220936* / 220935**
420737
Metric
Plasma Cutflow
7.6 m 15.3 m 22.9 m 30.5 m
Lead Lead Lead Lead
52 54 55 56
English
Plasma Cutflow
25 ft 50 ft 75 ft 100 ft
Lead Lead Lead Lead
52 54 55 56
*with IHS tab / **without IHS tab
MAXPRO200 Instruction Manual
Mild steel
Air Plasma / Air Shield
200 A Extreme bevel cutting
420734
Shield Cutflow
7.6 m 15.3 m 22.9 m 30.5 m
Lead Lead Lead Lead
48 50 54 58
Shield Cutflow
25 ft 50 ft 75 ft 100 ft
Lead Lead Lead Lead
48 50 54 58
811270
420732
220488
Effective Arc Cut
Thickness Voltage Height
mm Volts mm
6 137 1.0
140 1.3
8
142 3.0
10
144 3.0
12
147 4.3
15
20 153 4.8
25 159 6.4
32 167 6.4
38 174 6.4
44 180 6.4
187 6.4
50
Effective Arc Cut
Thickness Voltage Height
in Volts in
140 0.100
.25
139 0.100
0.3125
138 0.100
0.375
142 0.130
0.50
149 0.190
0.625
0.75 152 0.190
0.875 156 0.190
1.00 165 0.250
1.25 166 0.250
1.50 171 0.250
181 0.250
1.75
188 0.250
2.00
Cut charts
420823
Cut Pierce
Pierce Height
Speed
Factor
mm/min mm Seconds
%
4885 3.0 300
4515 3.9 300
3556 5.5 200
2794 6.0 200
2265 8.6 200
1415 9.6 200
940 11.4 180
630 11.4 180
510
320 Edge start
215
Cut
Pierce Height
Speed
Factor
ipm in Seconds
%
190 0.120 300
180 0.150 300
140 0.200 200
110 0.250 200
85 0.380 200
60 0.380 200
50 0.380 200
35 0.450 180
25 0.450 180
20
12 Edge start
8
Delay
0.3
0.5
0.8
0.9
1.0
1.4
1.7
2.3
Pierce
Delay
0.3
0.5
0.8
0.9
1.0
1.2
1.4
1.7
2.3
