INSTALLATION INSTRUCTIONS FOR PART 99-7300
HYUNDAI Tiburon 1997-2002
HYUNDAI Accent 2000-2001
99-7300
KIT FEATURES
• ISO Mount Radio Provision
KIT COMPONENTS
A) Radio Housing 1 • B) Bracket Set 1 • C) (2) #10 x 3/4" Phillips Screws • D) Radio Housing 2
• E) Bracket Set 2 • F) (4) #10 x 3/4" Phillips Pan Headed Screws
A
D
1-800-221-0932
© COPYRIGHT 2004-2007 METRA ELECTRONICS CORPORATION
APPLICATIONS
B
E
TOOLS REQUIRED:
Phillips Screwdriver • Panel Removal Tool
www.metraonline.com
C
F
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Metra Electronics 99-7300
Summary of Contents for Metra Electronics 99-7300
- Page 1 INSTALLATION INSTRUCTIONS FOR PART 99-7300 HYUNDAI Tiburon 1997-2002 HYUNDAI Accent 2000-2001 99-7300 KIT FEATURES • ISO Mount Radio Provision KIT COMPONENTS A) Radio Housing 1 • B) Bracket Set 1 • C) (2) #10 x 3/4” Phillips Screws • D) Radio Housing 2 •...
- Page 2 - HYUNDAI Tiburon 1997-2002 ......1 - HYUNDAI Accent 2000-2001 ......2 Kit Assembly - Tiburon ISO Mount Radio Provision with Pocket .
- Page 3 99-7300 DASH DISASSEMBL Y HYUNDAI Tiburon 1997-2002 isconnect the negative battery ter- minal to prevent an accidental short circuit. Remove (4) Phillips screws securing the center console. Pry out on the front edge of the console and unclip the radio trim bezel. Remove (4) Phillips screws securing the factory head unit and disconnect the wiring.
- Page 4 (2) vent cables located above the accelerator. Unclip the dash trim bezel and remove. Remove (4) screws securing the fac- tory head unit and disconnect the wiring. (Figure A) Continue to final assembly. 99-7300 DASH DISASSEMBL Y...
- Page 5 Slide the head unit into the Radio Housing, align the holes in the head unit with the holes in the Housing and mount the unit with the screws supplied with the unit. (Figure B) Continue to final assembly. 99-7300 KIT ASSEMBL Y...
- Page 6 HYUNDAI ACCENT ISO MOUNT RADIO PROVISION Note: Refer also to the instructions included with the aftermarket radio. Snap the ISO Brackets over the mounting tabs on the Radio Housing. (Figure A) Slide the head unit into the Radio Housing, align the holes in the head...
- Page 7 * * N N O O T T E E : : When a Black wire is not present, ground radio to vehicle chassis. All colors may not be present on all leads due to manufacturer’s specifications. 99-7300 FINAL ASSEMBL Y (A) Strip wire ends back 1/2"...
- Page 8 99-7300 INSTRUCTIONS www.metraonline.com 1-800-221-0932 REV. 08/24/07 © COPYRIGHT 2004-2007 METRA ELECTRONICS CORPORATION INST99-7300...
