Electrical Tray - CMA Dishmachines CMA-180UC Parts Manual

1.4.3. Electrical Tray

ITEM NO.
P/N
NO. REQ'D
1 1 14504.00 Electrical Tray for CMA-180UC
2 1 14408.80 Timer Assy 4 Cam 2 Min. CMA-180UC
3 1 15504.00 Motor Contactor, 2-Pole 20 Amp
4 1 15504.50 Heater Contactor, 2-Pole 35 Amp
5 1 15520.50 Power Block, 3-Position
6 2 00438.00 Snap Bushing, Universal
7 2 01001.00 6-32 x 1" Panhead Screw
MODEL CMA-180UC PARTS MANUAL Rev. 1.14
DESCRIPTION
Parts Manual
ITEM NO.
P/N
NO. REQ'D
8 12 00927.00 8-32 Nylon Lock Nut
9 1 13426.60 Ground Block
10 2 00965.00 6-32 Lock Nut
11 1 00401.85 3/4" Conduit Connector, Straight
12 9 00400.85 3/4" Conduit, Sealtite
13 1 13304.61 HT Plumbing Bracket
DESCRIPTION
Page 9
