Summary of Contents for Deagostini MODEL SPACE Lamborghini Countach LP 500S

  • Page 1 WALTER WOLF MODEL Pack ™...
  • Page 2 Lamborghini Countach LP 500S CONTENTS ™ Editorial and design by Continuo Creative, 39-41 North Road, London N7 9DP. Published in the UK by De Agostini UK Ltd, Battersea Studios 2, Assembly Guide Stages 65-67 82 Silverthorne Road, London SW8 3HE. Published in the USA by De Agostini Publishing USA, Inc., 915 Broadway, Suite 609, New York, NY 10010.
  • Page 3 Lamborghini Countach LP 500S The plaque on the inside of the driver’s door, identifying this as the Lamborghini Countach LP 500S built specially for Walter Wolf.
  • Page 4 Lamborghini Countach LP 500S Stage 65 The chassis Parts Chassis 2.6 × 3mm screws with washers × 7 2.3 × 5mm screws × 3 2.6 × 6mm tapping screws × 3 Plaque Tools Prepare Tweezers Soft cloth Top edge Check the words on the plaque to confirm which edge is Remove the double-sided tape from the back of the plaque.
  • Page 5 Lamborghini Countach LP 500S Place in the middle of this section Locate the point indicated in the next step, and place the Once the plaque is in position, press it against the chassis. Wipe the surface of the plaque with a soft cloth. The surface plaque there, with the top edge facing inwards.
  • Page 6 Lamborghini Countach LP 500S...
  • Page 7 Lamborghini Countach LP 500S Here you can see the rear storage compartment with the boot cover (assembled in the previous pack) raised, to give you an idea of the internal size.
  • Page 8 Lamborghini Countach LP 500S Stage 66 The boot liner Parts Boot liner Boot lock Tools Tweezers Peel the double-sided tape from between the two pins on Locate the two mounting holes in the back edge of the Align the pins on the lock with the holes in the liner. the back of the boot lock.
  • Page 9 Lamborghini Countach LP 500S STAGE COMPLETE This stage is now complete. Store the boot liner in a closed plastic bag until it’s needed again, because Insert the pins of the lock into the holes in the edge of the liner. Press the lock its flocked surface will easily pick up dust and dirt.
  • Page 10 Lamborghini Countach LP 500S A close-up shot of the front end, with headlamps in the raised position and illuminated.
  • Page 11 Lamborghini Countach LP 500S...
  • Page 12 Lamborghini Countach LP 500S Stage 67 The left headlamp lenses Parts Left headlamp unit Headlamp lens A Headlamp lens B Tools Prepare Phillips screwdriver (size 1) LED tester (Stage 28) Main assembly (Stage 54) AAA batteries × 3 Masking tape Remove the battery box cover and insert Replace the battery box cover and tighten Connect the battery box to the ‘BATTERY’...
  • Page 13 Lamborghini Countach LP 500S Step Look inside each headlamp reflector and There is a step around the rim of each Apply a small strip of masking tape to each Then apply a strip of masking tape to the locate the stepped lip (circled and inset). headlamp lens (A and B), which matches side of the headlamp, in line with the steps in upper half of each lens, in line with the step.
  • Page 14 Lamborghini Countach LP 500S Hose B In Stage 51, the instructions for connecting hose B to the right radiator were, unfortunately, incorrect. The steps below show you how to remove it and fit it into the correct hole. Pull the end of hose B out of the upper hole in the Remove the oil filter as well.
  • Page 15 Lamborghini Countach LP 500S A detailed shot of the right-hand side of the engine, and the area under the right wheel box that houses the hose and radiator.
  • Page 16 Lamborghini Countach LP 500S...
