UG-963

BILL OF MATERIALS

Table 1. Bill of Materials
Reference Designator
+5V
3V3_USB, 5V_USB
AGND
C1
C2
C3, C4
C5, C8, C28, C30
C6, C17, C33, C36, C37, C38, C62, C63
C7, C29, C31, C32, C39, C40, C41, C64,
C65, C66, C70, C71
C9
C10, C13, C18, C19, C21, C25, C44, C45,
C46, C53, C54, C55, C57, C58, C59, C60,
C61
C1, C12, C49
C14, C15, C16, C20, C22, C52, C56
C23, C34
C24
C26, C27
C35
C42, C43
C47, C50
C48, C51
C67
C68, C69
CE, CLK
D1, D6
D2, D4, D5
D3
DATA
GND
GNDT
L1, L2
L3
LD, LE, MUXOUT, PDBRF
LK1
PRE_IN
R1
R2, R3
R4
R5, R6, R8, R14, R18, R30, R36, R42, R43,
R46, R53, R54, R55, R57, R102
R7, R38
R9, R48
R10, R12, R29
R11
R13, R22, R31, R32, R35, R37, R51, R52,
R56, R58, R101
R15, R16, R17, R19
1
Value Description
N/A Red test point
Do not insert Red test point
N/A Black test point
2.2 nF 50 V, X7R, SMD ceramic capacitor
47 nF 50 V, X7R, SMD ceramic capacitor
1.5 nF 50 V, X7R, SMD ceramic capacitor
1 µF Capacitor, 0603, 1 µF, 10 V, X5R
100 pF 50 V, C0G, ceramic capacitor
1 µF 50 V, X5R, 0805, 1.0 µF, ceramic
capacitor
Do not insert TAJ-A capacitor location, not inserted
0.1 µF 16 V, X7R, ceramic capacitor
1 nF 50 V, NP0, ceramic capacitor
10 pF 50 V, NP0, ceramic capacitor
68 pF 50 V, C0G, ceramic capacitor
120 pF 50 V, NP0, ceramic capacitor
12 pF 50 V, NP0, SMD, ceramic capacitor
Do not insert 0402 capacitor location , not inserted
1 nF Ceramic capacitor, 1000 pF, 50 V, C0G,
0402
1 µF Ceramic capacitor, 1.0 µF, 50 V, X5R,
0805
22 µF 6.3 V, tantalum capacitor (TAJ-A case)
1.2 nF 50 V, X7R, ceramic capacitor
33 pF 50 V, C0G, ceramic capacitor
Do not insert Red test point
N/A Green LED
LL4002G Power rectifier diode
N/A Red LED
Do not insert Red test point
N/A Black 4 mm banana socket
N/A Black test point
27 nH Coilcraft 0402CS SMD inductor
47 nH Coilcraft 0402CS SMD inductor
Do not insert Red test point
N/A 3-pin SIL header and shorting link
N/A End-launch 50 Ω SMA jack
510 Ω SMD resistor
330 Ω SMD resistor
5.1 kΩ SMD resistor
Do not insert 0603 resistor location, not inserted
1 kΩ SMD resistor
240 Ω SMD resistor
Do not insert 0402 resistor location, not inserted
150 Ω 0402 SMD resistor
0 Ω SMD resistor
10 kΩ SMD resistor
Rev. 0 | Page 18 of 20
EVAL-ADF4152HVEB1Z User Guide
Manufacturer/Part Number
Vero 20-313137
Not applicable
Vero 20-2137
Multicomp MCCA000229
Multicomp MCCA000249
Multicomp MCCA000227
Murata GRM188R61A105KA61D
Murata GRM1555C1H101JD01D
Taiyo/Yuden GRM32RR71H105KA01L
Not applicable
Kemet C0402C104K4RAC
AVX 06035A102JAT2A
AVX 04025U100GAT2A
Murata GRM1555C1H680JZ01D
AVX 04025A121JAT2A
Phycomp 2238 867 15129
Not applicable
Murata GRM1555C1H102JA01D
Taiyo/Yuden TMK107BJ105KA-T
AVX TAJA226K006R
Murata GRM155R71H122KA01D
Murata GRM1555C1H330JZ01D
Not applicable
Avago Technologies, HSMG-C170
Multicomp LL4002G
Avago Technologies HSMS-C170
Not applicable
Deltron 571-0100-01
Vero 20-2137
Coilcraft 0402CS-27NX-LU
Coilcraft 0402CS-47NX-LU
Not applicable
Harwin M20-9990345 & M7567-05
Emerson Network 142-0701-851
Multicomp MC 0.063W 0603 510r
Multicomp MC 0.063W 0603 330R
Multicomp MC 0.063W 0603 5k1
Not applicable
Multicomp MC 0.063W 0603 1K
Multicomp MC 0.063W 0603 240R
Not applicable
Multicomp MC 0.0625W 0402 1% 150R
Multicomp MC 0.063W 0603 0R
Multicomp MC 0.063W 0603 10K
