2) Technical Specifications

Products MS5/16NEU-12, MS9/16NEU-12, MS13/16NEU-12 and MS17/16NEU-12 are satellite
multiswitches for distribution of terrestrial and satellite signals from up to 4 satellite positions to 16 users,
providing data link over the same coaxial cable with bandwidth up to 100 Mbit/s.
Products MS5/20NEU-12, MS9/20NEU-12, MS13/20NEU-12 and MS17/20NEU-12 are satellite
multiswitches for distribution of terrestrial and satellite signals from up to 4 satellite positions to 20 users,
providing data link over the same coaxial cable with bandwidth up to 100 Mbit/s.
Satellite inputs require use of Quattro LNBs. The terrestrial input features built-in amplifier, which can be
switched off and bypassed using rotary knob. The data input supports speeds up to 1Gbit/s, according to
standards 802.3i, 802.3u, 802.3ab. The multiswitch is supplied from external power supply 12 V (included in
package) connected to socket DC2.1.
Specification of
multiswitch
Number of Inputs / Outputs 5 / 16
Frequency Range
Insertion Loss TERR
Insertion Loss SAT
Isolation H/V
Isolation low/high
Isolation LNB
Maximum Input level*
Maximum Output Level*
Current Consumption
Data input (port Eth)
Power supply
consumption**
Dimensions (w,d,h)
Temperature Range
*Terr.: EN 50083-3/60dB IMA3 [dBµV]; SAT: EN 50083-3/35dB IMA3 [dBµV]
** Depends on number of connected wall sockets and actual data activity

3) Product Takeover

Make sure that the product is not damaged and following accessories are enclosed:
• power supply 12 V
•
75 Ω DC isolated loads for impedancy termination of unused outputs (8 pcs for 16-output
products, 10 pcs for 20-outputs products)
In the case of damage or missing accessories please contact your dealer.
MS5/16 MS5/20 MS9/16
NEU-12 NEU-12 NEU-12
5 / 20 9 / 16
TERR 470–862 MHz, SAT 950–2150 MHz
8 dB active, 25 dB passive
5 dB
20 dB min
25 dB min
- 25 dB min
TERR 90 dBuV, SAT 105 dBuV
TERR 82 dBuV active, 65 dBuV passive, SAT 100 dBuV
150 mA (18 V DC) from each satellite receiver
10BASE-T (10 Mbit/s), 100BASE-TX (100 Mbit/s), 1000BASE-T (1Gbit/s)
20–40 W 25–45 W
18.6 x 25.0 x 5.1 cm
−25 – +60 °C
MS9/20 MS13/16
NEU-12 NEU-12
9 / 20 13 / 16
30–50 W
2 of 8
MS13/20 MS17/16
NEU-12 NEU-12
13 / 20 17 / 16
35–55 W
MS17/20
NEU-12
17 / 20
