Summary of Contents for Nucraft Tavola
- Page 1 Tavola Table Installation Instructions...
-
Page 2: Before Beginning Installation
Before Beginning Installation • Read through the entire instruction thoroughly • A minimum of 2 persons is required for this assembly • These instructions reflect typical assemblies. They may not match your specific configuration. -
Page 3: Required Tools
Required Tools • Drill Driver • #2 and #3 Phillips Bit • 7MM Hex Bit • ½” Open Face Wrench • 3/8” Wrench • 7/16” Wrench • Laser Level • PODS for glass handling... -
Page 4: Required Hardware
Required Hardware Hardware 1 Hardware 6 Hardware 2 Hardware 7 Hardware 3 Hardware 8 Hardware 4 Hardware 9 Hardware 5... - Page 5 Tavola Conference Table • Point 1 • Point 2 • Point 3...
- Page 6 Tavola Conference Table Exploded Table Base Glass Ender Glass Center 1-1/2” Sub Top Center Perimeter Extrusion Table Spine Glass Spine Power Trim Perimeter End 10. Sub Tops for Center 11. Top Plate for Connecting Bases 12. Support Tubes...
- Page 7 Step 1: Assembling Bases • If your table has a single base, skip to step 3. • Set the two base sections in line. • Use hardware 2 between the bases, and connect with hardware 3 and 4.
- Page 8 Step 2: Attaching Mounting Plate • Place hardware #1 on bases as shown. • Position hardware #9 in line with through holes. • Attach using hardware #7. • Repeat on the opposite side. • Position the table in it’s final location and level.
- Page 9 Step 3: Installing the Sub Top • Set the sub-top on the bases. Position the recessed pockets on the underside of the top, over corresponding base plated. • If sub top is multiple pieces, connect with rod and tube as shown. •...
- Page 10 Step 4: Installing Extrusions • Install the extrusions around the perimeter of the sub-top. Start on one end work to the other (labeled for correct order). • Extrusions are slid together using the pins to align. Tighten using set screws. •...
- Page 11 Step 5: Installing Center Spine and Sub-Tops • Install the center spine extrusions • These extrusions are designed to “float” in place. • Install the sub-panels (for glass tops) using hardware #5 • Make sure extrusions are tight to the sub panels before securing.
- Page 12 Step 6: Installing Veneer and Glass Panels • Install the veneer panels in place per labeling. • Fasten the veneer panels from the underside of table using hardware #6. – Use caution to not overtighten the bolt. Use a hand Allen wrench only •...
