mikroElektronika DC MOTOR 2 click Manual page 2

5. Schematic
VCC
R1
2K2
PWR
VCC
AN PWM
IN2
RST INT
IN1
CS TX
SCK RX
SCL
MISO
SDA
MOSI
+3.3V +5V
GND GND
MIKROBUS DEVICE CONN.
R3 0R
R2 0R
GND GND PGND
6. Dimensions
42.9 mm / 1690 mils
VCC VCC
C1 C2
10uF 100nF
VM
U1
1
GND
PWM PWM 2
PWM
SLP SLP 3
STBY
4
VM1
5
VM2
OUT1 6
O1
OUT1 7
O1
8
PGND
9
PGND
10
PGND
TB6593FNGTR
GND GND PGND
mm mils
42.9 1690
LENGTH
25.4 1000
WIDTH
17.5 689
HEIGHT*
* without headers
VM VM
C3 C4
10uF 100nF
VCC VM VM
20
VCC
19 IN1
IN1
18 IN2
IN2
17
VM4
16
VM3
15 OUT2
O2
14 OUT2
O2
13
PGND
12 PGND
PGND
11
PGND
OUT2
OUT1
PGND
7. SMD jumper
DC MOTOR 2 click features an SMD jumper
(zero ohm resistor) that let's you switch
between a 3.3V or a 5V power supply.
8. Code examples
Once you have done all the necessary
preparations, it's time to get your click board
up and running. We have provided examples
for mikroC , mikroBasic
™
compilers on our Libstock website. Just
download them and you are ready to start.
CN2
9. Support
MikroElektronika offers free tech support
(www.mikroe.com/support) until the end of
the product's lifetime, so if something goes
CN1
wrong, we're ready and willing to help!
SCREW
TERMINAL
10. Disclaimer
MikroElektronika assumes no responsibility
or liability for any errors or inaccuracies
that may appear in the present document.
Specification and information contained in
the present schematic are subject to change
at any time without notice.
Copyright © 2015 MikroElektronika.
All rights reserved.
™
and mikroPascal
™ ™
