KINTEX-7 FPGA Development Board AV7K325 User Manual
HDMI1_IN_D0
HDMI1_IN_D1
HDMI1_IN_D2
HDMI1_IN_D3
HDMI1_IN_D4
HDMI1_IN_D5
HDMI1_IN_D6
HDMI1_IN_D7
HDMI1_IN_D8
HDMI1_IN_D9
HDMI1_IN_D10
HDMI1_IN_D11
HDMI1_IN_D12
HDMI1_IN_D13
HDMI1_IN_D14
HDMI1_IN_D15
HDMI1_IN_D16
HDMI1_IN_D17
HDMI1_IN_D18
HDMI1_IN_D19
HDMI1_IN_D20
HDMI1_IN_D21
HDMI1_IN_D22
HDMI1_IN_D23
HDMI1_IN_D24
HDMI1_IN_D25
HDMI1_IN_D26
HDMI1_IN_D27
HDMI1_IN_D28
HDMI1_IN_D29
HDMI1_IN_D30
HDMI1_IN_D31
42 / 54
B13_L23_P
B15_L4_N
B15_L4_P
B15_L16_P
B15_L16_N
B15_L6_P
B15_L6_N
B15_L5_P
B15_L5_N
B15_L9_P
B15_L9_N
B15_L20_P
B15_L20_N
B15_L12_P
B15_L12_N
B15_L21_P
B15_L21_N
B15_L3_P
B15_L3_N
B15_L24_P
B15_L24_N
B15_L8_P
B15_L8_N
B15_L7_P
B15_L7_N
B15_L23_P
B15_L23_N
B15_L11_N
B15_L17_P
B15_L17_N
B15_L19_P
B15_L19_N
Amazon Store: https://www.amazon.com/alinx
AF26 Video input signal data 0
K21 Video input signal data 1
L21 Video input signal data 2
N27 Video input signal data 3
M27 Video input signal data 4
M20 Video input signal data 5
L20 Video input signal data 6
J21 Video input signal data 7
J22 Video input signal data 8
L30 Video input signal data 9
K30 Video input signal data 10
N21 Video input signal data 11
N22 Video input signal data 12
L25 Video input signal data 13
K25 Video input signal data 14
P23 Video input signal data 15
N24 Video input signal data 16
K23 Video input signal data 17
K24 Video input signal data 18
M22 Video input signal data 19
M23 Video input signal data 20
J27 Video input signal data 21
J28 Video input signal data 22
J29 Video input signal data 23
H29 Video input signal data 24
M24 Video input signal data 25
M25 Video input signal data 26
L27 Video input signal data 27
N29 Video input signal data 28
N30 Video input signal data 29
N19 Video input signal data 30
N20 Video input signal data 31
