CEECO ssw-321-x Service Manual

Hide thumbs Also See for ssw-321-x:
Table of Contents

Advertisement

Quick Links

Download this manual
Service Manual
-IP
Voice over Internet Protocol
-M
Magnetic Hookswitch
-BK
Braille Keypad
-IVC
Internal Volume Control &
Background Noise Reduction
-ACH*
Handset Color _________________
(Red, Yellow or White)
For
SSW-321-X
Communication Equipment
& Engineering Company
519 S.W. Park Street
Okeechobee, FL 33313
Phone: 863-357-0798
Fax:
863-357-0006
Email: info@ceeco.net
Web: www.ceeco.net
SSW-321-X -ISSUE 4.01
-ACH**
Handset cord length_________Inches
-CCH
Coiled cord length ___________Feet
5', 10', or 15'
-PBVC
Pushbutton volume control on
Handset
-C
Background noise reduction on
Handset
-BR
Braille emergency Plate

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ssw-321-x and is the answer not in the manual?

Questions and answers

Related Manuals for CEECO ssw-321-x

Summary of Contents for CEECO ssw-321-x

  • Page 1 SSW-321-X -ISSUE 4.01 Service Manual SSW-321-X Voice over Internet Protocol -ACH** Handset cord length_________Inches Magnetic Hookswitch -CCH Coiled cord length ___________Feet 5’, 10’, or 15’ Braille Keypad -PBVC Pushbutton volume control on Handset -IVC Internal Volume Control & Background noise reduction on...

  • Page 2: Table Of Contents

    SSW-321-X -ISSUE 4.01 Table of Contents Important Customer Information ................1.0 Introduction ....................... 2.0 General Description ....................3.0 Operation ........................4.0 Recommended Tools & Test Equipment ............5.0 Installation & Assembly ................. 6.0 Testing .......................... 7.0 Troubleshooting ....................... 8.0 Specifications ......................

  • Page 3: Important Customer Information

    SSW-321-X -ISSUE 4.01 IMPORTANT INFORMATION CUSTOMER Please fill in before you continue. The following information is necessary when calling CEECO for assistance. SSW-321-X MODEL NUMBER SERIAL NUMBER DATE MANUFACTURED LOCATION INSTALLED For us to better serve you, please have this information available when calling for technical support.

  • Page 4: Introduction

    (863) 357-0798 PHONE (863) 357-0006 FAX GENERAL DESCRIPTION The CEECO Model SSW-321-X is a Stainless Steel Telephone designed for special applications where a durable telephone instrument must be sturdy and attractive. The SSW-321-X will accept incoming calls only. The user cannot initiate a call.
  • Page 5 SSW-321-X -ISSUE 4.01 5.0 INSTALLATION NOTES & ASSEMBLY INSTRUCTIONS 5.1 Using a 301-037 security tool (sold separately) loosen and remove the security screw. 5.2 The security tool is for a standard 5/32" button head screw generally used on the framework of the phone booths.

  • Page 6: Testing

    SSW-321-X -ISSUE 4.01 5.9 Over-Voltage Protection Wiring Diagram TESTING 6.1. Connect the phone to a phone line or a DTMF phone test set. 6.2. From the test set or another phone place a call into the telephone. 6.3. Verify that the ringer is working 6.4.

  • Page 7: Troubleshooting

    SSW-321-X -ISSUE 4.01 7.0 TROUBLESHOOTING GUIDE Always visually check the phone for loose or shorted wires, damaged terminals or damaged parts. PROBLEM: NO DIAL TONE POSSIBLE CAUSE: LINE CORD RJ11C CONNECTOR NETWORK HANDSET HOOKSWITCH ASSEMBLY PROBLEM: DIAL TONE IS DISTORTED...

  • Page 8: Specifications

    SSW-321-X -ISSUE 4.01 8.0 SPECIFICATIONS INPUT POWER: C.O. Line Powered LOOP CURRENT: 23mA min to 80mA max IMPEDANCE: 600 ohms HEARING AID COMPATIBLE: Meets EIA standards ENVIRONMENTAL: Temp. -30C (-22F) to 60C (140F) Humidity 0%-90% non-condensating RINGER EQUIVALENCY: 0.4A TYPE JACK:...

  • Page 9: Parts List

    SSW-321-X -ISSUE 4.01 9.0 PARTS LIST QUANTITY PART NUMBER DESCRIPTION 301-106-32-1 32” ACH Handset w/steel Lanyard and Swivel 401-009 Ringer 301-009 Network 301-528 Mechanical Hookswitch or 301-592 Magnetic Hookswitch 321-012 Stainless Steel Housing 321-015 Stainless Steel Backplate 321-016 ¼” – 20” x ¾” Security Screw...

  • Page 10: Fcc Notice

    SSW-321-X -ISSUE 4.01 10.0 FCC NOTICE 10.1 FCC REGISTRATION AND REPAIR INFORMATION Your new telephone has been registered with the Federal Communication Commission (FCC) in accordance with Part 68. The FCC requires that you be advised of certain requirements involving the use of this telephone.

  • Page 11: Repair And Return

    Okeechobee, FL. 34972 (863) 357-0798 11.3 NON-WARRANTY REPAIR CEECO will repair equipment out of warranty for a set charge plus parts. The customer must pay the shipping costs both directions. 11.4 RETURN FOR CREDIT Material may be returned for credit only with prior approval.

  • Page 12: Warranty Policy

    CEECO will repair or replace any unit during this period if found to be defective for reasons other than abuse and improper use or improper installation. It is the buyer’s responsibility to return the defective unit to the factory.
  • Page 13 SSW-321-X -ISSUE 4.01 NOTES...
  • Page 14 SSW-321-X -ISSUE 4.01 NOTES...
  • Page 15 SSW-321-X -ISSUE 4.01 NOTES...
  • Page 16 Whatever the application may require, CEECO is prepared to offer affordable solutions that are “Built to Last”, with customer support that lasts the life of the product! CEECO is proud to manufacture our telephones in the USA.
