Carlisle BINKS IEC 71 Assemblies

Qs agitator
Hide thumbs

Advertisement

Quick Links

Download this manual
Service Manual
EN
QS AGITATOR ASSEMBLIES
IMPORTANT! DO NOT DESTROY
It is the Customer's responsibility to have all operators and service personnel read and understand this
manual.
Contact your local Carlisle Fluid Technologies representative for additional copies of this manual.
READ ALL INSTRUCTIONS BEFORE OPERATING THIS PRODUCT
77-3318 R1.1
www.carlisleft.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the BINKS IEC 71 and is the answer not in the manual?

Questions and answers

Related Manuals for Carlisle BINKS IEC 71

Summary of Contents for Carlisle BINKS IEC 71

  • Page 1 IMPORTANT! DO NOT DESTROY It is the Customer's responsibility to have all operators and service personnel read and understand this manual. Contact your local Carlisle Fluid Technologies representative for additional copies of this manual. READ ALL INSTRUCTIONS BEFORE OPERATING THIS PRODUCT 77-3318 R1.1...
  • Page 2 Providing all conditions of safe use / installation stated within the product manuals have been complied with and also installed in accordance with any applicable local codes of practice. Director of Sales (EMEA) D Smith Signed for and on behalf of Carlisle Fluid Technologies UK Ltd: 1/2/18 Bournemouth,BH11 9LH,UK 2/24 77-3318 R1.1...
  • Page 3 In this part sheet, the words WARNING, CAUTION and NOTE are used to emphasize important safety information as follows: WARNING CAUTION NOTE Hazards or unsafe practices which could result in Hazards or unsafe practices which could result in Important installation, operation or maintenance minor personal injury, product or property severe personal injury, death or substantial property information.

  • Page 4: Functional Description

    FUNCTIONAL DESCRIPTION The Binks agitator is intended for agitating paints and similar finishing materials upto 1000 Centipoise viscosity. For materials >500 Centipoise, it is recommended to use two impeller configurations. The agitator can be mounted to a tank or lid and has various shaft and impeller configurations to suit most applications.
  • Page 5 PART NUMBER SELECTION GUIDE IMPELLER ASSEMBLY SHAFT LENGTH [cm] MATERIALS OF CONSTRUCTION STAINLESS STEEL DRIVE TYPE ELECTRIC PNEUMATIC PART NUMBER PREFIX Ø [cm] IMPELLER TYPE IMPELLER 1 X PADDLE 2 X PADDLE 4 X PADDLE DRIVE COMBINATIONS IEC 71 GEARBOX & AGITATOR ONLY NEMA 56C GEARBOX &...
  • Page 6 EQUIPMENT PROTECTION LEVELS IEC 71 MODELS ONLY ZONE 1 EPL Gb SHAFT LENGTH [cm] ZONE 0 E.G., 75cm EPL Ga TANK LID OFFSET CALCULATION - AGITATOR POSITIONING Calculation example: Tank ØD = Ø600 Offset = 0.125 x D Offset = 0.125 x 600 Offset = 75 NOTE...

