Cut charts
220936* / 220935**
420737
Metric
Plasma Cutflow
7.6 m 15.3 m 22.9 m 30.5 m
Lead Lead Lead Lead
68 69 70 71
English
Plasma Cutflow
25 ft 50 ft 75 ft 100 ft
Lead Lead Lead Lead
68 69 70 71
*with IHS tab / **without IHS tab
22
Mild steel
O2 Plasma / Air Shield
200 A Extreme bevel cutting
420733
Shield Cutflow
7.6 m 15.3 m 22.9 m 30.5 m
Lead Lead Lead Lead
48 50 54 58
Shield Cutflow
25 ft 50 ft 75 ft 100 ft
Lead Lead Lead Lead
48 50 54 58
420732
220488
Effective Arc Cut
Thickness Voltage Height
mm Volts mm
139 1.5
6
143 3.4
8
148 4.6
10
146 3.8
12
145 3.1
15
146 3.0
20
146 3.2
25
153 3.1
32
160 4.4
38
166 4.4
44
171 4.4
50
Effective Arc Cut
Thickness Voltage Height
in Volts in
137 0.100
.25
151 0.190
.375
147 0.140
0.50
147 0.120
0.625
148 0.120
.75
148 0.130
.875
148 0.130
1.00
155 0.130
1.25
161 0.180
1.50
168 0.180
1.75
174 0.180
2.00
811270
420823
Cut
Pierce Height
Speed
Factor
mm/min mm Seconds
%
6210 3.0 200
4850 5.1 150
3735 6.9 150
3415 9.5 250
2845 7.8 250
1920 7.5 250
1430 8.0 250
805 8.9 280
570
395 Edge start
270
Cut
Pierce Height
Speed
Factor
ipm in Seconds
%
235 0.200 200
150 0.280 150
130 0.280 200
105 0.280 250
80 0.280 250
65 0.280 250
55 0.310 250
32 0.350 280
22
15 Edge start
10
Instruction Manual MAXPRO200
Pierce
Delay
0.3
0.4
0.5
0.7
0.9
1.3
1.6
2.5
Pierce
Delay
0.3
0.5
0.5
0.9
1.2
1.4
1.6
2.5
