Mounting the protective vice housing

For this operation you need access to the underside of the machine. For this tip the machine with help from another
person, or, if the workbench allows, access it directly from the hole (see "Physical installation advice" photo 11).
1. Loosen the two screws
2. Place the housing
and 14).
3. Tighten the two screws
If the plate is correctly tightened, noise and vibrations are reduced to a minimum when the machine is engraving.
IS200 TX machine . 14
(photo 13) and put them safety to one side.
so that the holes are directly over the two grub screws
(photo 14).
(photos 13