  • Page 7: Specification

    GEARBOX & AGITATOR ONLY - IEC 71 'D' B5 PART NUMBER - QS-ESXXXXXXA DIMENSIONS FOR DETAILS OF GEARBOX, SEE MANUFACTURER'S MANUAL FOR DETAILS OF AGITATOR, SEE QS-5016S SERVICE MANUAL SPECIFICATION 0.37 kW [0.5 hp] MAX. POWER MAX. OUTPUT TORQUE 25.6 Nm [226.6 lb-in] MINIMUM SPEED 0 RPM 216 RPM...
  • Page 8 GEARBOX & AGITATOR ONLY - NEMA 56C PART NUMBER - QS-ESXXXXXXB DIMENSIONS FOR DETAILS OF GEARBOX, SEE MANUFACTURER'S MANUAL FOR DETAILS OF AGITATOR, SEE QS-5016S SERVICE MANUAL NOTE THIS UNIT IS NOT FOR SALE IN EUROPE AND THEREFORE IS EXCLUDED FROM THE DECLARATION OF CONFORMITY SPECIFICATION MAX.
  • Page 9 ELECTRIC FIXED SPEED AGITATOR - IEC71 'D' B5 PART NUMBER - QS-ESXXXXXXC DIMENSIONS FOR DETAILS OF DRIVE UNIT, SEE MANUFACTURER'S MANUAL FOR DETAILS OF GEARBOX, SEE MANUFACTURER'S MANUAL FOR DETAILS OF AGITATOR, SEE QS-5016S SERVICE MANUAL SPECIFICATION PROTECTION LEVEL II 2G Ex db eb IIC T4 Gb MAX.
  • Page 10 ELECTRIC INVERTER DRIVE AGITATOR - IEC 71 'D' B5 PART NUMBER - QS-ESXXXXXXD DIMENSIONS FOR DETAILS OF DRIVE UNIT, SEE MANUFACTURER'S MANUAL FOR DETAILS OF GEARBOX, SEE MANUFACTURER'S MANUAL FOR DETAILS OF AGITATOR, SEE QS-5016S SERVICE MANUAL SPECIFICATION PROTECTION LEVEL II 2G Ex db/eb IIC T4 Gb MAX.
  • Page 11 ELECTRIC VARIATOR DRIVE AGITATOR - IEC 71 'D' B5 PART NUMBER - QS-ESXXXXXXE DIMENSIONS FOR DETAILS OF DRIVE UNIT, SEE MANUFACTURER'S MANUAL FOR DETAILS OF VARIATOR, SEE MANUFACTURER'S MANUAL FOR DETAILS OF GEARBOX, SEE MANUFACTURER'S MANUAL FOR DETAILS OF AGITATOR, SEE QS-5016S SERVICE MANUAL 11/24 77-3318 R1.1...
  • Page 12 ELECTRIC VARIATOR DRIVE AGITATOR - IEC 71 'D' B5 PART NUMBER - QS-ESXXXXXXE SPECIFICATION PROTECTION LEVEL II 2G Ex db/de IIC T4 Gb MAX. POWER 0.37 kW [0.5 hp] MAX. OUTPUT TORQUE 18.4 Nm [162.9 lb-in] MINIMUM SPEED 40 RPM @ 50Hz MAXIMUM SPEED 229 RPM @ 50Hz GEARBOX RATIO...
  • Page 13 ELECTRIC VARIATOR DRIVE AGITATOR - NEMA 56C PART NUMBER - QS-ESXXXXXXF DIMENSIONS FOR DETAILS OF DRIVE UNIT, SEE MANUFACTURER'S MANUAL FOR DETAILS OF VARIATOR, SEE MANUFACTURER'S MANUAL FOR DETAILS OF GEARBOX, SEE MANUFACTURER'S MANUAL FOR DETAILS OF AGITATOR, SEE MANUFACTURER'S MANUAL NOTE THIS UNIT IS NOT FOR SALE IN EUROPE AND THEREFORE IS EXCLUDED FROM...
  • Page 14 ELECTRIC VARIATOR DRIVE AGITATOR - NEMA56C PART NUMBER - QS-ESXXXXXXF SPECIFICATION MAX. POWER 0.37 kW [0.5 hp] MAX. OUTPUT TORQUE 18 Nm [159.3lb-in] MINIMUM SPEED 12 RPM @ 60Hz MAXIMUM SPEED 285 RPM @ 60Hz GEARBOX RATIO 2.62:1 MAX. WEIGHT OF UNIT 41 Kg [90.4 lbs] GEARBOX OIL VOLUME 1.4 Litres...
  • Page 15 PNEUMATIC DRIVE AGITATOR - STANDARD - IEC 71 'D' B5 PART NUMBER - QS-PSXXXXXXK DIMENSIONS FOR DETAILS OF DRIVE UNIT, SEE MANUFACTURER'S MANUAL FOR DETAILS OF GEARBOX, SEE MANUFACTURER'S MANUAL FOR DETAILS OF AGITATOR, SEE QS-5016S SERVICE MANUAL 15/24 77-3318 R1.1 www.carlisleft.com...
  • Page 16 PNEUMATIC DRIVE AGITATOR - STANDARD - IEC 71 'D' B5 PART NUMBER - QS-PSXXXXXXK SPECIFICATION PROTECTION LEVEL II 2GD Exh IIC T4 Gc IIIC T135°C Dc MAX. POWER 0.37 kW [0.5 hp] MAX. OUTPUT TORQUE 2.8 Nm [24.8 lb-in] MINIMUM SPEED 0 RPM MAXIMUM SPEED 216 RPM...
  • Page 17 PNEUMATIC DRIVE AGITATOR - LONG LIFE - IEC 71 'D' B5 PART NUMBER - QS-PSXXXXXXL DIMENSIONS FOR DETAILS OF DRIVE UNIT, SEE MANUFACTURER'S MANUAL FOR DETAILS OF GEARBOX, SEE MANUFACTURER'S MANUAL FOR DETAILS OF AGITATOR, SEE QS-5016S SERVICE MANUAL 17/24 77-3318 R1.1 www.carlisleft.com...
  • Page 18 PNEUMATIC DRIVE AGITATOR - LONG LIFE - IEC 71 'D' B5 PART NUMBER - QS-PSXXXXXXL SPECIFICATION PROTECTION LEVEL II 2GD c T6 T85°C X 0.41 kW [0.55 hp] MAX. POWER MAX. OUTPUT TORQUE 3.3 Nm [29.2 lb-in] MINIMUM SPEED 0 RPM MAXIMUM SPEED 216 RPM GEARBOX RATIO...

