Replace broken or interrupted coaxial cable.
Sometimes the reset of the multiswitch microprocessor is enough to fix the problem. Pull out
the power plug of the multiswitch and satellite receiver from power grid and then re-plug them
a few seconds later.
In the case the product does not work and LED of power supply seems to be overloaded:
Disconnect the product from the power grid and check that there is no short-circuit on the input
satellite coaxial cables, which prevents the power supplying of LNBs. If yes, remove short-circuit
and re-plug the product into the power grid again.
The cause can be current consumption of devices connected to the satellite inputs of product
which exceeds the specifications, see section 2) Product Specifications.
Upon the power on the multiswitch tests condition of user ports and deactivates data operation for
all ports where EMP-Centauri NET CLASS wall socket is not detected. During operation, any user port
is automatically disabled for data operation if physical connection to the data wall socket is lost. Data
operation is resumed automatically after re-connection of the wall socket. In case of long user cable it
may be necessary to re-activate data operation manually by short disconnecting and reconnecting
of power supply cord.
If the failure cannot be removed, please contact your distributor.

10) Symbols Explanation

certificate of conformity
international standard for digital satellite equipment control, number (1.0, 1.1, 1.2 or 2.0)
determines DiSEqC version.
for indoor use only
DC power supply
protective bonding
class II device
fuse protected
safety transformer
According to EU directive, electric and electronic devices which are identified by one of the
following symbols must not be disposed of together with municipal waste. When disposing
of the old device, use local waste collection and separation systems.
6 of 8
