Cut charts
420735 220936* / 220935**
Metric
Plasma Cutflow
7.6 m 15.3 m 22.9 m 30.5 m
Lead Lead Lead Lead
62 62 64 64
English
Plasma Cutflow
25 ft 50 ft 75 ft 100 ft
Lead Lead Lead Lead
62 62 64 64
*with IHS tab / **without IHS tab
20
Mild steel
O Plasma / Air Shield
2
130 A Extreme bevel cutting
420828
Shield Cutflow
7.6 m 15.3 m 22.9 m 30.5 m
Lead Lead Lead Lead
30 32 35 37
Shield Cutflow
25 ft 50 ft 75 ft 100 ft
Lead Lead Lead Lead
30 32 35 37
220529 420824
Effective Arc Cut
Thickness Voltage Height
mm Volts mm
3 130 2.6
131 2.7
4
134 2.8
6
136 3.0
10
138 3.0
12
140 3.6
15
20 145 3.9
25 151 3.9
32 158 3.9
Effective Arc Cut
Thickness Voltage Height
in Volts in
0.135 130 0.100
0.1875 132 0.110
0.25 134 0.110
136 0.120
0.375
138 0.120
0.50
141 0.150
0.625
144 0.150
0.75
1.00 151 0.150
1.25 158 0.150
811270
420823
Cut Pierce
Pierce Height
Speed Delay
Factor
mm/min mm Seconds
%
5900 5.2 200
5325 5.4 200
3925 5.6 200
2680 6.0 200
2200 6.0 200
1310 7.2 200
880 7.8 200
845
Edge start
365
Cut Pierce
Pierce Height
Speed Delay
Factor
ipm in Seconds
%
240 0.200 200
190 0.220 200
150 0.220 200
110 0.240 200
80 0.240 200
50 0.300 200
35 0.300 200
18
Edge start
14
Instruction Manual MAXPRO200
0.1
0.2
0.3
0.4
0.5
0.7
1.0
0.1
0.2
0.3
0.3
0.5
0.7
1.0
