User Manual - TRANSLATION
POLARIS REMOTE
POLARIS Remote KVM Analog 15" / 19.1"
Type 17-71V2-....
ATEX / IECEx / CSA
Zone 1 and Zone 21
Document no. 11-71V2-7D0010 / 236279
Status: 02 August 2019
Reservation: 3 Technical data subject to change without notice. Changes, errors
and
misprints may not be used as a basis for any claim for damages.
GmbH
Max-Eyth-Straße 16
97980 Bad Mergentheim
GERMANY
Content
English
Phone: +49 7931 597-0
Fax: +49 7931 597-119
Pages
1-50
Support:
support-polaris@bartec.de
Download:
http://automation.bartec.de
Internet:
www.bartec.de

Advertisement

Table of Contents
loading

Related Manuals for Bartec POLARIS Remote KVM Analog Series

Summary of Contents for Bartec POLARIS Remote KVM Analog Series

  • Page 1 Reservation: 3 Technical data subject to change without notice. Changes, errors misprints may not be used as a basis for any claim for damages. Content Pages English 1-50 GmbH Max-Eyth-Straße 16 Phone: +49 7931 597-0 Support: support-polaris@bartec.de 97980 Bad Mergentheim Fax: +49 7931 597-119 Download: http://automation.bartec.de GERMANY Internet: www.bartec.de...
  • Page 3 POLARIS REMOTE - for Zone 1/21 Table of Contents POLARIS Remote KVM Analog 15" / 19.1" Technical data subject to change. 08/2019...

  • Page 4: Table Of Contents

    POLARIS REMOTE - for Zone 1/21 Table of Contents POLARIS Remote KVM Analog 15" / 19.1" Basic safety instructions ........................1 Notes on this manual ........................ 1 1.1.1 Languages ........................2 1.1.2 Changes in the document ..................... 2 Handling the product ......................... 2 Intended use ..........................
  • Page 5 6.6.3 Terminal assignment LSA-Plus terminal (X13-X20) ........... 28 Ex i terminal compartment ...................... 28 6.7.1 Connection of Ex i keyboard to the POLARIS (optional) ..........29 6.7.2 Connection of a BARTEC BCS 160 series (optional) ..........30 Local unit for STP cable ......................31 6.8.1 Technical data of local unit ..................
  • Page 7 Blank...

  • Page 9: Basic Safety Instructions

    The BARTEC company reserves the right to carry out technical changes at any time. In no event will BARTEC company be responsible or liable for indirect or consequential damages resulting from the use or application of this user manual.

  • Page 10: Languages

    It is used exclusively in combination with operating devices which satisfy the requirements for Overvoltage Category I. The POLARIS REMOTE KVM Analog series have been designed specially for use in hazardous (potentially explosive) areas in Zone 1 or Zones 21.

  • Page 11: Unintended Use

    POLARIS REMOTE - for Zone 1/21 Basic POLARIS Remote KVM Analog 15" / 19.1" safety instructions 1.3.2 Unintended use Any other use is not in accordance with the intended purpose and can cause damage and accidents. The manufacturer will not be liable for any use beyond that of its Exclusive II intended purpose.

  • Page 12: Servicing

    The device features an explosion protection label, as well as a test certificate. For an explanation of the symbols and information used, see chapter 4 "Technical data". The POLARIS REMOTE KVM Analog series complies with Directive 2014/34/EU on equipment and protective systems intended for use in potentially explosive atmospheres (ATEX Directive).
  • Page 13 BARTEC grants a warranty period of one year on the POLARIS series, starting from the BARTEC delivery date. The warranty period for accessories is 1 year from the date of delivery. This warranty covers all parts of the delivery and is limited to the free-of- charge replacement of or repair of the defective parts by BARTEC.

  • Page 14: Product Description

    Illustration 2: e.g. local unit with STP cable The POLARIS Remote KVM Analog series is optimised for signals such as VGA and PS/2 (USB via adapter). A local monitor, a keyboard and a mouse can be connected via "VGA/PS2 Out".

