Cut charts

Recommended torch-pivot lengths

The bevel-pivot point
point is the intersection of the torch axis and the top of the workpiece when the torch is at its
maximum angle and minimum clearance.
The use of extreme bevel consumables increases the recommended torch-pivot length by more than
100%. Refer to Figure 1
3
1 Torch-pivot length
2 Maximum tilt angle
3 Effective thickness
Torch-pivot length
Maximum torch angle

Clearance

Clearance
Clearance is the minimum distance between the torch and the top of the workpiece. A higher
4
clearance can decrease the chance of torch collisions with the workpiece. But, it can also cause the
following conditions:
Increased cut heights that give bad edge quality and make higher-angle compensations

necessary
Increased voltages that can have a bad effect on the duty cycle of the plasma power supply

16
has an effect on the recommended torch-pivot length
5
and Table 1.
1
2
5
4 Clearance
5 Bevel-pivot point
Table 1 – Recommended torch-pivot lengths by product type
MAXPRO200 standard mechanized
consumables
30 mm (1.18 in.) 31 mm (1.24 in.)
45 degrees 45 degrees
2 mm (0.08 in.) 3 mm (0.125 in.)
Figure 1
4
In this example, the torch-pivot length shows the
extreme-bevel consumables at 66.5 degrees and
MAXPRO200 extreme bevel
consumables
62 mm (2.44 in.)
66.5 degrees
2 mm (0.08 in.)
811270
. The bevel-pivot
1
at a clearance of 2 mm (0.080 in.).
65 mm (2.55 in.)
66.5 degrees
3 mm (0.125 in.)
Instruction Manual MAXPRO200
