- Page 1 Two4Six Freestanding Table Installation Instructions...
-
Page 2: Before Beginning Installation
Before Beginning Installation • Read through the entire instruction thoroughly • A minimum of 2 persons is required for this assembly • These instructions reflect typical assemblies. They may not match your specific configuration. -
Page 3: Required Tools
Required Tools • Drill Driver • #2 and #3 Phillips Bit • Level... - Page 4 Top Shapes Rectangle Soft Rectangle...
- Page 5 Step 1: Open Frame Setup • Align the holes in the top plate of the open frame base to the two predrilled holes in the table top. • Be sure the “T” shape of the base are as shown below. •...
- Page 6 Step 2: Modesty Attachment • Attach the modesty at the 2 predrilled locations. • Once these 2 fasteners are tightened, insert remaining HW0747 fasteners into the modesty bracket. • NOTE: DO NOT overtighten the screws as this may damage the top.
- Page 7 Step 3: Level Table • Place level on top, running along the length of the top. • Check for levelness and extend or retract glides as needed. • Repeat the above procedure along the width of the top. • Double check both directions. •...
- Page 8 Step 4: Installing Power Rails (If applicable) • Insert thumbscrews into predrilled holes on the bottom of the table top. • Part can be attached at ends or along the length of the table. • Additionally the power rail can be adjusted toward or away from the edge of the table.
- Page 9 Step 5: Pencil Caddy (if applicable) • Secure the pencil caddy by securing the black steel plate to the top. • The tray will need to be rotated to secure all 4 screws. • The pencil caddy can be installed to the customer’s preference (HW0741).
