KIT COMPONENTS
• A) Radio trim panel • B) Radio housing • C) Sub dash brackets • D) Radio brackets • E) Panel clips (3) • F) #8 x 1/2" Phillips screws (4)
A
B
Metra. The World's Best Kits.
®
Ford Transit
(excludes factory radio delete models)
Visit
MetraOnline.com
for more detailed information about the product and up-to-date vehicle
specific applications
KIT FEATURES
• ISO DDIN radio provision*
• Painted scratch resistant matte black
* This kit is designed for an ISO DDIN radio which have an "L" shaped chassis
design, with the radio chassis at the bottom of the screen,
or Pioneer modular 6.8" radios.
† Refer to the radio manufacturer for current models
C
MetraOnline.com
2020
D
E
F
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
107-FD1B
I N S TA L L AT I O N I N S T R U C T I O N S
Patent Pending
TABLE OF CONTENTS
Dash Disassembly ..................................................2
Kit Preparation .......................................................3
Kit Assembly
–ISO DDIN radio provision .....................................4
–Pioneer Modular radio provision .......................5
WIRING & ANTENNA CONNECTIONS (sold separately)
See metra-online.com or axxessinterfaces.com
for audio and SWC interface options
Antenna Adapter: 40-EU10
TOOLS REQUIRED
• Panel removal tool • 9/32" socket
• Phillips screwdriver • Cutting tool
Attention!
Let the vehicle sit with the key
out of the ignition for a few minutes before
removing the factory radio. When testing the
aftermarket equipment, ensure that all factory
equipment is connected before cycling the
key to ignition.
REV. 12/11/20 INST107-FD1B
