SF 28PT • Setup Guide (Continued)
7.
Use an Extron Tweeker or small screwdriver to set the tap
selector switch to the desired position.
4
Enclosure
Cloth Scrim Backing
Speaker Grille
Grille Hook
8.
Replace the grille.
NOTES:
•
Wiring is the same for all hanging methods
where PCC-2 cable is used. If it is not used,
the 2-pole splicing connectors at the speaker
should be replaced with the provided 3-pole
splicing connectors. Refer to
Installation and Configuration
•
Setting the tap switch is the same for all
installation metnods.
•
Follow steps 1 through 2 of the
the Mounting Hardware
continuing with any of the optional mounting
methods.
•
Be sure to allow extra cable length for the
structure attachment points.
16W
OFF
8
32W
64W
64W
32W
16W
8Ω
OFF
8W
Adjust the Tap Selector
Speaker
for details.
Installing
section before
