JXCP1-TF2Z197EN
5 Setting
5.1 Initial Setting
• Appropriate setting is required in order to establish the communication
of the controller (JXCP1) on the PROFINET network.
• Please refer to the PLC setting software "SIMATIC Manager Version
5.5 (STEP7) for the representative PROFINET master device.
• The required setting method such as the GSDML file installation varies
depending on which setting software will be used, so if software other
than STEP7 is used, please refer to the operation manual of the
applicable setting software.
In order to move the electric actuator to a specific position, it is necessary
to set up the patterns of operation with a PC using the controller setting
software or by using a teaching box. This set up data will be recorded in
the memory of the controller.
Refer to the Operation Manual on the SMC website (URL:
https://www.smcworld.com) for further setting details.
5.2 Configuration
• A GSDML file and icons file are required to configure the controller.
The latest GSDML file can be downloaded from the SMC website
(URL: https://www.smcworld.com).
6 LED Display
Refer to the table below for the LED status.
LED
Details
OFF
Power is not supplied
Power supply
PWR
Green LED is
status.
Power is supplied
ON
OFF
Normal operation
Controller alarm
ALM
Red LED is
status.
Alarm generated
ON
OFF
Normal operation
Controller
SF
Red LED is
Alarm generated (Linked to
status.
ON
ALM)
PROFINET communication
OFF
is established.
PROFINET
Red LED is
PROFINET communication
BF
communication
flashing
is not established.
status
Red LED is
Both Port1 and Port2 are
ON
not connected.
Refer to the table below for the LED and controller status
LED
Controller status
PWR
ALM
SF
Green
LED is
When power is supplied
LED is
-
OFF
ON
When PROFINET
LED is
-
-
communication is normal
OFF
Controller
Red
Red
LED is
alarm
LED is
LED is
OFF
generated
ON
ON
Controller
Green
Red
Motor
system error
LED is
LED is
-
controller
generated
ON
ON
Writing to
Green
controller
LED is
-
-
Eeprom
flashing
Caution
Do not turn OFF the power supply for the controller or connect /
disconnect the cable while data is being written to EEPROM (PWR LED
(green) is flashing).
This is to avoid the possibility of incorrect / corrupt data (step data,
parameter).
7 How to Order
Refer
to
the
catalogue
on
the
https://www.smcworld.com) for the How to Order information.
8 Outline Dimensions (mm)
Refer to the drawings / operation manual on the SMC website (URL:
https://www.smcworld.com) for outline dimensions.
9 Maintenance
9.1 General Maintenance
Caution
• Not following proper maintenance procedures could cause the product
to malfunction and lead to equipment damage.
• Before performing maintenance, turn off the power supply. Check the
voltage with a tester 5 minutes after the power supply is turned OFF.
• If any electrical connections are disturbed during maintenance, ensure
they are reconnected correctly and safety checks are carried out as
required to ensure continued compliance with applicable national
regulations.
• Do not make any modification to the product.
• Do not disassemble the product, unless required by installation or
maintenance instructions.
Caution
• Maintenance should be performed according to the procedure
indicated in the Operation Manual.
• When equipment is serviced, first confirm that measures are in place
to prevent dropping of work pieces and run-away of equipment, etc,
then cut the power supply to the system. When machinery is restarted,
check that operation is normal with actuators in the correct position.
Warning
• Perform maintenance checks periodically.
• Confirm wiring and screws are not loose. Loose screws or wires may
cause unexpected malfunction.
• Conduct an appropriate functional inspection and test after completing
maintenance. In case of any abnormalities (if the actuator does not
move, etc.), stop the operation of the system. Otherwise, an
unexpected malfunction may occur and it will become impossible to
ensure safety. Operate an emergency stop instruction to confirm safety.
• Do not put anything conductive or flammable inside of the controller.
• Ensure sufficient space around the controller for maintenance.
10 Limitations of Use
BF
10.1 Limited warranty and Disclaimer/Compliance Requirements
-
Refer to Handling Precautions for SMC Products.
LED is
OFF
11 Product disposal
This product shall not be disposed of as municipal waste. Check your
-
local regulations and guidelines to dispose of this product correctly, in
order to reduce the impact on human health and the environment.
-
-
SMC
website
(URL:
12 Contacts
Refer to
www.smcworld.com
or
www.smc.eu
for your local distributor /
importer.
URL:
https://www.smcworld.com
(Global)
https://www.smc.eu
(Europe)
SMC Corporation, Akihabara UDX15F, 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101
0021
Specifications are subject to change without prior notice from the manufacturer.
© 2021 SMC Corporation All Rights Reserved.
Template DKP50047-F-085M
Page 2 of 2
