MODEL C MA-180UC-3
INSTALLATION
COMMERCIAL WAREWASHING
EQUIPMENT*
NSF/ANSI 3
<SA45466>
C M A D I S H M A C H I N E S
1 2 7 0 0 K N O T T S T R E E T
GARDEN GROVE, CALIFORNIA 92841
8 0 0 - 8 5 4 - 6 4 1 7
F A X 7 1 4 - 8 9 5 - 2 14 1
Owner's Manual
Rev 1.00C 01-01-24
www.cmadishmachines.com
&
OPERATION
Advertisement
Related Manuals for CMA Dishmachines CMA-180UC-3
Summary of Contents for CMA Dishmachines CMA-180UC-3
- Page 1 Owner’s Manual MODEL C MA-180UC-3 & INSTALLATION OPERATION Rev 1.00C 01-01-24 COMMERCIAL WAREWASHING EQUIPMENT* NSF/ANSI 3 <SA45466> C M A D I S H M A C H I N E S 1 2 7 0 0 K N O T T S T R E E T GARDEN GROVE, CALIFORNIA 92841 8 0 0 - 8 5 4 - 6 4 1 7 F A X 7 1 4 - 8 9 5 - 2 14 1...
-
Page 2: Specifications
THIS SYSTEM REQUIRES TWO POWER WIRES, NO NEUTRAL NEEDED. AN ADDITIONAL THIRD WIRE MUST BE PROVIDED FOR MACHINE GROUND. GFCI BREAKER IF REQUIRED. SHIPPING WEIGHT 234# (106 kg) * For faster heat recovery. ** Plus 7 seconds load time. MODEL CMA-180UC-3 INSTALLATION & OPERATION MANUAL Rev. 1.00 Page... - Page 3 (by others). If flowing pressure is lower than 15 psi, improper machine operation may result. CMA-180UC-3 Operational Cycle The CMA-180UC-3 Operational Cycle has a total cycle time of 2 minutes (120 seconds). The steps listed below detail the individual functions that are executed during each Operational Cycle.
-
Page 4: Customer Notice
Ground) extending out of the conduit are provided for easily connecting the power at installation. CMA recommends a minimum 40-amp dedicated circuit, you should consult your local building code requirements for proper breaker size. MODEL CMA-180UC-3 INSTALLATION & OPERATION MANUAL Rev. 1.00 Page... -
Page 5: Getting Started
180°F final rinse water each cycle. The supply water to the CMA-180UC-3 must be a minimum of 120°F at 24 PSI (Pounds per Square Inch) with a 6 GPM (Gallons per Minute) flow rate and 60 GPH (Gallons per Hour) recovery rate. -
Page 6: Receiving And Installation
The supply water to the CMA-180UC-3 must be a minimum of 120°F at 24 PSI (Pounds per Square Inch) with a 6 GPM (Gallons per Minute) flow rate and 60 GPH (Gallons per Hour) recovery rate. - Page 7 Warning: If water pressure exceeds 50 PSI, pressure reducing valve (PRV) is recommended. The CMA-180UC-3 is manufactured with a pumped drain. The drain pump can not be removed. Caution: CMA recommends utilizing a water softening system to maintain water hardness measurements of 3.5 gpg (grains per gallon) or less.
-
Page 8: Installers Checklist
Drain hose is installed with air gap (discharge 1” above drain) Dishmachine is properly grounded Dishmachine is properly leveled Machine circuit breaker is labeled “DISHWASHER” Machine has been “hard-wired” with correctly sized wire MODEL CMA-180UC-3 INSTALLATION & OPERATION MANUAL Rev. 1.00 Page... -
Page 9: Operation
8. To prime chemical dispensers press and hold down the prime switch until product is discharging into machine. 9. Drain machine and power machine off at end of day. Rinse cycle temperature must be observed during a rinse cycle while the machine is in operation. MODEL CMA-180UC-3 INSTALLATION & OPERATION MANUAL Rev. 1.00 Page...
