SERVICE MANUAL
STAINLESS STEEL HANDS FREE
CHARGE-A-CALL TELEPHONE
EQUIPPED WITH SPK1.07UNVLr1 FIRMWARE
Communication Equipment
& Engineering Company
FOR
MODEL SSC-501-F
MODEL BLC-501-F
SSC-501-F OR BLC-501-F-SPK1.07UNVLr1-ISSUE4.0
OR
Serving the Telephone Industry Since 1930
519 W South Park Street
Okeechobee, FL 34972
Voice: 863-357-0798
Fax: 863-357-0006
Advertisement
Table of Contents
Related Manuals for CEECO SSC-501-F
Summary of Contents for CEECO SSC-501-F
- Page 1 SSC-501-F OR BLC-501-F-SPK1.07UNVLr1-ISSUE4.0 SERVICE MANUAL MODEL SSC-501-F MODEL BLC-501-F STAINLESS STEEL HANDS FREE CHARGE-A-CALL TELEPHONE EQUIPPED WITH SPK1.07UNVLr1 FIRMWARE Serving the Telephone Industry Since 1930 Communication Equipment 519 W South Park Street & Engineering Company Okeechobee, FL 34972 Voice: 863-357-0798...
- Page 2 ISSUE 4.0 IMPORTANT INFORMATION CUSTOMER Please fill in before you continue. The following information is necessary when calling CEECO for assistance. MODEL NUMBER MODEL SSC-501-F OR BLC-501-F, EQUIPPED WITH SPK1.07UNVLr1 FIRMWARE. SERIAL NUMBER DATE MANUFACTURED LOCATION INSTALLED For us to better serve you, please have this information available when calling for technical support.
-
Page 3: Table Of Contents
RECOMMENDED TOOLS AND TEST EQUIPMENT ........ 11 INSTALLATION NOTES AND ASSEMBLY INSTRUCTIONS ....12 OVER-VOLTAGE PROTECTION DIAGRAM..........13 TESTING......................13 10.0 SPECIFICATIONS..................... 14 11.0 PARTS LIST ....................... 15 13.0 REPAIR AND RETURN INFORMATION............. 17 14.0 WARRANTY POLICY ..................18 CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 4: Introduction
GENERAL The CEECO hands free telephone is a sturdy, vandal resistant, Stainless Steel Panel Speakerphone. Instead of a hookswitch and handset, the telephone has a Press to start/Press to stop button for initiation and termination of phone calls. Manual volume control is also provided inside the telephone. -
Page 5: Programming
Connect the phone to a working telephone line or a DTMF test set before programming. Move the mini-jumpers (located on the CEECO-SPK Printed Circuit Board) to the “ON” position, as depicted on the last page of this manual. Press the CALL button and wait for dial tone before programming any digits. -
Page 6: Programming Continued
Always 0 for this model. Digit 9: 0 Always 0 for this model. Digit 10: 0 No Wink Detect l-9 Length of the Wink (l = 50ms incremental to 450ms – entering a 5 is recommended) CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 7: Programming Continued
Be sure to record your entries in the speed dial table for future reference. EXAMPLE: Enter #3018005551212 in the programming sequence. When in normal operating mode, the user dials #30 and the phone will Speed Dial 1 800 555 1212. CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 8: Programming Continued
When programming is finished, return the mini-jumpers to the "OFF" position. Then hang up the phone (“on hook” condition), by pressing the black "CALL " button. The phone is now ready for use. CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 9: Speed Dial/Allowed Call Tables
#68 _ - _ _ _ - _ _ _ - _ _ _ _ #49 _ - _ _ _ - _ _ _ - _ _ _ _ #69 _ - _ _ _ - _ _ _ - _ _ _ _ CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 10: Programming Tables Continued
#72 1 - 8 0 0 - * * * - * * * * #75 _ - _ _ _ - _ _ _ - _ _ _ _ Allows 1-800 calls if set in option table. CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 11: Operation
RECOMMENDED TOOLS AND TEST EQUIPMENT DTMF Test Set Volt/Ohm Meter 3/8" Nut Driver 5/16" Nut Driver Flat Blade Screw Driver Security Tool, CEECO Part Number 301-064 CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 12: Installation Notes And Assembly Instructions
Run the inside station wire through the Housing and terminate on to the RJ11C modular jack on the housing, as depicted on the following page. This CEECO-provided modular jack must be used, as it contains required over-voltage protection. The use of a gas tube or carbon station protector is recommended. The station ground should not exceed 50 ohms. -
Page 13: Over-Voltage Protection Diagram
Reaction: The called party answers. A normal speakerphone conversation is allowed. Action: Finish the conversation. Press the "CALL" button, or wait until time-out occurs (if programmed as such). Reaction: The call is terminated. CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 14: Specifications
Stainless Steel (14ga) DIMENSIONS: 7 1/2" Wide x 21" High x 4 1/8" Deep MOUNTING: Standard Coinless Public telephone foot print WEIGHT: 15 lb. RINGER EQUIVALENCY: 0.4A TYPE JACK: RJ11C UL LISTED NO.: 6OF5 CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 15: Parts List
PARTS LIST QUANTITY PART NUMBER DESCRIPTION 301-030 INSTRUCTION CARD KIT 301-012 OUTER COVER LOCKING SCREW 301-018 MODULAR LINE CORD SSC-501-F (or) STAINLESS STEEL OUTER COVER BLC-501-F BLUE POWDER COAT STEEL COVER 301-039 NUMBER WINDOW 301-040 NUMBER CARD 301-051 BACK PLATE... - Page 16 FCC registration number and ringer equivalence number. These numbers are listed in Section 11.00. The FCC further requires that you notify your local telephone company when permanently disconnecting this telephone. CEECO Communication Equipment & Engineering Company PROPRIETARY...
-
Page 17: Repair And Return Information
13.3 NON-WARRANTY REPAIR CEECO will repair equipment out of warranty for a set charge plus parts. The customer must pay the shipping costs both directions. 13.4 RETURN FOR CREDIT Material may be returned for credit only with prior approval. Material authorized for return is subject to a 20% restocking charge based on the manufacturer’s list price Return RMA must be requested no later than 30... -
Page 18: Warranty Policy
14.0 WARRANTY POLICY 14.1 GENERAL CEECO products are guaranteed to be free of defects in material and workmanship for a period of 365 days from the date of original purchase. CEECO's obligation under this warranty is limited to repair or replacement of any part found to be defective by CEECO. - Page 19 ON position BEFORE going off-hook. When programming is completed, move the mini jumpers to the OFF position. NOTE: Do not leave the mini jumpers in the ON position, this will decrease battery life. CEECO Communication Equipment & Engineering Company PROPRIETARY...
- Page 20 ISSUE 4.0 CEECO Communication Equipment & Engineering Company PROPRIETARY...
