2) Technical Specifications

Products MS5/6NEU-4, MS9/6NEU-4, MS13/6NEU-4 and MS17/6NEU-4 are satellite multiswitches for
distribution of terrestrial and satellite signals from up to 4 satellite positions to 6 users, providing data link
over the same coaxial cable with bandwidth up to 100 Mbit/s.
Products MS5/10NEU-4, MS9/10NEU-4, MS13/10NEU-4 and MS17/10NEU-4 are satellite multiswitches for
distribution of terrestrial and satellite signals from up to 4 satellite positions to 10 users, providing data link
over the same coaxial cable with bandwidth up to 100 Mbit/s.
Satellite inputs require use of Quattro LNBs. The terrestrial input features built-in amplifier, which can be
switched off and bypassed using rotary knob. The data input supports speeds up to 1Gbit/s, according to
standards 802.3i, 802.3u, 802.3ab. The multiswitch is supplied from external power supply PA12 F
(included in package) connected to socket DC2.1.
Specification of
multiswitch
Number of Inputs / Outputs
Frequency Range
Insertion Loss TERR
Insertion Loss SAT
Isolation H/V
Isolation low/high
Isolation LNB
Maximum Input level*
Maximum Output Level*
Current Consumption
Data input (port Eth)
Power supply consumption** 15–30 W
Dimensions (w,d,h)
Temperature Range
*Terr.: EN 50083-3/60dB IMA3 [dBµV]; SAT: EN 50083-3/35dB IMA3 [dBµV]
** Depends on number of connected wall sockets and actual data activity

3) Product Takeover

Make sure that the product is not damaged and following accessories are enclosed:
• power supply PA12 F
• 75 Ω DC isolated loads for impedancy termination of unused outputs (3 pcs for 6-output products,
5 pcs for 10-outputs products)
In the case of damage or missing accessories please contact your dealer.
MS5/6 MS5/10 MS9/6
NEU-4 NEU-4 NEU-4
5 / 6 5 / 10 9 / 6
TERR 470–862 MHz, SAT 950–2150 MHz
2 dB active, 20 dB passive
5 dB
20 dB min
25 dB min
- 25 dB min
TERR 90 dBuV, SAT 105 dBuV
TERR 88 dBuV active, 70 dBuV passive, SAT 100 dBuV
150 mA (18 V DC) from each satellite receiver
10BASE-T (10 Mbit/s), 100BASE-TX (100 Mbit/s), 1000BASE-T (1Gbit/s)
18–33 W
18.6 x 14.6 x 5.1 cm
−25 – +60 °C
2 of 8
MS9/10 MS13/6 MS13/10
NEU-4 NEU-4 NEU-4
9 / 10 13 / 6 13 / 10
21–36 W
MS17/6 MS17/10
NEU-4 NEU-4
17 / 6 17 / 10
24–39 W
