1) Field of Application, Warranty

The product is designed for the distribution of satellite (SAT), terrestrial (TERR); TV and radio signals. Its
purpose is to allow connecting of multiple user to the common satellite antenna.
The manufacturer provides for E.LITE CLASS products extended 4 (four) years warranty from the date of
purchase, see details in EMP-Centauri General trade conditions, published at manufacturer's website
www.emp-centauri.cz.
It is prohibited to dismantle the product and make any interventions in it. Repairs or any interventions in the
product may be performed only by EMP-Centauri company, or other companies authorized by EMP-Centauri.

2) Technical Specifications

Products MS9/6ECP-4, MS13/6ECP-4 and MS17/6ECP-4 are satellite multiswitches for distribution of
terrestrial and satellite signals from up to 4 satellite positions to 6 users.
Products MS9/8ECP-4, MS13/8ECP-4 and MS17/8ECP-4 are satellite multiswitches for distribution of
terrestrial and satellite signals from up to 4 satellite positions to 8 users.
Products MS9/10ECP-4, MS13/10ECP-4 and MS17/10ECP-4 are satellite multiswitches for distribution of
terrestrial and satellite signals from up to 4 satellite positions to 10 users.
Specification
Number of Inputs
Number of Outputs
Frequency Range
Insertion Loss (avg.)
Isolation
Maximum Input level
Max. Output Level 1
Current drawn 2
Dimensions (w,d,h)
Temperature Range
Products MS9/12ECP-12, MS13/12ECP-12 and MS17/12ECP-12 are satellite multiswitches for distribution
of terrestrial and satellite signals from up to 4 satellite positions to 12 users.
Products MS9/16ECP-12, MS13/16ECP-12 and MS17/16ECP-12 are satellite multiswitches for distribution
of terrestrial and satellite signals from up to 4 satellite positions to 16 users.
Products MS9/20ECP-12, MS13/20ECP-12 and MS17/20ECP-12 are satellite multiswitches for distribution
of terrestrial and satellite signals from up to 4 satellite positions to 20 users.
Specification
Number of Inputs
MS9/6 MS13/6 MS17/6
ECP-4 ECP-4 ECP-4
9 13 17
6
TERR 5–862 MHz, SAT 950–2150 MHz
TERR 18 dB, SAT 5 dB
H/V 20 dB, Low/High 25 dB, SAT/SAT 25 dB
1
TERR 105 dB, SAT 105 dB
TERR 87 dB, SAT 100
dB
80 mA 90 mA 100 mA 80 mA 90 mA
18.6 x 14.6 x 5.1 cm
−25 – +60 °C
MS9/12 MS13/12 MS17/12
ECP-12 ECP-12 ECP-12
9 13 17
MS9/8 MS13/8 MS17/8
ECP-4 ECP-4 ECP-4
9 13 17
8
TERR 22 dB, SAT 5 dB
TERR 85 dB, SAT 100 dB
100 mA 80 mA
MS9/16 MS13/16 MS17/16
ECP-12 ECP-12 ECP-12
9 13 17
2 of 8
MS9/10 MS13/10 MS17/10
ECP-4 ECP-4 ECP-4
9 13 17
10
90 mA 100 mA
MS9/20 MS13/20 MS17/20
ECP-12 ECP-12 ECP-12
9 13 17