  • Page 15: System Design

    Intrinsically safe keyboards in various national languages, and mouse, trackball, joystick and touchpad as front-panel installation are available. A resistive (intrinsically safe) touch screen and the connection of a BARTEC hand-held scanner are optional possibilities. The intrinsically safe input devices are supplied through barriers which are also integrated in the POLARIS Remote.

  • Page 16: Explosion Protection And Approvals

    Explosion protection and POLARIS REMOTE - for Zone 1/21 approvals POLARIS Remote KVM Analog 15" / 19.1" Explosion protection and approvals POLARIS Remote KVM Analog Type 17-71V2-…. ATEX II 2G Ex db eb mb q [ib op pr] IIC T4 Gb Ex protection type II 2D Ex mb tb IIIC T120°C Db -20 °C ≤...
  • Page 17 Korea KTL 14-KB4BO-0258X India CCEs P261984 China NEPSI GYJ18.1382X America CSA 70010166 More test certificates www.bartec.de EU-conformity RoHS-Directive 2011/65/EU Standards in accordance with EN/IEC 61000-6-2:2005 EMC Directive 2014/30/EU EN 61000-6-4:2007 + A1:2011 IEC 61000-6-4:2006 + A1:2010 EN 60529:1991 + A1 2000 + A2 :2013...

  • Page 18: Technical Data

    POLARIS REMOTE - for Zone 1/21 Technical data POLARIS Remote KVM Analog 15" / 19.1" Technical data POLARIS Remote KVM Analog 4.1.1 General data Construction Front panel fitting; Optional turn-key system solutions in a stainless steel enclosure as wall, floor or table mounting versions. Connection to the PC Connection directly to VGA, PS/2 keyboard and PS/2 mouse, optionally RS232 interface for touch...

  • Page 19: Characteristics Polaris Remote Kvm Analog 15

    POLARIS REMOTE - for Zone 1/21 Technical data POLARIS Remote KVM Analog 15" / 19.1" 4.1.2 Characteristics POLARIS Remote KVM Analog 15″ Display 15" graphics-capable TFT display XGA resolution 1024 x 768 pixels 262,144 colours Brightness 350 cd/m2 Visible surface approx.

  • Page 20: Keyboard

    Class I, Zone 1 (A)Ex ib IIC T4; Gb Class II, Zone 21 (A)Ex ib IIIC T120 °C; Db Certification CSA 15.70010166 More test certificates www.bartec.de 4.2.2 General data Construction Front panel fitting Polyester foil on aluminium sheet Material (conditionally UV-resistant)

  • Page 21: Characteristics Enclosure For Keyboard

    IECEx IBE 11.0007X Ex protection type Class I, Zone 1 (A)Ex ib IIC T4; Gb Class II, Zone 21 (A)Ex ib IIIC T120 °C; Db Certification CSA 15.70010166 More test certificates www.bartec.de Technical data subject to change. EN 13/48 08/2019...

  • Page 22: General Data

    POLARIS REMOTE - for Zone 1/21 Technical data POLARIS Remote KVM Analog 15" / 19.1" 4.3.2 General data Construction Front panel fitting Material Polyester foil on aluminium sheet (conditionally UV-resistant) Protection class Fingermouse/Joystick/Touchpad IP65 front site Trackball Static IP65 front site Dynamic IP51 front site...

  • Page 23: Product Labelling

    POLARIS REMOTE - for Zone 1/21 Technical data POLARIS Remote KVM Analog 15" / 19.1" Product labelling Example: ATEX type label IMMETRO type label Warnings on the device Warning on terminal compartment! Test sticker Technical data subject to change. EN 15/48 08/2019...

