Summary of Contents for Stahl 6414/11 Series
- Page 1 Operation, Installation and Maintenance Manual for 6414/11-Series Operating instructions For Additional languages www.stahl-ex.com Linear Luminaire Sheet Steel for Fluorescent Lamps Series 6414/11 ID-No.: 240912 / 6414603300 Publication Code: 2015-04-30:BA00.lll.en.00 Page - 1 - of 17...
-
Page 2: Table Of Contents
Operation, Installation and Maintenance Manual for 6414/11-Series Contents General Information ............................ - 3 - Manufacturer ............................- 3 - Information regarding the operating instructions ................. - 3 - Conformity to Standards ........................- 3 - Explanation of symbols..........................- 3 - Symbols in these operating instructions .................... -
Page 3: General Information
Operation, Installation and Maintenance Manual for 6414/11-Series General Information Manufacturer R. Stahl Schaltgeräte GmbH R. STAHL (P) LTD., Plot No. – 5 Am Bahnhof 30 Malrosapuram Road, Sengundram Indl. Area 74638 Waldenburg Singaperumal Koil, Kancheepuram Dist., Germany Tamil Nadu – 603 204, INDIA... -
Page 4: Warning Notes
Operation, Installation and Maintenance Manual for 6414/11-Series Warning notes Warning notes must be observed under all circumstances, in order to minimize the risk due to construction and operation. The warning notes have the following structure: Signaling word: DANGER, WARNING, CAUTION, NOTICE ... -
Page 5: Intended Use
Operation, Installation and Maintenance Manual for 6414/11-Series We cannot be held liable for damage caused by incorrect or unauthorized use or by non-compliance with these operating • instructions. Before installation and commissioning, make sure that the device is not damaged! •... -
Page 6: Function
Operation, Installation and Maintenance Manual for 6414/11-Series Function DANGER Explosion Hazard due to improper use! Non-compliance results in severe or fatal injuries. • Use the device only according to the operating conditions described in these operating instructions. for lighting areas, work spaces and objects •... -
Page 7: Technical Data
Operation, Installation and Maintenance Manual for 6414/11-Series Technical Data Explosion Protection Certificats ATEX, IEC Ex, PESO, Zone Classification Zone 2, 21 & 22 Explosion Protection Type Equipment protection by type of protection "n", Equipment dust ignition protection by enclosure "t" IECEx BVS 14.0113 IECEx Ex nAc IIC T4... -
Page 8: Transport And Storage
Operation, Installation and Maintenance Manual for 6414/11-Series Technical Data Mounting / Installation Cable Glands 1x M20/M25 left and 2x M20/M25 Right, 1x cable glands and 2 stopping plugs as standard. (Others or on Special request - Certified single/double compression glands) Connection Spring clamp terminal up to 4 mm 3-pole (2x L1, 2x N, 2x PE) -
Page 9: Dimensions / Fastening Dimensions
Operation, Installation and Maintenance Manual for 6414/11-Series Dimensions / fastening dimensions Dimensional Drawings (All Dimensions in mm [inch]) - Subject to Alterations Model 2x18W 4x18W 2x36W 4x36W 2x58W 4x58W 1343 1343 1643 1643 1250 1250 ID-No.: 240912 / 6414603300 Publication Code: 2015-04-30:BA00.lll.en.00 Page - 9 - of 17... -
Page 10: Mounting / Dismounting, Operating Position
Wall mounting must be performed with the central lock directed downwards. For outdoor use, we recommend to install a 8162/1 breather from R. STAHL Schaltgeräte GmbH. The breather guarantees compliance with degree of protection IP64 in all mounting positions. -
Page 11: Installation
Recommendation Opening and closing of the luminaire by using a socket wrench from R. STAHL Schaltgeräte GmbH. Remove the closing cap of the central lock. To open the fixture, press inward and Turn the central lock using a socket key M5 hex socket head driver, by 90° anti-clockwise direction as far as it can go. -
Page 12: Electrical Connections
Operation, Installation and Maintenance Manual for 6414/11-Series Note: a) Version without switch: Disconnect the luminaire from the power supply and secure it against being switched on again. b) Version with switch: The luminaire is positively disconnected from the power supply by actuating the central lock. c) In opened condition and with luminaire cover swiveled down, a restart lock-out device prevents the central lock from being actuated. -
Page 13: Cable Entries
7.3.3 Cable Entries The standard luminaire is delivered with 3 lead-in holes, 1 cable gland and 2 stopping plugs. Please observe the tightening torque for luminaires with installed cable glands and stopping plugs from R. STAHL Schaltgeräte GmbH. Pressure screw... -
Page 14: Commissioning
Operation, Installation and Maintenance Manual for 6414/11-Series WARNING Using of the Cable glands and stopping plugs which are not approved. The explosion protection is impaired! Only use separately certified cable glands and stopping plugs. Note: the required dust resistance! ... -
Page 15: Operations
The lamp reached its end of service life. Replace the lamp. If the error cannot be eliminated using the mentioned procedures: • Contact the local representative of R. STAHL Schaltgeräte GmbH. For fast processing, have the following information ready: • Type and serial number •... -
Page 16: 10.1.1 Replacement Of Lamps
Operation, Installation and Maintenance Manual for 6414/11-Series The following tests and measures must be carried out during regular maintenance. Check Measures If exceeding the permissible ambient temperature or falling below the the permissible ambient temperature device must be taken out of operation. ... -
Page 17: Returning The Device
Download the service form and fill it out. Send the device along with the service form in the original packaging to “STAHL Schaltgeräte GmbH”. Disposal Do not incinerate lamps. To comply with the Waste Electrical and Electronic Equipment directive 2002/96/EC the apparatus cannot be classified as commercial waste and as such must be disposed of or recycled in such a manner as to reduce the environmental impact.
