GETEST
5.- TECHNICAL FEATURES
5�1�- GETEST
Rated voltage
Frequency
Current
Installation category
Maximum output voltage
Maximum current
Maximum power
Installation category
Type
Maximum voltage
Scales
Input impedance
Resolution
Type
Maximum current
Scales
Input impedance
Resolution
Range
Voltage measurement
Current measurement
Resistance measurement
Protocol
Range
LED
Switch
Operating temperature
Storage temperature
Relative humidity (non-condensing)
Maximum Altitude
Instructions Manual
AC Power supply
Measurement circuit
Voltage measurement
0.8, 30, 70, 105, 280 and 700 V ~ (Self-adjusting)
1 kΩ, 2 kΩ, 10 MΩ (Selectable)
Scales: 08 , 30, 70, 105, 280 V
Scale: 700 V
Current measurement
10, 100 A (Self-adjusting)
Scale: 10 A
Scale: 100 A
Resistance measurement
Accuracy
2.5% reading + 2 digits
Wireless communications
UART protocol, key protected, Class I
TX Power: + 18dBm, Sensitivity: 88 dBm
User interface
1, resistance switch
Environmental features
230 V ~ ± 20% (L1-N)
50 ... 60 Hz
15 A ~
CAT II 300 V
600 V ~
50 A at 10 Ω - 5 A at 110 Ω
30 kW / 20 ms
CAT II 300 V
True effective value
700 V ~
True effective value
100 A
< 0.1 Ω
0.01 A ~
0.1 A ~
0 ... 120 Ω
1% reading + 2 digits
1% reading + 2 digits
2 LEDs
0 ºC ... 40 ºC
-10 ºC ... 50 ºC
595%
2000 m
0.1 V ~
0.5 V ~
