  • Page 1 Tesano Monitor Table Installation Instructions...

  • Page 2: Before Beginning Installation

    Before Beginning Installation • Read through the entire instruction thoroughly • A minimum of 1-2 persons is required for this assembly • These instructions reflect typical assemblies. They may not match your specific configuration.

  • Page 3: Required Tools

    Required Tools • Drill Driver • #6 Hex Drill Bit • Phillips Bit • Bit Extender • Level...
  • Page 4 Provided Hardware HW0543 HW0747 HW3774 HW0666 HW2248 HW0615...
  • Page 5 Tesano Monitor Table...
  • Page 6 Tesano Monitor Table Exploded Monitor Panel Column Base Beams Wire Management Wood Rails Apron...
  • Page 7 Step 1: Center Column and Beams • Place column in desired location. Secure the support beams in place with fHW0543 screws and HW3774 washers. • Have a person or item to support the other end of the beams. • NOTE: The beam ends that match with the column brackets are labeled.

  • Page 8: Step 2: Monitor Panel

    Step 2: Monitor Panel • Prop up the monitor panel to be in line with the support beams. • Slide beams into brackets and secure with HW2248. • NOTE: DO NOT tighten screws, but keep loose.
  • Page 9 Step 3: Top • Place top on to support beams. – Keep the end of the top tight to the monitor wall, no gap. – Flush the sides of the top to the sides of the monitor wall. Flush • Secure the top to the support, by inserting HW0615 screws through the support beams into the wood rails.
  • Page 10 Step 4: Level Monitor Panel • Level the monitor panel to be straight. • It is easy for the panel to veer left or right so be sure it is at a right angle to the top. • Now tighten the fasteners from earlier that attach the monitor panel to the support beams.
  • Page 11 Step 5: Rails and Aprons Then add the aprons by securing with HW through the metal channel into the wood rail.
  • Page 12 Step 6: Electrical • The duplexes will already be attached to the support beams. Front Panel • Connect the “U” shaped jumper to connect the two duplexes. • Connect the infeed wire to one of the duplexes, and the other end will run out through the column base.
