Sweeper Beam Quad LED
Disconnect the unit from its power source. Remove the power cord from the unit. Once the cord has
been removed, you will find that the fuse holder is located inside the power socket. Insert a flat-head
screw driver into the power socket and gently pry out the fuse holder. Remove the bad fuse and re-
place with a new one. Note that the fuse holder also includes a slot for a spare fuse.
Sweeper Beam Quad LED
Fixture Cleaning: Due to fog residue, smoke, and dust, cleaning the internal and external optical
lenses and mirror should be carried out periodically to optimize light output. Cleaning frequency de-
pends on the environment in which the fixture operates (I.e. smoke, fog residue, dust, dew). In heavy
club use, cleaning on a monthly basis is recommended. Periodic cleaning will ensure longevity and
crisp output.
• Use normal glass cleaner and a soft cloth to wipe down the outside casing.
• Use a brush to wipe down the cooling vents and fan grill.
• Clean the external optics and mirror with glass cleaner and a soft cloth every 20 days.
• Clean the internal optics with glass cleaner and a soft cloth every 30-60 days.
• Always be sure to dry all parts completely before plugging the unit back in.
Sweeper Beam Quad LED
Trouble Shooting: Listed below are a few common problems that you may encounter, with solu-
tions.
No light output from the unit;
• Be sure the external fuse has not blown. The fuse is located inside the power socket.
• Be sure the fuse holder is completely and properly seated.
Unit does not respond to sound;
Low frequencies (bass) should cause the unit to react to sound, but quiet or high pitched sounds,
such as tapping on the microphone, may not activate the unit.
ADJ Products, LLC - www.adj.com - Sweeper Beam Quad LED User Manual Page 22

Fuse Replacement

Cleaning
Trouble Shooting
