EZ-1
ONE BUTTON REMOTE START SYSTEM
CONGRATULATIONS on your choice of a Cool Start™ Remote Engine Starter and Keyless Entry with DP
Technology by Crimestopper Security Products Inc. This booklet contains the information necessary for operating
your system. If any questions arise, contact your installation dealer or Crimestopper Security Products Inc.
*IMPORTANT INFORMATION: Primary and Optional Features
-PRIMARY: These are features that must be connected in order for the system to operate properly i.e. Remote
Start connections, Flashing lights, and Brake Reset. For programming, the hood pin and program button are
required.
-OPTIONAL: These features are to be connected only if desired or agreed upon by the customer and the installing
dealer i.e. Door Locks, Trunk Pop, Dome Light Illumination, Horn-Honk, Anti-Grind, etc. These features may also
require additional parts and/or labor fees. Consult with your installer beforehand to be sure of what is going to be
installed with your particular system.
CRIMESTOPPER SECURITY PRODUCTS, INC.
1770 S. TAPO STREET, SIMI VALLEY, CA. 93063
REV 09-2008
OPERATING INSTRUCTIONS
This device complies with FCC Rules part 15. Operation is
subject to the following two conditions: 1) This device may not
cause interference, and (2) this device must accept any
interference that may be received, including interference that
may cause undesired operation.
responsible for any radio or TV interference caused by
unauthorized modification to this equipment. Such modification
could void the user's authority to operate the equipment.
The manufacturer is not

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EZEE Start EZ-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CrimeStopper EZEE Start EZ-1

Summary of Contents for CrimeStopper EZEE Start EZ-1

  • Page 1 CONGRATULATIONS on your choice of a Cool Start™ Remote Engine Starter and Keyless Entry with DP Technology by Crimestopper Security Products Inc. This booklet contains the information necessary for operating your system. If any questions arise, contact your installation dealer or Crimestopper Security Products Inc. *IMPORTANT INFORMATION: Primary and Optional Features -PRIMARY: These are features that must be connected in order for the system to operate properly i.e.

  • Page 2: Table Of Contents

    OPERATION CAUTIONS & WARNINGS CRIMESTOPPER SECURITY PRODUCTS, INC. and its VENDORS shall not be liable for any accident resulting from the use of this equipment. This system is designed to be professionally installed into a car or vehicle in which all items, such as parking brake and all associated components, door switches, transmission shift linkage, throttle linkage, and all engine safety features, are in perfect working condition.

  • Page 3: Using The Remote Transmitter

    The transmitter supplied with this system is a single button remote control. To eliminate the possibility of accidentally starting the vehicle, there are (3) options for button press selection. This option will allow you to change whether the Remote Starter is activated by a: 1. Double Button - ½ second presses.

  • Page 4: Status Led

    VEHICLE STATUS LED : (Install optional) The optional LED will remain solid when the system is in Valet Service mode. The remote start function WILL NOT operate when in Valet Mode. See page # 11. REMOTE ENGINE STARTING - SUCCESSFUL START: 1) Press the remote start button for at least 1/2 second (*default).
  • Page 5 3) Turn Ignition to ON/RUN position, then press brake pedal to reset the Remote Starter & Shift out of park. 4) Remote starter will reset instantly when the brake is pressed. Parking lights will turn off and the ignition key is now controlling your vehicle.
  • Page 6 IDLE DOWN MODE: This mode allows the unit to take over operation of the parked vehicle while the ignition key is removed and you exit the vehicle. The vehicle is put into a remote running condition before you exit and it will remain running for the programmed run time or until you come back.
  • Page 7 INFINITY RUN MODE This mode can only be activated with "Idle Down" procedure. The Infinity Run mode allows the vehicle engine to remain running INDEFINITELY after the programmed run time elapses. This mode will allow the vehicle to be left running and unattended without the ignition key in the switch preventing the vehicle from being stolen.

  • Page 8: Turbo Timer Mode

    TURBO TIMER MODE (OPTION #22) The optional Turbo Timer mode allows the CoolStart system to keep a Turbo or Turbo Diesel vehicle running for 1 to 5 minutes [selectively] after you remove the key and exit the vehicle. This is handy for turbo cool-down without the need for expensive turbo timers.
  • Page 9 SETTING THE TURBO TIMER RUN TIME PRESS TURBO RELEASE TIMER BUTTON PRESS RUNNING BRAKE 1-5 TIMES AND HOLD BRAKE LIGHTS REMOVE KEY FLASH 1-5X REMAIN RUNNING 1-5 MIN. EXIT VEH.

  • Page 10: Convenience And Safety Features

    CONVENIENCE AND SAFETY FEATURES KEYLESS ENTRY (POWER DOOR LOCK CONTROL, Optional) This system enables you to remotely lock and unlock the vehicle’s doors (if equipped with power locks) via remote control for safety and convenience. Note: This feature may require extra labor and/or parts to install. Press the Lock or Unlock transmitter button as you leave or come near the vehicle.

  • Page 11: Valet Service Mode

    This Optional feature prevents the user from accidentally grinding the starter if the Ignition key is turned too far to the start position while engine is already running from the remote starter. The Anti-Grind/Starter Disable requires the use of an external relay.

  • Page 12: Transmitter Programming

    Note: All transmitter codes must be learned at time of programming!! The RS-1 learns up to 4 different transmitter codes. 1. Turn key to the ON position. (Pink wire must be connected.) 2. Press Programming button 4 times, then after a few seconds the unit flashes the parking lights 4 times. 3.

  • Page 13: No Factory Keyless Entry After Remote Start

    SYSTEM IS UNSUCCESSFUL AT REMOTE START DURING EXTREME COLD CONDITIONS: Please be aware that during sub-freezing conditions your remote starter may take more that one attempt to start, or it may not successfully start the vehicle after 3 attempts. During these conditions the vehicle may not properly start...

  • Page 14: Battery Replacement

    To replace the battery: Simply remove the screw on back of the transmitter and slide the case apart as shown. Remove the two CR-2016 Lithium batteries and replace. Slide case back together and tighten screw. Back Cover Screw BATTERY REPLACEMENT Slide apart LITHIUM CR 2016...

  • Page 15: 2-Way Data Port

    Databus modules are used to communicate with the vehicles computer at the OBD2 Data connector or Canbus wires. This reduces installation error. Crimestopper Systems with DP Series have a direct Data Port Plug-In for the Databus bypass module. This eliminates conventional wiring between the Alarm/Remote Starter and the bypass interface module.
  • Page 16 ONLINE TECHNICAL SUPPORT email@crimestopper.com www.crimestopper.com Phone (800) 998-6880 FAX (805) 581-9500 © 2008 Crimestopper Security Products...