  • Page 24: Transport, Storage, Scope And Assembly

    A written report of any transport damage or missing items must be given to the appointed forwarder and to BARTEC GmbH immediately on receipt of the delivery. Damage caused by incorrect storage and transport shall not fall within the warranty provisions of BARTEC GmbH.

  • Page 25: Assembly

    POLARIS REMOTE - for Zone 1/21 Transport, storage, POLARIS Remote KVM Analog 15" / 19.1" scope and assembly Assembly Before assembling the device, make sure you have all the components and documents. Required Tools POLARIS (mounting clamps) 1 x hex key 3 mm 1 x slotted screwdriver POLARIS termination-compartments 1 x hex key 2,5 mm...

  • Page 26: Installation

    POLARIS REMOTE - for Zone 1/21 Installation POLARIS Remote KVM Analog 15" / 19.1" Installation We recommend setting up and testing the entire system before its ultimate installation in the ex-area. If a long connection cable is not available, please use a patch cable to test the basic functions.

  • Page 27: Mechanical Installation

    POLARIS REMOTE - for Zone 1/21 Installation POLARIS Remote KVM Analog 15" / 19.1" Do not mount in direct proximity to switching or current changing devices. – Only install the POLARIS in conjunction with the reinforcement frame in an IP65 –...
  • Page 28 POLARIS REMOTE - for Zone 1/21 Installation POLARIS Remote KVM Analog 15" / 19.1" DANGER If there is no reinforcement frame, it will not be possible to maintain the IP protection. There is a risk of fatal injury in an explosive atmosphere! Only use enclosure with at least 2 mm wall thickness.

  • Page 29: Installation As A System Solution In The Stainless Steel Enclosure "Exclusive Ii

    POLARIS REMOTE - for Zone 1/21 Installation POLARIS Remote KVM Analog 15" / 19.1" 6.2.2 Installation as a system solution in the stainless steel enclosure "Exclusive II" The POLARIS is available as a ready-made system solution in a stainless steel enclosure e.g.

  • Page 30: Floor Mounting (Stainless Steel Enclosure "Exclusive Ii")

    POLARIS REMOTE - for Zone 1/21 Installation POLARIS Remote KVM Analog 15" / 19.1" 6.2.3 Floor mounting (Stainless steel enclosure "Exclusive II") Illustration 7: Drilling pattern - supporting system for floor mounting 6.2.4 Wall mounting (Stainless steel enclosure "Exclusive II") Illustration 8: Drilling pattern - supporting system for floor mounting Technical data subject to change.
  • Page 31 POLARIS REMOTE - for Zone 1/21 Installation POLARIS Remote KVM Analog 15" / 19.1" 6.2.5 Table mounting swivel/tilt (Stainless steel enclosure "Exclusive II") CAUTION Movable enclosure parts on the swivel-mounted enclosure. There is a risk of injury by hands being crushed. 3 people are needed for assembly/disassembly.

  • Page 32: Electrical Installation

    POLARIS REMOTE - for Zone 1/21 Installation POLARIS Remote KVM Analog 15" / 19.1" Electrical installation 6.3.1 Installation guidelines Only qualified personnel, i.e. trained electricians will have the required specialised knowledge to be able to do all the electrical work. Familiarity with and the technically perfect implementation of the safety instructions described in this manual are preconditions for safe installation and commissioning.

  • Page 33: Terminal Compartments

    POLARIS REMOTE - for Zone 1/21 Installation POLARIS Remote KVM Analog 15" / 19.1" Terminal compartments DANGER Sealed locking screw! The device is closed in the factory. The explosion protection is lost if opened, and danger to life exists in an explosive atmosphere! Do not open the locking screw! DANGER...

  • Page 34: Pe Conductor Connection

    POLARIS REMOTE - for Zone 1/21 Installation POLARIS Remote KVM Analog 15" / 19.1" PE conductor connection DANGER Death or danger of injury as a result of no PE conductor connection. There is no explosion protection. Equipotential bonding with a core cross-section of at least 4 mm is to be set up for the POLARIS (see figure).

