POWER AND CONTROL WIRING ENTRY LOCATIONS

Drive HP A B
305/254 1.63 4.50
437/362 6.63 6.75
*Contact factory for detailed dimensions.
VYPER VARIABLE SPEED DRIVE
™
INSTALLATION
Dimensions in Inches *
C D E
9.00 6.38 4.38 35.00
10.13 2.00 3.25 40.53
F G H J
5.50 3.56 6.63
2.25 3.00 13.00
S100-200 IOM (MAY 08)
Page 19
K
2.00
2.00
