User Manual
Remote Control IK2 Transmitters
Technical description
IK2 Detailed description
Description
Stop Function (400 - 900 MHz)
Stop Function (2.4 GHz)
Ingress Protection rating
Anti-condensation system
Frequency band - ERP
Range (normal conditions)
Main mechanisms (maximum number)
Auxiliary mechanisms
Removable EEPROM
Battery model
Battery life
Response Time
Operating temperature range
Storage Temperature Range (24h)
Storage Temperature Range (long periods)
Relative Humidity
Weight (with battery)
Dimensions LxWxH mm
Harness
Available Options
Display
LED Panel
Cable connector
Range limiter
Associated receivers
©
Danfoss | May 2021
Value
Cat. 3-PLd
Cat3 - PLe
IP65/NEMA4
Goretex Film
433.050 to 434.040 MHz; ERP<1 mW
434.040 to 434.790 MHz; ERP<10mW
869.700 to 870.000 MHz; ERP<5 mW
902.000 to 928.000 MHz; ERP<1mW
2405MHz to 2475MHz ; ERP 20dBm/100mW
100m
Joystick (2) or Paddle (4)
Pushbutton, toggle and rotary switches
External
BT11K
8 hours
100ms
-20 °C to 70 °C (-4 °F to 158 °F)
-25ºC to 75ºC (-13ºF to 167ºF)
-25ºC to 55ºC (-13ºF to 131ºF)
max. 95% without condensation
950 grams
184 x 173.4 x 158.7
Belt/shoulder strap
128x64 Graphic LCD
Yes (up to 8 LEDs)
Yes (M12 Connector)
Yes
R06, R13, R70, MPCAN, MP08, MP20
BC290862531428en-000201 | 9