  • Page 35: Ex E Terminal Compartments

    POLARIS REMOTE - for Zone 1/21 Installation POLARIS Remote KVM Analog 15" / 19.1" Ex e terminal compartments 6.6.1 Cable entries When connecting cables and leads to supplies / communications equipment in increased safety protected areas, Ex certified cable entries must be used which are suitable for each type of cable and lead.

  • Page 36: Terminal Assignment Lsa-Plus Terminal (X13-X20)

    RS 232 (Optional for Power module BCS 3600) Klemme Schnittstelle Signal Power Module for BCS 3600 X 21 Not connected X 22 Input X5 (TxD) X 23 Output X6 (RxD) X 24 More information: http://automation.bartec.de/scannerE.htm Technical data subject to change. EN 28/48 08/2019...

  • Page 37: Ex I Terminal Compartment

    POLARIS REMOTE - for Zone 1/21 Installation POLARIS Remote KVM Analog 15" / 19.1" Ex i terminal compartment Do not connect the keyboard, mouse, trackball, touchpad, joystick or the hand scanner while the power supply is active. DANGER Accessories which have not been approved jeopardise the explosion protection. Danger to life exists in an explosive atmosphere! Only use POLARIS accessories! The cover for the Ex i terminal compartment need not be used when deploying a...

  • Page 38: Connection Of A Bartec Bcs 160

    55.8 µF The hand scanner BCS 160 series can only be used with the original connection cable from BARTEC. Hand scanner BCS 160 with 1D/2D imager (type 17-21BA- M31S/I0000000) is not compatible. Connection cable to Barcode hand scanner BCS 160...

  • Page 39: Local Unit For Stp Cable

    POLARIS REMOTE - for Zone 1/21 Installation POLARIS Remote KVM Analog 15" / 19.1" Local unit for STP cable The local unit is used in connection with the POLARIS Remote KVM Analog. Please read the enclosed manufacturer’s manual and also observe the warnings given by the manufacturer.

  • Page 40: Emc (Electromagnetic Compatibility)

    POLARIS REMOTE - for Zone 1/21 Installation POLARIS Remote KVM Analog 15" / 19.1" EMC (Electromagnetic compatibility) This is a class A unit and can cause radio interference in residential areas; if it does, the owner/managing operator may be required to implement suitable measures and pay for loss or damage.

  • Page 41: Back-Up Fuse

    1000A@250VAC We recommend that the POLARIS is secured with a back-up fuse to avoid triggering the internal fuse in the device. The internal fuse can only be replaced by BARTEC. Back-up fuse AC: 1.6 A slow-blowing (since June 2015: 2.5 A) DC: 4 A quick-blowing.

  • Page 42: Shielding

    POLARIS REMOTE - for Zone 1/21 Installation POLARIS Remote KVM Analog 15" / 19.1" 6.9.4 Shielding Only cables with braided shielding should be used – (recommended cover density > 80%). Sheet shielding should not be used. – Generally, connection of the shielding at both ends results in optimum damping of all –...
  • Page 43 POLARIS REMOTE - for Zone 1/21 Installation POLARIS Remote KVM Analog 15" / 19.1" Single-sided shield connection on the connecting cables Illustration 13: Example of single-sided shield connection Connection of the shielding at one end only is recommended when there is inadequate equipotential bonding, or none at all.

  • Page 44: Commissioning

    POLARIS REMOTE - for Zone 1/21 Inbetriebnahme POLARIS Remote KVM Analog 15" / 19.1" Commissioning For electrical systems the relevant installation and operating specifications (e.g. Directives 2014/34/EU, BetrSichV and the applicable national ordinances, IEC 60 079-14 and the DIN VDE 0100 series) must be observed. The operator of an electrical system in a hazardous environment must keep the operating equipment in an orderly condition, operate it correctly, monitor it and do the required maintenance and repairs.

