CHARGE-A-CALL TELEPHONE
EQUIPPED WITH CAC6.00 FIRMWARE
Communication Equipment
& Engineering Company
SSC-303-F- (303-FS) OR BLC-303-F (303-F)-650-521-CAC6.00-ISSUE4.0
SERVICE MANUAL
FOR
MODEL SSC-303-F
(FORMERLY 303-FS)
OR
MODEL BLC-303-F
(FORMERLY 303-F)
Serving the Telephone Industry Since 1930
1580 NW 65
Plantation, FL 33313
Voice: 954-587-5430
Fax: 954-587-5440
th
Avenue
Advertisement
Table of Contents
Related Manuals for CEECO BLC-303-F
Summary of Contents for CEECO BLC-303-F
- Page 1 SSC-303-F- (303-FS) OR BLC-303-F (303-F)-650-521-CAC6.00-ISSUE4.0 SERVICE MANUAL MODEL SSC-303-F (FORMERLY 303-FS) MODEL BLC-303-F (FORMERLY 303-F) CHARGE-A-CALL TELEPHONE EQUIPPED WITH CAC6.00 FIRMWARE Serving the Telephone Industry Since 1930 Communication Equipment 1580 NW 65 Avenue & Engineering Company Plantation, FL 33313 Voice: 954-587-5430...
-
Page 2: Important Information
ISSUE 4.0 IMPORTANT INFORMATION CUSTOMER Please fill in before you continue. The following information is necessary when calling CEECO for assistance. MODEL NUMBER MODEL SSC-303-F EQUIPPED WITH CAC6.00 FIRMWARE SERIAL NUMBER DATE MANUFACTURED LOCATION INSTALLED For us to better serve you, please have this information available when calling for technical support. -
Page 3: Table Of Contents
RECOMMENDED TOOLS AND TEST EQUIPMENT ........12 INSTALLATION NOTES AND ASSEMBLY INSTRUCTIONS ....13 SPECIFICATIONS....................14 PARTS LIST ......................15 FCC NOTICE......................16 10.0 REPAIR AND RETURN INFORMATION ............17 11.0 WARRANTY POLICY ..................18 12.0 DIAGRAM......................19 CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 4: Introduction
1580 NW 65th Avenue Plantation, FL 33313 (954) 587-5430 GENERAL The CEECO Model SSC-303-F Telephone, equipped with CAC6.00 Firmware, is a stainless steel; microprocessor-based coinless wall phone designed to withstand abuse and fraudulent call attempts. The phone may be programmed to: ... -
Page 5: Programming
Example: Entering #00 followed by 101003 would program the phone to have no call restrictions, no incoming call allowed, a wide dial tone detect window, a muted microphone initially, DTMF dialing, and a 5 minute automatic timed call disconnect. CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 6: Programming Continued
9=30 min.call timeout Be sure to record your selections in the table below for future reference. Telephone Options Table: #00 __ __ __ __ __ __ 1 2 3 4 5 6 CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 7: Programming Continued
1212, when the handset is lifted. Be sure to record your entry in the table below for future reference. 2nd Auto Dial Number Table: #18 __ __ __ __ __ __ __ __ __ __ __ CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 8: Programming Continued
Those locations are #30 thru #69. The speed numbers may be up eleven digits in length. Simply enter the pound key, followed by the location number, followed by the desired speed dial number. CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 9: Programming Continued
#48 __ __ __ __ __ __ __ __ __ __ __ #68 __ __ __ __ __ __ __ __ __ __ __ #49 __ __ __ __ __ __ __ __ __ __ __ #69 __ __ __ __ __ __ __ __ __ __ __ CEECO Communication Equipment & Engineering Company... -
Page 10: Programming Continued
Programming is now completed. Hang up the phone and return the mini- jumpers to the “OFF” position, as depicted on the last page of this manual. The phone is now ready for Testing/Operation. CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 11: Testing/Operation
(three short beeps) and reset the line. If not, hang up and repeat sections 3.2, 3.3, 3.5, 3.9, and 3.10 only. If this does not solve the problem, please refer to section 10.2. CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 12: Testing/Operation Continued
If not, please refer to section 10.2. RECOMMENDED TOOLS AND TEST EQUIPMENT DTMF Test Set Volt/Ohm Meter 1/4" Nut Driver Flat Blade Screw Driver Security Tool, CEECO Part Number 301-037 CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 13: Installation Notes And Assembly Instructions
Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations. Never touch uninsulated telephone wires or terminals unless the telephone line has been disconnected at the network interface. Use caution when installing or modifying telephone lines. CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 14: Specifications
(Handset on hook) MOUNTING: Standard Coinless Public Telephone footprint MEMORY RETENTION: Lithium Battery - Long Life WEIGHT: Approximately 17 Pounds FCC REGISTRATION: BW88T7-13823-TE-T UL LISTED NO.: 6OF5 RINGER EQUIVALENCY: 0.4A TYPE JACK: RJ11C FIRMWARE: CAC6.00 CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 15: Parts List
Number Window 301-040 Number Card 301-051 Backplate 301-054 Modular Connector (RJ11C) 700-008 Keypad Cable 650-570 Network Cable 650-521 MCRK-2 Board 705-110 Connectorized Keypad W/ 705 Mounting 9023 Security Screws ACCESSORIES: 301-037 Security Tool CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 16: Fcc Notice
FCC registration number and ringer equivalence number. These numbers are listed in Section 9.0. The FCC further requires that you notify your local telephone company when permanently disconnecting this telephone. CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 17: Repair And Return Information
Plantation, FL 33313 (954) 587-5430 10.3 NON-WARRANTY REPAIR CEECO will repair equipment out of warranty for a set charge plus parts. The customer must pay the shipping costs both directions. 10.4 RETURN FOR CREDIT Material may be returned for credit only with prior approval. Material authorized for return is subject to a 15% restocking charge based on the manufacturer's list price. -
Page 18: Warranty Policy
11.0 WARRANTY POLICY 11.1 GENERAL CEECO products are guaranteed to be free of defects in material and workmanship for a period of 365 days from the date of original purchase. CEECO's obligation under this warranty is limited to repair or replacement of any part found to be defective by CEECO. -
Page 19: Diagram
POSITION BEFORE GOING OFF HOOK When programming is completed, move the mini jumpers to the OFF position. NOTE: Do not leave the mini jumpers in the ON position; this will decrease battery life. CEECO Communication Equipment & Engineering Company PROPRIETARY...
