's Lock button 3 times
or pressing an Auxiliary channel button on an Aftermarket system. This is referred to in this manual as activating
the "Green Start input wire".
*IMPORTANT INFORMATION: Primary and Optional Features
-PRIMARY: These are features that must be connected in order for the system to operate properly i.e. Remote
Start connections, Flashing lights, Brake Reset. For programming, the hood pin and program button are required.
-OPTIONAL: These are features to be connected only if desired or agreed upon by the customer and the
installing dealer i.e. Door Locks, Trunk Pop, Dome Light Illumination, Horn-Honk, Anti-Grind, etc. These features
may also require additional parts and/or labor fees. Consult with your installer beforehand to be sure of what is
going to be installed with your particular system.
TECHNICAL SUPPORT: (800) 998-6880
Monday - Friday 8:00am - 4:30pm Pacific Std. Time
Web Site: www.crimestopper.com
E-mail: email@crimestopper.com
CRIMESTOPPER SECURITY PRODUCTS, INC.
1770 S. TAPO STREET, SIMI VALLEY, CA. 93063
REV A - 08.2004
INTRODUCTION
This device complies with FCC Rules part 15. Operation is
subject to the following two conditions: 1) This device may not
cause interference, and (2) this device must accept any
interference that may be received, including interference that
may cause undesired operation.
responsible for any radio or TV interference caused by
unauthorized modification to this equipment. Such modification
could void the user's authority to operate the equipment.
The manufacturer is not
Advertisement
Table of Contents
Related Manuals for CrimeStopper EZEE Start EZ-90
Summary of Contents for CrimeStopper EZEE Start EZ-90
-
Page 1: Operating Instructions
EZ-90 / EZ-91 REMOTE ENGINE STARTING SYSTEM OPERATING INSTRUCTIONS **IMPORTANT NOTES:- FOR EZ-91 MODEL ONLY** The EZ-91 model is an add-on (expansion unit), without remotes or antenna. It must be controlled by an existing alarm or keyless entry system (host system). The “Infinity Run” feature is not available on an EZ-91 system. Most of the other standard remote starting features of this system can be controlled through the existing remote of the host system. -
Page 2: Table Of Contents
OPERATION CAUTIONS & WARNINGS CRIMESTOPPER SECURITY PRODUCTS, INC. and its VENDORS shall not be liable for any accident resulting from the use of this equipment. This system is designed to be professionally installed into a car or vehicle in which all items, such as parking brake and all associated components, door switches, transmission shift linkage, throttle linkage, and all engine safety features, are in perfect working condition. -
Page 3: Using The Remote Transmitter
USING THE REMOTE TRANSMITTER The transmitter supplied with the EZ-90 system has six buttons. The button configuration of the EZ-90 is Factory-set and unchangeable. The EZ-91 model does not include remote transmitters, as it is designed for the expansion of a “parent” remote keyless or alarm system. - Page 4 3) Turn Ignition to ON/RUN position, then press brake pedal to reset the Remote Starter & Shift out of park. 4) Remote starter will reset instantly when the brake is pressed. Parking lights will turn off and the ignition key is now controlling your vehicle.
- Page 5 REMOTE ENGINE CONTROL IDLE DOWN MODE - EXITING THE VEHICLE: 1) With vehicle engine running with key, press the Remote Start button for at least one second. (For EZ-91 model activate Green remote start input wire.) 2) Parking Lights will turn ON. 3) Doors will unlock, or if brake pedal is being depressed, doors will unlock when it is released.
- Page 6 INFINITY RUN MODE – EXITING THE VEHICLE: 1) With vehicle engine running with the key, press the Remote Start button for at least 1 second, pause a few seconds, then press and release the remote start button a second time. 2) Parking Lights will start flashing, and doors will unlock.
-
Page 7: Turbo Timer Mode
TURBO TIMER MODE (OPTIONAL) The optional Turbo Timer mode allows the EZEE system to keep a Turbo or Turbo Diesel vehicle running for 1 to 5 minutes [selectively] after you remove the key, exit the vehicle, and lock the doors remotely. This is handy for turbo cool-down without the need for expensive turbo timers. -
Page 8: Convenience And Safety Features
CONVENIENCE AND SAFETY FEATURES KEYLESS ENTRY (POWER DOOR LOCK CONTROL, Optional) This system enables you to remotely lock and unlock the vehicle’s doors (if equipped with power locks) via remote control for safety and convenience. Note: This feature may require extra labor and/or parts to install. Press the Lock or Unlock transmitter button as you leave or come near the vehicle. -
Page 9: Convenience And Safety Features
This system must be programmed to allow this relay to work as a starter disable. PASSIVE STARTER DISABLE (Optional) This EZ-90 includes a programmable feature to allow the Optional Starter Disable to activate automatically 1 minute after the ignition is turned off. This programmable feature may provide insurance discounts for “Passive Security”... -
Page 10: Transmitter Programming
Note: All transmitter codes must be learned at time of programming!! The EZ-90 learns up to 4 different transmitter codes. 1. Open Hood (If no hood pin installed with your system, then you must ground the Gray Hood pin wire). -
Page 11: Vehicle Operation
A single EZ-90 remote can control a second vehicle with an EZEE Start EZ-90 system installed. SETUP: Follow the “Transmitter Programming” steps on the second vehicle. Program Car #2’s existing remotes, then quickly press the Car #2 side button on your remote before pressing the Lock button on your remote to program it to Car #2. - Page 12 SYSTEM IS UNSUCCESSFUL AT REMOTE START DURING EXTREME COLD CONDITIONS: Please be aware that during sub-freezing conditions your remote starter may take more that one attempt to start, or it may not successfully start the vehicle after 3 attempts. During these conditions the vehicle may not properly start even using the key, therefore trying to start by the remote would also be unsuccessful.