  • Page 45: Operation

    POLARIS REMOTE - for Zone 1/21 Operation POLARIS Remote KVM Analog 15" / 19.1" Operation The POLARIS series does not have any ON/OFF switch. The device can be put into operation after the final check has been made. Putting into operation for the first time Compatibility The system was tested with different devices.

  • Page 46: Display Settings

    The touch driver for the respective operating system must be installed on the local server or PC. There is also the option of downloading the touch screen software from http://automation.bartec.de/ After installation, the touch screen must be calibrated. The transmission is made via the RS232 interface.

  • Page 47: Faults And Troubleshooting

    Check serial interface - check interface for function Wrong driver installed Driver installation for serial interface is necessary Mouse pointer on screen www.automation.bartec.de and Touch point on screen Touchscreen wrong or not calibrate calibrate touchscreen are not the same Display show "Out of...

  • Page 48: Maintenance, Inspection, Repair

    Wartung, Inspektion, POLARIS REMOTE - for Zone 1/21 Reparatur POLARIS Remote KVM Analog 15" / 19.1" Maintenance, inspection, repair Only trained and qualified personnel may commission and do maintenance work on the POLARIS! Trained qualified personnel are people who are familiar with the installation, assembly, commissioning and operation of the POLARIS, have been instructed about the risks and have the appropriate qualifications by virtue of the work they do.

  • Page 49: Instructions For Repairs

    Then fill in and sign the RMA (Return Merchandise Authorisation) form and send it to our "Retouren Center". E-Mail: services@bartec.de Fax: +49 7931 597-119 We cannot guarantee any contractually agreed processing times for devices that are sent in without an RMA number.

  • Page 50: Accessories, Spare Parts

    CAT.7 4x2x23 AWG, outer diameter: 7.9 mm 02-4082-0002 CAT.7 4x2x22 AWG, outer diameter: 18 mm; armoured 02-4082-0004 BCS 160 BARTEC hand scanner 17-21BA-M3.S.-…… Connection cable for BARTEC hand scanner on request Original packing POLARIS 15" 04-9035-0007 POLARIS 19.1" 04-9035-0008 Local unit...

  • Page 51: Order Numbers

    POLARIS REMOTE - for Zone 1/21 Order numbers POLARIS Remote KVM Analog 15" / 19.1" Order numbers POLARIS Remote KVM Analog 15" POLARIS Remote KVM Analog 19.1" Technical data subject to change. EN 43/48 08/2019...

  • Page 52: Additional Information

    POLARIS REMOTE - for Zone 1/21 Additional information POLARIS Remote KVM Analog 15″ and 19.1″ Additional information Technical data subject to change. EN 44/48 08/2019...
  • Page 53 POLARIS REMOTE - for Zone 1/21 Additional information POLARIS Remote KVM Analog 15" / 19.1" Mounting instructions Class D/E, CAT 6 Outlet 1. Preperation of the Cable Ends Remove cable sheathing approx. 50 mm in length. Cut back overall screen to approximate 15 mm, remove twisted pair screen as required.
  • Page 54 POLARIS REMOTE - for Zone 1/21 Additional information POLARIS Remote KVM Analog 15″ and 19.1″ Mounting instructions Class D/E, CAT 6 Outlet 4. Wire connection Connect the connecting blocks with the LSA-Plus tool. The twist should only be opened sufficiently to connect (max.

  • Page 55: Declaration Of Conformity

    POLARIS REMOTE - for Zone 1/21 EU Declaration of POLARIS Remote KVM Analog 15" / 19.1" conformity Declaration of conformity Technical data subject to change. EN 47/48 08/2019...
  • Page 56 EU Declaration of POLARIS REMOTE - for Zone 1/21 conformity POLARIS Remote KVM Analog 15" / 19.1" All certificates see www.bartec.de Technical data subject to change. EN 48/48 08/2019...