  • Page 19: Spare Parts

    SPARE PARTS PART NO. DESCRIPTION IEC71 GEARBOX QSK-030 IEC71 GASKET IEC COUPLING DIPSTICK GEARBOX OIL [ 1 LITRE ] QSK-031 OIL SUCTION GUN DIPSTICK QSK-032 IEC COUPLING QSK-033 IEC71 GASKET NEMA 56C GEARBOX QSK-040 NEMA 56C GASKET NEMA COUPLING QSK-041 NEMA COUPLING 19/24 77-3318 R1.1...
  • Page 20 SPARE PARTS - CONTINUED PART NO. DESCRIPTION QSK-042 NEMA 56C GASKET QSK-050 MOTOR AND GEARBOX QSK-060 MOTOR, VARIATOR AND GEARBOX QSK-061 VARIATOR TRACTION LUBRICANT [1 LITRE] (FOR VARIATOR ONLY) AIR MOTOR - STANDARD QSK-070 1/4" INLET RESTRICTOR 1/4" MUFFLER R1/4" MUFFLER (FITS AIR MOTOR - STANDARD) QSK-071 20/24...
  • Page 21 SPARE PARTS - CONTINUED PART NO. DESCRIPTION QSK-072 1/4" INLET RESTRICTOR (FITS AIR MOTOR - STANDARD) QSK-073 AIR ADJUSTING VALVE AND GAUGE QSK-080 AIR MOTOR- LONG LIFE G3/8" INLET RESTRICTOR R1" HIGH NOISE REDUCTION SILENCER NOISE REDUCTION FELT QSK-081 G1/2" x G1" FEMALE UNEQUAL SOCKET R1/2"...
  • Page 22 SPARE PARTS - CONTINUED PART NO. DESCRIPTION NOISE REDUCTION FELT (KIT OF 5) (FITS AIR MOTOR - LONG LIFE) QSK-084 QSK-090 MOTOR AND GEARBOX QSK-100 MOTOR, VARIATOR AND GEARBOX 22/24 77-3318 R1.1 www.carlisleft.com...
  • Page 23 NOTES 23/24 77-3318 R1.1 www.carlisleft.com...

  • Page 24: Warranty Policy

    WARRANTY POLICY This product is covered by Carlisle Fluid Technologies’ materials and workmanship limited warranty. The use of any parts or accessories, from a source other than Carlisle Fluid Technologies, will void all warranties. Failure to reasonably follow any maintenance guidance provided, may invalidate any warranty.
