Summary of Contents for Deagostini Fast & Furious Pack 18
- Page 1 pack...
- Page 2 FCA US LLC and used under license by Assembling the fuel cap Premium and Collectibles Trading Co. Ltd. ©2019 FCA US LLC. ©️ 2019 Editorial Planeta DeAgostini S.A.U. Todos los derechos reservados. Stage 78 Rear left wheel arch ©️...
- Page 3 STAGE REAR BODY PANELS In this assembly session you will attach the rear left and right inner body panels. Follow our instructions carefully, using the illustrations to help you. PIECES FOR THIS STAGE 76A Rear left inner panel 75B Rear right inner panel PP Screws 2x4x5 mm (x 12)* *Some of the parts are spares.
- Page 4 STAGE 76 76.1 the rear left inner panel 76A on the inside of the middle lace section of the car body 61A, as shown in the illustration. 76.2 the panel with five type PP screws, ecure inserted from the outside of the body.
- Page 5 STAGE 76 76.3 place the rear right inner panel 76B on the middle section of the car body 61A. A USEFUL TIP Remember that before permanently joining two or more pieces, it is advisable to put them close to each other and see just how they fit together, without forcing them unnecessarily.
- Page 6 STAGE 76 76.4 secure the right panel 76B to the middle iNally section of the car body 61A with five type PP screws. STAGE 76 FINAL RESULT You have now mounted the rear left and right inner body panels. Keep what you have built so far in a safe place.
- Page 7 ASSEMBLING STAGE THE FUEL CAP In this assembly session you will be working on the fuel cap. Please follow our instructions and the accompanying illustrations very carefully. PIECES FOR THIS STAGE 77A Rear left parking light mount plate 77E Fuel cap base 77B Rear left parking light frame 77F Fuel cap ring 77C Rear left parking light lens...
- Page 8 STAGE 77 77.1 the tab on the fuel cap ring 77F into the corresponding slot NSert in the base 77E. 77.2 the piece over and attach the fuel cap 77D, so that the two protruding parts are either side of the tab on the ring 77F.
- Page 9 STAGE 77 MAXIMUM ATTENTION TO DETAILS Every single detail on the 1970 Dodge Charger R/T, the model Dominic Toretto drove in Fast and Furious, is a tiny work of art, for example this shiny fuel cap on the left side of the car.
- Page 10 STAGE 77 77.3 secure the fuel cap 77D to the iNally A USEFUL TIP completed base with a type RP screw. Once you have finished this assembly session, check that the fuel cap’s hinge has the same resistance when opening and closing.
- Page 11 THE REAR LEFT STAGE WHEEL ARCH In this assembly session you will attach the fuel cap and parking light to the rear left wheel arch of your model. You will then attach the wheel arch to the car body. PIECES FOR THIS STAGE 78A Rear left wheel arch DM Screws 1.7x3x5 mm (x 3)* AM Screws 2x4 mm (x 11)*...
- Page 12 STAGE 78 78.1 78.2 the pieces from the last stage. GaiN from the inside, insert the lens 77C into Insert the parking light frame 77B into the rear left the frame. The interlocking elements mean that the wheel arch 78A from the inside. pieces only fit together in one way.
- Page 13 STAGE 78 78.5 the fuel o Secure tap to the wheel arch 78A, insert two type AP screws from underneath. 78.6 SiNG the linchpins, mount the wheel arch 78A on the left side of the car body.
- Page 14 STAGE 78 78.7 ecure the wheel arch from the inside using nine type AM screws. STAGE 78 FINAL RESULT You have now attached the rear left wheel arch, with the fuel cap and parking light, to the car body.
- Page 15 THE REAR RIGHT STAGE BOOT SIDE PANEL In this assembly session you will attach the rear right boot side panel to the car body. Please follow our instructions and the accompanying illustrations very carefully. PIECES FOR THIS STAGE 79A Right boot side panel 79D Rear right parking light lens 79B Rear right parking light mount plate SM Screws 2x4x5 mm (x 6)*...
- Page 16 STAGE 79 79.1 ttach the rear right boot side panel 79A to the inside of the right side of the car body (62A and 61A) by aligning the five linchpins with the five corresponding holes in the car body.
- Page 17 STAGE 79 79.2 securing the panel by inserting two type SM tart screws in the holes at the back. 79.3 insert another two type SM screws from the outside of the car body to secure the middle of the rear right boot side panel 79A.
- Page 18 STAGE 79 79.4 iNally insert another type SM screw in the hole in the middle section of the car body 61A, indicated in the illustration. STAGE 79 FINAL RESULT You have now mounted the rear right boot side panel. Keep any pieces you haven’t used in a safe place.
- Page 19 THE REAR RIGHT STAGE WHEEL ARCH In this assembly session we will show you how to attach the rear right wheel arch to the body of your model. Follow our instructions and the accompanying illustrations carefully. PIECES FOR THIS STAGE 80A Rear right wheel arch DM Screws 1.7x3x5 mm (x 3)* AM Screws 2x4 mm (x 11)*...
- Page 20 STAGE 80 80.1 the pieces from stage 79. Insert the parking light frame 79C into the rear right wheel arch 80A from the inside. 80.2 from the inside, insert the lens GaiN 79D into the frame. The interlocking elements mean that the pieces only fit together in one way.
- Page 21 STAGE 80 80.4 the linchpins, mount the wheel arch 80A on the SiNG right side of the car body. 80.5 securing the wheel tart arch from the inside using five type AM screws.
- Page 22 STAGE 80 80.6 finish securing the rear right wheel arch iNally with another four type AM screws. STAGE 80 FINAL RESULT You have now mounted the rear right wheel arch on the car body.
