Extreme Bevel Cut Charts - Hypertherm MAXPRO200 Original Instructions Manual

Extreme bevel cut charts

420735
220936* / 220935**
Metric
Plasma Cutflow
7.6 m 15.3 m 22.9 m 30.5 m
Lead Lead Lead Lead
68 69 70 71
English
Plasma Cutflow
25 ft 50 ft 75 ft 100 ft
Lead Lead Lead Lead
68 69 70 71
*with IHS tab / **without IHS tab
MAXPRO200 Instruction Manual
Air Plasma / Air Shield
130 A Extreme bevel cutting
420829
Shield Cutflow
7.6 m 15.3 m 22.9 m 30.5 m
Lead Lead Lead Lead
22 24 26 28
Shield Cutflow
25 ft 50 ft 75 ft 100 ft
Lead Lead Lead Lead
22 24 26 28
811270
Mild steel
220488 420824
Effective Arc Cut
Thickness Voltage Height
mm Volts mm
142 3.0
3
143 3.0
4
146 2.4
6
10 151 4.1
12 153 4.1
15 157 4.4
20 163 4.6
25 170 4.6
32 179 4.6
Effective Arc Cut
Thickness Voltage Height
in Volts in
145 0.120
0.135
144 0.120
0.1875
143 0.120
0.25
152 0.160
0.375
153 0.160
0.50
0.625 158 0.180
0.75 160 0.180
1.00 172 0.180
1.25 178 0.180
Cut charts
420823
Cut Pierce
Pierce Height
Speed Delay
Factor
mm/min mm Seconds
%
5350 6.0 200
4630 6.0 200
3865 7.5 300
2445 8.2 200
2045 8.2 200
1445 8.8 200
815 9.6 210
415
Edge start
250
Cut Pierce
Pierce Height
Speed Delay
Factor
ipm in Seconds
%
220 0.240 200
160 0.240 200
150 0.300 300
100 0.320 200
75 0.320 200
50 0.360 200
35 0.375 210
15
Edge start
10
0.1
0.2
0.3
0.5
0.5
0.8
1.2
0.1
0.2
0.3
0.5
0.5
0.8
1.2
19
